Maršrutētājs TP-Link Omada DR3650V

DR3650v
Omada AX3000 Wi-Fi 6 Gigabit Desktop DSL Gateway
Functions

* 2402 Mb/s na 5 GHz a 574 Mb/s na 2.4 GHz
VDSL2 35b:
* Support for DSL connection up to 350 Mb/s
Compatibility with DSL:
* VDSL2/ADSL2+/ADSL2/ADSL
Centralized management in the cloud
Advanced VPN protocols:
* IPSec, PPTP, L2TP, OpenVPN, WireGuard, GRE, SSL VPN
Load balancing:
* Medzi DSL a Ethernet WAN
Omada Mesh Technology:
* Pre extended Wi-Fi pokrytia
Storage:
* 3 × RJ11 ports (2 × FXS, 1 × DSL)
* 5 × RJ45 gigabitových ports
* 2 × USB 3.0 ports
Location:
* Na stool alebo montage na stenu
Dimensions (W × H × V):
* 226 × 131.2 × 35 mm (8.9 × 5.2 × 1.4 inches)

Specifications

Source/Destination IP Based Access Control
Filtering:
* Web Group Filtering
* URL Filtering
* Web Security
Control ARP:
* Sending GARP Packets
* ARP Scanning
* IP-MAC Binding
Protection against attacks:
* TCP/UDP/ICMP Flood Defense
* Block TCP Scan (Stealth FIN/Xmas/Null)
* Block Ping from WAN
HARDWARE EQUIPMENT
Storage:
* 3 × RJ11 ports (2 × FXS, 1 × DSL)
* 5 × RJ45 gigabitových ports (1 × WAN/LAN, 4 × LAN)
* 2 × USB 3.0 porty
Press: Reset Button
Power supply: 12VDC / 3.3A napájácí adapter
Wi-Fi frequency and signal speed:
* 2.4 GHz: 574 Mbps
* 5 GHz: 2402 Mbps (HE160)
Flash memory: 256MB NAND
DRAM: 512 MB DDR4
Dimensions (W × H × V): 226 × 131 × 35 mm
Antennas:
* 2.4 GHz: 2× 3 dBi dvojpásmové odnímatelné anténny
* 5 GHz: 3× 4.5 dBi dvojpásmové odnímatelné anténny
Assembly: Stolová / nástenná / Rackmount (Kit-D226, sold separately)
Maximum energy consumption:
* 30.6 W (with 2 USB 3.0 connections)
* 20.6 W (without USB 3.0 connection)
PERFORMANCE
GRE:
* Unencrypted: 624.2 Mbps
* Encrypted: 301.5 Mbps
WireGuard VPN: 393.5 Mbps
Current shows: 150,000
New shows per second: 5 100
NAT (static IP): 937.2 / 936.1 Mbps
NAT (DHCP): 945.8 / 940.6 Mbps
NAT (PPPoE): 942.9 / 942.9 Mbps
NAT (L2TP): 837.4 / 881.5 Mbps
NAT (PPTP): 803.0 / 910.5 Mbps
IPsec VPN throughput:
* ESP-SHA1-AES256: 646.9 Mbps
* ESP-SHA256-AES256: 642.8 Mbps
* ESP-SHA384-AES256: 648.9 Mbps
* ESP-SHA512-AES256: 658.4 Mbps
OpenVPN: 129.3 Mbps
L2TP VPN permeability:
* Unencrypted: 1034.0 Mbps
* Encrypted: 570.0 Mbps
PPTP VPN throughput:
* Unencrypted: 1165.0 Mbps
* Encrypted: 209.0 Mbps
SSL VPN throughput: 126.7 Mbps
Presmerovanie paketov (66 bytes): 1 453 489 / 1 453 488 pps
Presmerovanie paketov (1518 bytes): 81 274 / 91 275 pps
WIRELESS FUNCTIONS
Advanced features:
* Seamless Roaming
* Mesh (s EAP podporujucim Mesh)
* OFDMA
* Beamforming
* MU-MIMO
* Шифрование бездривуей siete: WPA/WPA2/WPA3 Osobné, WPA/WPA2/WPA3 Enterprise
Host network: Podpora
BASIC FUNCTIONS
