SONOFF Zigbee Smart Curtain Motor

SONOFF smart curtain motor, Zigbee3.0
SONOFF smart home system allows you to control electrical appliances remotely using the "eWeLink" app or by voice with "Amazon Alexa" or "Google Home". It allows you to create various scenarios, group devices to turn on/off multiple devices in your home with one touch, set desired timers and schedules, monitor the status of your home and devices in real time, and share their control. Sonoff smart home system devices have the built-in ability to operate in a local LAN network without a cloud server.
Features:

• The smart curtain motor is designed to automate the curtains in your home. It is simple and easy to turn existing curtains into smart ones, does not require special installation, tools, or changing the curtain rail. Suitable for one-way or two-way curtain opening.


• The curtains are controlled remotely via an app or remote control (control control included).


• Manual start or stop is also made easier. The collected data on the movement process of the curtains allows you to calculate the operating voltage curve of the curtains. Therefore, it is enough to just gently move the curtain for it to automatically open and stop. The powerful motor can easily pull a curtain weighing up to 8 kg at a constant speed.


• Supports creation and management of various scenarios, device grouping, timer settings, synchronization, and control sharing.


• Voice control via Google Assistant or Amazon Alexa, supports SmartThings and Alice.


• The main motor uses a rechargeable 4000 mAh lithium-ion battery, which can be used for up to 3 months on a full charge. Continuous charging is possible via a USB Type-C cable.


• This motor can be combined with a variety of other products to complement smart home scenarios.

Technical data:

• Compatible with: Sonoff ZBBridge, ZBBridge-P, NSPanel Pro, ZBDongle-P, ZBDongle-E; SmartThings hub V3, AeoTec Smart Home Hub V3; Echo Plus 2nd, Echo 4th Gen, Echo Show 2nd.


• Catering: DC 5V (1A).


• Wireless connection: Zigbee 3.0.


• Max. power: 5W.


• Curtain rail length: up to 3.5 m.


• Max. curtain rail diameter: 40 mm.


• Max load: 8 kg.


• Engine battery model: Li-ion, 103450 (2x 3.7V).


• Engine battery capacity: 4000mAh.


• Charging interface: USB Type-C.


• App: eWeLink (Android, iOS).


• Works with Amazon Alexa Google Assistant.


• Remote control battery model: CR2032 (1x 3V).


• Remote control operating frequency: 2.4GHz.


• Main engine dimensions: 115x78x29 mm.


• Dimensions of the auxiliary engine: 115x58x28 mm.


• Remote control dimensions: 110x50x10 mm.


• Housing material: ABS plastic.


• Operating temperature: 0°C~40°C.


• Color: white.


• The set includes: Curtain motor (main motor, auxiliary motor, drive chain, clamp), 1x remote control, 1x charging cable USB Type-C 3m, installation kit (screws, brackets, mounting base with adhesive, etc.).
