Switch - NETGEAR M4350-24F4V L3 24 SFP+ 4 SFP28 1U Black
Product reference:
14-606449161397
The NETGEAR M4350-24F4V is a managed L3 switch with 24 SFP+ modules and 4 SFP28 ports. It features front-to-back airflow, a 1U footprint, and supports a variety of security and management protocols.
Switch - NETGEAR M4350-24F4V L3 24 SFP+ 4 SFP28 1U Black
Product reference:
14-606449161397
The NETGEAR M4350-24F4V is a managed L3 switch with 24 SFP+ modules and 4 SFP28 ports. It features front-to-back airflow, a 1U footprint, and supports a variety of security and management protocols.
You have 3 products in compare list, please remove someone and try again
- Add to favorites products
- Added to favorites products
- Removed to favorites product
Guarantee
24 month
Delivery from Europe in
8 - 9
business days
Netgear M4350-24F4V Managed L3 1U Black
The NETGEAR M4350-24F4V is a managed L3 switch with 24 SFP+ module slots and 4 SFP28 ports. It features front-to-back airflow, a 1U form factor design, and supports a variety of security and management protocols.
- Managed L3 switch with 24 SFP+ module slots for high-speed networks.
- Front-to-back airflow design in a compact 1U form factor, perfect for rack mounting.
- Comprehensive security features including DHCP snooping, access control lists, and DoS attack prevention.
- Web-based management interface for easy configuration and monitoring.
Design | |
|---|---|
| LED indicator | Yes |
| Possibility of mounting in a pile | Yes |
| Airflow direction | From front to back |
| Product color | Black |
| Rack mounting | Yes |
Power | |
| AC input frequency | 50/60Hz |
| Input current | 6.3 A |
| AC input voltage | 100 - 240V |
| Power (average) | 119.3 W |
| Power supply included | Yes |
| Power source | AC |
Operating conditions | |
| Operating relative humidity (HH) | 0 - 90% |
| Heat release | 374.6 BTU/h |
| Operating height | 0 - 3000 m |
| Storage relative humidity (HH) | 0 - 95% |
| Operating temperature (OT) | 0 - 50 °C |
| Storage temperature (TT) | -20 - 70 °C |
| Idle height | 0 - 3000 m |
Weight and dimensions | |
| Weight | 6.25 kg |
| Width | 440mm |
| Height | 43.2 mm |
| Depth | 400mm |
Network | |
| Network standards | IEEE 802.1D, IEEE 802.1x, IEEE 802.1w, IEEE 802.3u, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ak, IEEE 802.1Qav, IEEE 802.3bz, IEEE 802.1Q, IEEE 802.3ad, IEEE 802.1s |
| Link aggregation | Yes |
| Broadcast storm control | Yes |
| Virtual LAN features | Private VLAN, Voice VLAN, MAC address-based VLAN |
| Policy-based routing | Yes |
| Speed limit | Yes |
| Spanning tree protocol | Yes |
| IPv4 routes | 512 |
| Data flow control support | Yes |
| IPv6 routes | 256 |
| 6to4 tunnel | Yes |
| Full duplex | Yes |
| 10G support | Yes |
| Number of VLANs | 4093 |
| VLAN support | Yes |
Operation | |
| sFlow | Yes |
| Processor frequency | 1800MHz |
| Noise level | 61.8 dB |
| Processor model | ARM Cortex-A57 |
| Memory type | DDR4-SDRAM |
| Built-in processor | Yes |
| Mean Time Between Failures (MTBF) | 778741 hours |
| Flash memory | 512MB |
| Internal memory | 2048MB |
Ports and interfaces | |
| Number of SFP+ module slots | 24 |
| Number of SFP28 ports | 4 |
| Console port | RJ-45 |
| Number of USB 2.0 ports | 2 |
| Main types of RJ-45 Ethernet ports | No |
| Power connector | AC-in jack |
Data transfer | |
| Store-and-forward | Yes |
| Latency (1 Gbps) | 1.06 µs |
| Jumbo frames | 12000 |
| Latency (10 Gbps) | 0.63 µs |
| Throughput | 505.92 Mpps |
| Static route | Yes |
| MAC address table | 16000 entries |
| Packet buffer memory | 32MB |
| Jumbo frame support | Yes |
| Connection capacity | 680 Gbps |