WAN connection type:
* Statická IP
* Dynamická IP
* PPPoE (with support MRU configuration)
* PPTP
* L2TP
MAC cloning: Modifikácia WAN adresy
DHCP:
* DHCP server
* DHCPv6 PD server (only in separate mode)
* Úprava DHCP option
* Reserve DHCP adries
* Viacero IP prámání
* Viacero šestových DHCP
IPv6: Statická IP / SLAAC / DHCPv6 / PPPoE / 6to4 tunel / PassThrough / Bez adresy
VLANs: 802.1Q VLAN
IPTV: IGMP v2/v3 proxy, custom mode, bridge mode
Advanced features:
* Statické smerovanie
* Policy Routing
* RIP
* OSPF
Bandwidth management: Riadenie šidakty pásma na zasati IP
Load balancing:
* Inteligentné vyvažovanie zátaže
* Aplikačne optimalizovane smerovanie
* Záložná linka (chasovanie, failover)
* Online detection
NAT:
* One-to-One NAT
* Multi-Net NAT
* Virtual server
* Port triggering
* NAT-DMZ
* FTP/H.323/SIP/IPSec/PPTP ALG
* UPnP
Relationship limit: Obmedzenie reláció podla IP
VPN
SSL VPN: 50 tunnels
IPsec VPN:
* 100 IPSec VPN tunnels
* LAN-to-LAN, client-to-LAN
* Hlavný, agresívny režim vyjedvania
* Šifrovatione algoritmy DES, 3DES, AES128, AES192, AES256
* IPsec failover
* IKE v1/v2_
* Autentizačné algoritmy MD5, SHA1, SHA2-384, SHA2-512
* NAT Traversal (NAT-T)
* Detekcia dead partnerov (DPD)
* Perfect Forward Secrecy (PFS)
PPTP VPN:
* PPTP VPN server
* PPTP VPN client (10)
* 50 tunnels
* PPTP s MPPE encryption
L2TP VPN:
* L2TP VPN server
* L2TP VPN client (10)
* 50 tunelov
* L2TP cez IPSec
OpenVPN:
* OpenVPN server
* OpenVPN client (5)
* 55 OpenVPN tunelov
* Regim "Certifikát + účet"
* Full regime
WireGuard VPN: 20 tunelov
AUTHENTICATION
Web authentication:
* Without authentication
* Simple password
* Hotspot (local user / voucher / SMS / Radius)
* Externý Radius server
* Externý portálový server
* LDAP
DEVICE MANAGEMENT
Omada application: Áno
Centralized administration:
* Omada cloudový radič
* Omada hardvérový radič
* Omada softvérový radič
Cloud access: Áno (vyžaduje Omada cloudový radič)
Services: Dynamic DNS (Dyndns, No-IP, Peanuthull, Comexe, Custom DDNS)
Maintenance:
* Webové právní pre spravá
* Vzdialená správa
* Export a import configuration
* SNMP v1/v2c/v3_
* Diagnostics (ping traceroute)
* Synchronization of clocks NTP
* Port mirroring
* CLI (only in separate mode)
* Support syslogu
* TR-069 (podpora dátových modelov TR-098 a TR-181)
Zero-Touch provisioning: Áno (vyžaduje Omada cloudový radič)
PROTOCOLS
IPv4/IPv6: Áno
Firewall: Stateful Packet Inspection (SPI)
DHCP Server: IPv4 a IPv6
VPNs: IPSec, PPTP, L2TP, OpenVPN, WireGuard, SSL VPN
QoS: 802.1p, DSCP
Routing: Static, RIP, OSPF
OTHER
Working temperature: 0 °C ~ 40 °C
Relative humidity: 10% ~ 90% (non-condensing)
Certification: CE, FCC, RoHS
