REGISTER AHD, HD-CVI, HD-TVI, CVBS, IP XVR5116HS-I3 / T 16 KANAŁÓW DAHUA
Product reference: 3-6937552414990

REGISTER AHD, HD-CVI, HD-TVI, CVBS, IP XVR5116HS-I3/T 16 KANAŁÓW DAHUA

REGISTER AHD, HD-CVI, HD-TVI, CVBS, IP XVR5116HS-I3 / T 16 KANAŁÓW DAHUA

Product reference: 3-6937552414990

REGISTER AHD, HD-CVI, HD-TVI, CVBS, IP XVR5116HS-I3/T 16 KANAŁÓW DAHUA

You have 3 products in compare list, please remove someone and try again
  • Add to favorites products
  • Added to favorites products
  • Removed to favorites product
Add to compare
184,47
Product in warehouse

Guarantee
24 month

Delivery from Europe in
9 - 14
business days

Your message has been successfully sent!
Fill in the required fields*

Launched by Dahua Technology, WizSense is a series of AI products and solutions that adopt an independent AI chip and deep learning algorithm. It focuses on human and vehicle with high accuracy, enabling users to act quickly on defined targets. Based on Dahua's advanced technologies, WizSense provides intelligent, simple and inclusive products and solutions.
Dahua Technology, a world-leading video-centric smart IoT solution and service provider, debuted its new XVR series, XVR5000-I3 Series featuring max.full-channel SMD Plus to benefit customers from AI upgrade (The number of channels differs depending on the model. Please refer to the specifications below for information on the number of channels.). This series has been developed to reduce false-alarm rates and the cost of human surveillance, thus bringing great value to customers in search of products with accurate human/vehicle alarm to raise the security level of various indoor and outdoor facilities.

  • H.265+/H.265 dual-stream video compression
  • Supports Full-channel AI Coding
  • Supports HDCVI/AHD/TVI/CVBS/IP video inputs
  • Max 24 channels IP camera inputs, each channel up to 6MP; Max 128Mbps incoming bandwidth
  • Up to 2 channels video stream (analog channel) Perimeter Protection
  • Up to 16 channels video stream (analog channel) SMD Plus
  • Up to 2 channels video stream (analog channel) human face recognition
  • IoT POS functionalities

Summary:Dahua Technology XVR5116HS-I3/T. Product colour: Black, Maximum video resolution: 3840 x 2160 pixels, Video compression formats: H.264, H.264+, H.265, H.265+. Audio input: 1 RCA, Audio output: 1 RCA, Video in: HDCVI/AHD/TVI/CVBS/IP. Ethernet interface type: Fast Ethernet, Supported network protocols: HTTP, HTTPS, TCP / IP, IPv4, RTSP, UDP, SMTP, NTP, DHCP, DNS, DDNS, P2P. HDD interface: SATA, Maximum HDD capacity: 16 TB. Power supply type: DC, DC voltage: 12 V
Vendor Homepage:https://www.dahuasecurity.com/products/All-Products/HDCVI-Recorders/5MP-Value1080p-Series/XVR5116HS-I3/T
Category Code:STD
CnCode:85219000
Unit Box Height:0.086
Unit Box Length:0.344
Unit Box Width:0.285
Audio input:1 RCA
Audio output:1 RCA
BNC input port:16
HDMI ports quantity:1
RS-485 port:1
USB 2.0 ports quantity:1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A port quantity:1
VGA (D-Sub) output port:1
Video in:HDCVI/AHD/TVI/CVBS/IP
Ethernet interface type:Fast Ethernet
Ethernet LAN:Yes
Ethernet LAN (RJ-45) port:1
Supported network protocols:HTTP, HTTPS, TCP/IP, IPv4, RTSP, UDP, SMTP, NTP, DHCP, DNS, DDNS, P2P
HDD interface:SATA
Maximum HDD capacity:16000GB
Analog signal format system:NTSC/PAL
Audio formats supported:G.711 µ-law/G.711 A-law/PCM
Backup function:Yes
Bitrate:32Kbit/s
Certification:CE: CE-LVD: EN 60950-1/IEC 60950-1
CE-EMC: EN 61000-3-2, EN 61000-3-3, EN 55032, EN
50130, EN 55024
FCC: Part 15 Subpart B
Channel quantity:16channels
Dual stream support:Yes
Maximum video resolution:3840 x 2160pixels
Operating system installed:Embedded LINUX
Product colour:Black
PTZ control:Yes
Rack capacity:1U
Video capturing speed (NTSC):30fps
Video capturing speed (PAL):25fps
Video compression formats:H.264/H.264+/H.265/H.265+
Video loss detection:Yes
Video motion detection:Yes
Video streaming:Yes
DC voltage:12V
Power supply type:DC
Depth:237.4mm
Height:47.6mm
Weight:1170g
Width:260mm
Package depth:333mm
Package height:315mm
Package width:89mm
Operating relative humidity (HH):10 - 90%
Operating temperature (TT):-10 - 55°C
Model:XVR5116HS-I3/T
Units per Shipping Box:1
Unit Calculated Volume:0.008431m³
Unit Calculated Weight:1.58kg
