Registrar Dahua Technology REGISTER IP DAHUA NVR4104-P-EI
Product reference: 3-6923172585615

Registrar Dahua Technology REGISTER IP DAHUA NVR4104-P-EI

Registrar Dahua Technology REGISTER IP DAHUA NVR4104-P-EI

Product reference: 3-6923172585615

Registrar Dahua Technology REGISTER IP DAHUA NVR4104-P-EI

You have 3 products in compare list, please remove someone and try again
  • Add to favorites products
  • Added to favorites products
  • Removed to favorites product
Add to compare
198,26
Product in warehouse

Guarantee
24 month

Delivery from Lithuania in
3 - 8
business days

Your message has been successfully sent!
Fill in the required fields*

Series Overview
NVR4000-EI series is a new generation of network recorders that offers powerful decoding capabilities, and strong bandwidth. It features high-precision face recognition, perimeter protection, and SMD (Smart Motion Detection), which can distinguish target vehicles and humans from other types in real time. When connected with select IPC cameras, Quick Pick technology becomes available, allowing human and vehicle targets to be easily searched for and picked out. This network recorder is not only cost-effective, but also compatible with a wide variety of third-party devices, making it a great choice for small and medium-sized businesses.
Face Recognition
Dahua Face Recognition technology extracts the features of captured faces and compares them with that in face database.
Perimeter Protection
Automatically filters out false alarms caused by animals, rustling leaves, bright lights, etc. Enables the system to perform secondary recognition for the targets. Improves alarm accuracy.
SMD Plus
With intelligent algorithm, Dahua Smart Motion Detection technology can categorize the targets that trigger motion detection and filter the motion detection alarm triggered by non-concerned targets to realize effective and accurate alarm.
AI Search
With AI search, operators can search for videos by the attributes of targets and event types, which helps them to quickly and efficiently investigate where and when targets appeared and events took place.
Heat Map by Camera
Dahua heat map technology is used to display the crowd density and people appearance probability. Export and display the crowd status by different colors. Generally, the crowd status is the statistics of people quantity in space and time dimensions.
ANPR by Camera
With deep learning algorithm, Dahua ANPR technology can recognize the number plate information of vehicles in the image with ANPR cameras. Support blocklist/allowlist mode, searching target vehicles from recorded video.
Quick Pick
Dahua Quick Pick technology can enable users to quickly pick up the human/vehicle targets that they are interested in, which facilitates retrieval from SMD events.


Summary:Dahua Technology WizSense NVR4104-P-EI. Video input channels: 4 channels, Maximum resolution: 3840 x 2160 pixels, Video recording modes: 720p, 960p, 1080p. Maximum storage capacity: 16 TB, HDD interface: SATA. Ethernet LAN data rates: 10,100 Mbit/s, Networking standards: IEEE 802.3af, IEEE 802.3at, Supported network protocols: HTTP; HTTPS; TCP/IP; IPv4/IPv6; UPnP; SNMP; UDP; SMTP; NTP; DHCP; DNA; IP Filter; PPPoE; DDNS;.... Rack capacity: 1U, Product colour: White, Certification: EN IEC 61000-3-2:2019+A1:2021; EN 61000-3-3:2013+A1:2019+A2:2021; EN 55035:2017+A11:2020; EN.... Power consumption (max): 36 W, Power consumption (typical): 25.5 W
Vendor Homepage:https://www.dahuasecurity.com/products/All-Products/Network-Recorders/WizSense-Series/NVR-4-EI-Series/1-HDD/NVR4104-P-EI
Category Code:NVR
CnCode:85219000
Unit Box Height:0.26
Unit Box Length:0.36
Unit Box Width:0.1
Audio formats supported:G.711 µ-law/G.711 A-law/G.726/PCM
Backup function:Yes
Face detection:Yes
Image formats supported:MJPEG
Input bandwidth:80Mbit/s
Maximum resolution:3840 x 2160pixels
Multi-screen:Yes
Operating system installed:Embedded LINUX
Output bandwidth:80Mbit/s
People counting:Yes
Supported resolutions:HDMI: 3840×2160, 1920×1080, 1280×1024, 1280×720
VGA: 1920×1080, 1280×1024, 1280×720
*Simultaneous/heterogeneous video source output for VGA and HDMI is configurable
Video formats supported:H.264/H.264+/H.265/H.265+
Video input channels:4channels
Video recording modes:1080p/720p/960p
Wi-Fi:From
HDD interface:SATA
Maximum storage capacity:16TB
Audio RCA inputs:1
Audio RCA outputs:1
DC-in jack:Yes
Ethernet LAN (RJ-45) port:1
Ethernet LAN data rates:10/100Mbit/s
HDMI output:Yes
HDMI ports quantity:1
Networking standards:IEEE 802.3af/IEEE 802.3at
Power over Ethernet (PoE):Yes
Power over Ethernet (PoE) port quantity:4
Supported network protocols:HTTP; HTTPS; TCP/IP; IPv4/IPv6; UPnP; SNMP; UDP; SMTP; NTP; DHCP; DNA; IP Filter; PPPoE; DDNS; FTP; Alarm Server; IP Search (Support Dahua IP camera; DVR; CIS; etc.); P2P; auto register
USB 2.0 ports quantity:2
VGA (D-Sub) output port:1
Certification:EN IEC 61000-3-2:2019+A1:2021;
EN 61000-3-3:2013+A1:2019+A2:2021; EN
55035:2017+A11:2020; EN 50130-4:2011+A1:2014
CE-LVD: EN 62368-1:2014
Product colour:White
Rack capacity:1U
Rack mounting:Yes
Power consumption (max):36W
Power consumption (typical):25.5W
Browser supported:Chrome; IE9 and later; Firefox
Mobile operating systems supported:Android/iOS
Operating relative humidity (HH):10 - 93%
Operating temperature (TT):-10 - 55°C
Storage temperature (TT):-20 - 60°C
Compliance certificates:CE/Federal Communications Commission (FCC)
Depth:206.4mm
Height:45.6mm
Package depth:96mm
Package height:261mm
Package weight:1380g
Package width:364mm
Weight:500g
Width:204.6mm
Model:NVR4104-P-EI
Model name:NVR4104-P-EI
Units per Pallet:0
Units per Shipping Box:10
Unit Calculated Volume:0.01066m³
Unit Calculated Weight:1.51kg
