−1%
NET CAMERA 6MP EYEBALL / HDW3649H-ASPV0280BPRO-B DAHUA
Product reference:
3-6939554948350
NET CAMERA 6MP EYEBALL/HDW3649H-ASPV0280BPRO-B DAHUA
NET CAMERA 6MP EYEBALL / HDW3649H-ASPV0280BPRO-B DAHUA
Product reference:
3-6939554948350
NET CAMERA 6MP EYEBALL/HDW3649H-ASPV0280BPRO-B DAHUA
You have 3 products in compare list, please remove someone and try again
- Add to favorites products
- Added to favorites products
- Removed to favorites product
Guarantee
24 month
Delivery from Europe in
9 - 14
business days
6MP Smart Dual Light Active Deterrence Fixed-focal Eyeball WizSense Network Camera
- 6-MP 1/1.8" CMOS image sensor, low luminance, and high definition image
- Output max. 6 MP (3288 × 1850)@25/30 fps
- H.265 codec, high compression rate, ultra-low bit rate
- Built-in multi-core light, the max. IR distance is 30 m and the max. warm light distance is 30 m. · ROI, SMART H.264+/H.265+, AI H.264/H.265, flexible coding, applicable to various bandwidth and storage environments
- Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes
- Intelligent monitoring: Intrusion, tripwire (the two functions support the classification and accurate detection of vehicle and human)
- Abnormality detection: Motion detection, privacy masking, scene changing, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection
- Alarm: 1 in, 1 out; audio: 1 in, 1 out; supports max. 512 G Micro SD card; built-in dual Mic; 1-ch speaker; support two-way talk
- 12 VDC/PoE power supply
- IP67 protection
- Sound and light alarm (red and blue lights)
- SMD 4.0
- Supports AI SSA and one-tap arming and disarming
- SMD area can be set in warm light areas that support triggering alarms
| Summary: | Dahua Technology WizSense HDW3649H-AS-PV-PRO. Type: IP security camera, Placement supported: Indoor outdoor, Connectivity technology: Wired. Mounting type: Ceiling/wall, Product colour: Black, Form factor: Turret. Minimum illumination: 0.0003 lx, Angle of rotation: 360°, Lens viewing angle, horizontal: 109°. Sensor type: CMOS, Optical sensor size: 25.4 / 1.8 mm (1 / 1.8"). Detect distance: 4.4 m, Fixed focal length: 3.6 mm |
| Vendor Homepage: | https://www.dahuasecurity.com/la/products/All-Products/Network-Cameras/WizSense-Series/3-Series/TiOC/IPC-HDW3649H-AS-PV-PRO |
| Category Code: | FNC |
| CnCode: | 85258900 |
| Unit Box Height: | 0.136 |
| Unit Box Length: | 0.155 |
| Unit Box Width: | 0.155 |
| Form factor: | Turret |
| Housing material: | Metal |
| International Protection (IP) code: | IP67 |
| Mounting type: | Ceiling/wall |
| Product colour: | Black |
| Alarm input/output: | Yes |
| Connectivity technology: | Wired |
| Day/night mode: | Yes |
| Placement supported: | Indoor outdoor |
| Type: | IP security camera |
| Wide Dynamic Range (WDR): | Yes |
| Angle of rotation: | 360° |
| Camera shutter speed: | 1/100000s |
| Camera shutter type: | Electronic |
| Lens viewing angle, diagonal: | 131° |
| Lens viewing angle, horizontal: | 109° |
| Lens viewing angle, vertical: | 59° |
| Minimum illumination: | 0.0003lx |
| Number of Privacy masking areas: | 8 |
| Pan range: | 0 - 360° |
| Tilt angle range: | 0 - 78° |
| White balance: | Auto/Manual/Natural/Outdoor/Regional custom/Street lamp |
| Number of sensors: | 1 |
| Optical sensor size: | 1/1.8" |
| Progressive scan: | Yes |
| Sensor type: | CMOS |
| Detect distance: | 4.4m |
| Fixed focal length: | 3.6mm |
| Fixed focus: | Yes |
| Number of lenses: | 1 |
| LED type: | IR/White |
| Night vision: | Yes |
| Night vision distance: | 30m |
| Number of illumination LEDs: | 2 |
| Back Light Compensation (BLC): | Yes |
| Bit rate control: | Constant Bit Rate (CBR)/Variable Bit Rate (VBR) |
| Frame rate: | 30fps |
| Gain control type: | Auto/Manual |
| Highlight Compensation (HLC): | Yes |
| Maximum resolution: | 3200 x 1800pixels |
| Noise reduction: | Yes |
| Noise reduction technology: | 3D noise reduction |
| Region of Interest (ROI) encoding: | Yes |
| Smart IS: | Yes |
| Supported graphics resolutions: | 1280 x 720 (HD 720)/1280 x 960/1536 x 2048/1920 x 1080 (HD 1080)/2304 x 1296/2560 x 1440/2688 x 1520/2880 x 1620/3200 x 1800/352 x 240/352 x 288/640 x 480 (VGA)/704 x 480/704 x 576 |
| Total megapixels: | 6MP |
| Video compression formats: | H.264/H.264+/H.264B/H.264H/H.265/H.265+/M-JPEG |
| Video streaming: | Yes |
| Audio formats supported: | G.711 µ-law/G.711 A-law/G.723/G.726/PCM |
| Audio input channels: | 1.0channels |
| Audio output channels: | 1.0channels |
| Built-in microphone: | Yes |
| Signal-to-Noise Ratio (SNR): | 56dB |
| Bluetooth: | From |
| Ethernet interface type: | Fast Ethernet |
| Ethernet LAN: | Yes |
| Number of users: | 20user(s) |
| Supported network protocols: | IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNA; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; SAMBA; PPPoE; SNMP |
| Wi-Fi: | From |
| Built-in HDD: | From |
| Card reader integrated: | Yes |
| Compatible memory cards: | MicroSD (TransFlash) |
| Maximum memory card size: | 256GB |
| RAM capacity: | 512MB |
| ROM capacity: | 128MB |
| Alarm input channels: | 1 |
| Alarm output channels: | 1 |
| Digital watermark: | Yes |
| Intelligent Video Surveillance (IVS) system features: | Intrusion/Tripwire |
| Mirror: | Yes |
| Security algorithms: | HTTPS |
| Video motion detection: | Yes |
| Management software: | Smart PSS; DSS; DMSS |
| Web-based management: | Yes |
| DC output voltage: | 12 |
| Power consumption (max): | 8.3W |
| Power consumption (Power over Ethernet (PoE)): | 4.8W |
| Power consumption (typical): | 3.7W |
| Power source type: | DC,PoE |
| Operating relative humidity (HH): | 0 - 95% |
| Operating temperature (TT): | -40 - 60°C |
| Storage temperature (TT): | -40 - 60°C |
| Mobile operating systems supported: | Android/iOS |
| Diameter: | 122mm |
| Height: | 110.9mm |
| Weight: | 745g |
| Package weight: | 915g |
| Number of cameras: | 1 |
| Model: | HDW3649H-ASPV0280B-PRO-B |
| Units per Shipping Box: | 20 |
| Unit Calculated Volume: | 0.0041432m³ |
| Unit Calculated Weight: | 1.06kg |
