Rejestrator HiLook Rejestrator IP HiLook by Hikvision NVR-104MH-D 4 kanałowy sieciowy

Key features of the product:

• Up to 4 IP cameras support - ideal solution for smaller surveillance systems
• Recording up to 4 MP - detailed image and clear recordings
• Compression H.265+/H.265/H.264+/H.264 - disk space savings of up to 75%
• Bandwidth up to 60 Mbps - smooth operation and image retention of stabila
• HDMI and VGA outputs (Full HD) - simultaneous monitor connection and easy use
• Simultaneous HDMI/VGA output - greater flexibility in system configuration
• Synchronous playback up to 4 channels - quick access to recordings
• SATA disk support up to 6 TB - large space for archiving records
• Remote access P2P (Hik-Connect / HiLookVision) - monitoring and management from anywhere
• Smart functions (VCA) - Motion detection, line crossing and intrusion
• 10/100 Mbps network interface - stable connection and data transmission
• Compact body - easy installation anywhere

Technical specification - HiLook NVR-104MH-D(D)

• Number of IP channels: 4 (up to 6 MP per channel)
• Bandwidth: 40 Mbps (input) / 60 Mbps (output)

Video and exits

• HDMI output: up to 1920 × 1080 / 60 Hz
• VGA output: up to 1920 × 1080 / 60 Hz
• Output mode: simultaneous HDMI/VGA

Compression and recording

• Compression: H.265+, H.265, H.264+, H.264
• Recording resolution:
• 6 MP / 4 MP / 3 MP / 1080p / 720p / VGA and below
• Flow type: video / video + audio

Decoding and playback

• Decoding:
• 4 × 1080p @30 fps
• 2 × 4 MP @30 fps
• 1 × 6 MP @30 fps
• Synchronous playback: up to 4 channels

Network

• Network interface: 1 × RJ-45 (10/100 Mbps)
• Protocols: TCP/IP, DHCP, DNS, DDNS, NTP, SMTP, UPnP and citi
• Remote connections: up to 16 users

Memory and ports

• SATA interface: 1 × SATA
• Max. disk capacity: up to 6 TB

System functions

• Intelligent recording search and playback
• VCA event support (e.g. motion detection, intrusion, line crossing)
• Third-party camera support (ONVIF)

Audio

• Stream: video + audio (from IP cameras)

Power supply and housing

• Power supply: 12 V DC
• Body type: compact (Mini 1U)
