Motherboard ASRock B760M-X GEN5
Product reference:
3-4711581492356
Motherboard ASRock B760M-X GEN5
Motherboard ASRock B760M-X GEN5
Product reference:
3-4711581492356
Motherboard ASRock B760M-X GEN5
You have 3 products in compare list, please remove someone and try again
- Add to favorites products
- Added to favorites products
- Removed to favorites product
Guarantee
24 month
Delivery from Europe in
10 - 15
business days
| Processor | |
|---|---|
| Processor manufacturer | Intel |
| Compatible processor series | Intel Core i3 12th Gen, Intel Core i3 13th Gen, Intel Core i5 14th Gen, Intel Core 13th Gen, Intel i5 12th Gen, Intel Core i3 14th Gen |
| Processor socket | LGA 1700 |
| Features | |
| Motherboard chipset | Intel B760 |
| Audio chip | Realtek ALC897 |
| Audio output channels | 7.1 channels |
| Motherboard chipset family | Intel |
| Motherboard form factor | micro ATX |
| Windows operating systems supported | Windows 10 x64, Windows 11 x64 |
| Memory | |
| Unbuffered memory | Yes |
| Maximum internal memory | 128GB |
| Supported memory clock speeds | 7200 |
| ECC compatibility | Non-ECC |
| Supported memory types | DDR5-SDRAM |
| Memory slot type | SO-DIMM |
| Number of memory slots | 2 |
| Memory channels | Dual channel |
| Weight dimensions | |
| Width | 244 mm |
| Depth | 221 mm |
| Network | |
| LAN controller | Dragon RTL8125BG |
| Wi-Fi | From |
| Ethernet LAN | Yes |
| Top Wi-Fi standard | Not available |
| Ethernet interface type | 2.5 Gigabit Ethernet |
| Internal I/O | |
| Number of SATA III connectors | 4 |
| ATX Power connector (24-pin) | Yes |
| CPU fan connector | Yes |
| Front panel audio connector | Yes |
| USB 3.2 Gen 1 (3.1 Gen 1) connectors | 1 |
| EPS power connector (8-pin) | Yes |
| USB 2.0 connectors | 2 |
| TPM connector | Yes |
| RGB LED pin header | Yes |
| BIOS | |
| BIOS type | UEFI AMI |
| Packaging content | |
| Cables included | SATA |
| Storage controllers | |
| Supported storage drive interfaces | SATA III, M.2 |
| RAID levels | 1, 5, 0, 10 |
| RAID support | Yes |
| Number of storage drives supported | 6 |
| Rear panel I/O port | |
| DisplayPort version | 1.4 |
| Ethernet LAN (RJ-45) port | 1 |
| USB 2.0 ports quantity | 2 |
| DisplayPort quantity | 1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C port quantity | 1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A port quantity | 3 |
| HDMI port quantity | 1 |
| Expansion slot | |
| Number of M.2 (M) slots | 2 |
| PCI Express x1 (Gen 3.x) slot | 1 |
| PCI Express x16 (Gen 5.x) slot | 1 |
