Matter-compatible white smart wall outlet that allows you to remotely control devices, set operating schedules, and monitor energy consumption via 2.4 GHz Wi-Fi. Suitable for loads up to 4,000 W and 16 A, it has overload, overvoltage, overcharging, and child lock protection.
Matter-compatible white smart wall outlet that allows you to remotely control devices, set operating schedules, and monitor energy consumption via 2.4 GHz Wi-Fi. Suitable for loads up to 4,000 W and 16 A, it has overload, overvoltage, overcharging, and child lock protection.
Guarantee
24 month
Delivery from Europe in
15 - 16
business days
Matter-compatible white Wi-Fi smart wall socket that allows you to remotely control devices, set schedules and monitor energy consumption via 2.4 GHz Wi-Fi. Designed for loads up to 4,000 W and 16 A, with overload, surge, overcharge and child protection.
Product information | |
|---|---|
| Product type | Matter-compatible smart Wi-Fi wall outlet |
| Brand | Sonoff |
| Model | WS01TPF-E |
| Color | White |
| Mounting type | Recessed wall mounting |
Technical specifications | |
| Rated voltage | 100-250V AC, 50/60Hz |
| Wireless communication standard | IEEE 802.11 b/g/n Wi-Fi, 2.4 GHz |
| Standby power consumption | <1W |
| Housing material | PC |
| Operating temperature | from -10°C to 40°C |
| Operating humidity | 5-95% RH, non-condensing |
| Dimensions | 86 × 86 × 42.5mm |
Installation and compatibility | |
| Compatible mounting boxes | Standard 86 type and European 60 mm diameter mounting boxes |
| Recommended cables | 1.5-2.5 mm² single or multi-core copper wires |
| Compatible plug types | Type F, Type C and Type F E (CEE 7/7) |
| Local governance | Available without a cloud connection |
Smart features | |
| Compatibility with smart home systems | Apple Home, Google Home, Amazon Alexa, Samsung SmartThings, Home Assistant and eWeLink |
| Management methods | App, voice commands, schedules and automated scripts |
| Energy monitoring | Real-time monitoring of energy consumption of connected devices |
| Linking | Setup via eWeLink app or pairing by scanning Matter QR code |
| Relay operating time | Up to 20,000 switching cycles |
Safety | |
| Security features | Overload, overvoltage, overcharge and child protection function |
| Safety warning | For indoor electrical installation only. Installation and wiring work must be carried out by a qualified electrician, with the power supply disconnected. Use only with compatible cables and do not exceed the rated voltage, current and load limits. Do not use if the socket or cables are damaged. Keep the device away from moisture and children. |
| Height | 100mm |
| Length | 150mm |
| Weight | 250 g |
| Width | 150mm |
