The Shelly Plus 0-10V dimmer allows you to control your lighting wirelessly via WiFi and Bluetooth, allowing you to adjust brightness and set schedules. It is compatible with various home assistants and supports individual scenarios, adapting the lighting to the user's preferences.
The Shelly Plus 0-10V dimmer allows you to control your lighting wirelessly via WiFi and Bluetooth, allowing you to adjust brightness and set schedules. It is compatible with various home assistants and supports individual scenarios, adapting the lighting to the user's preferences.





The Shelly Plus 0-10V dimmer allows you to control your lighting wirelessly via WiFi and Bluetooth, allowing you to adjust brightness and set schedules. It is compatible with various home assistants and supports individual scenarios, adapting the lighting to the user's preferences.
Guarantee
24 month
Delivery from Europe in
15 - 16
business days
Shelly Plus 0-10V dimmer allows you to control lighting wirelessly via WiFi and Bluetooth, allowing users to adjust brightness and set schedules. It is compatible with various home assistants and supports custom scenarios to create personalized lighting scenarios.
Features | |
|---|---|
| Product type | Light dimmer |
| Brand | Shelly |
| Model | Plus 0-10V |
Specifications | |
| Supply voltage | 110V to 240V AC |
| Power | up to 1.2 W |
| Neutral wire | Not necessary |
| Control type | Voltage 0 - 10 V (stepping down) |
| Maximum control voltage | 10V DC |
| Maximum control current | 0.35W |
| WiFi protocol | 802.11 b/g/n |
| WiFi range | Up to 30 m indoors, up to 50 m outdoors |
| Bluetooth standard | 4.2 |
| Bluetooth range | Up to 10 m indoors, up to 30 m outdoors |
| Chip | ESP32 4MB Flash |
| Number of schedules | 20 |
| MQTT | Yes |
| Working temperature | -20°C to 40°C |
| Working humidity | 30% to 70% RH |
| Dimensions | 42 × 37 × 17 mm |
| Weight | 17 grams |
| Height | 100mm |
| Length | 60mm |
| Weight | 30 g |
| Width | 80mm |
