Occupancy Sensor - MOES HP02 ZigBee mmWave Occupancy Sensor
Product reference: 14-6974246478289

MOES HP02 - ZigBee millimeter wave presence sensor that detects motion, breathing and subtle movements up to 6 meters away. Powered by a 5V USB connection, it has a magnetic base with 360° rotation and 45° angle adjustment, and works with the Smart Life, MOES and Tuya apps with a compatible ZigBee gateway.

Occupancy Sensor - MOES HP02 ZigBee mmWave Occupancy Sensor

Product reference: 14-6974246478289

MOES HP02 - ZigBee millimeter wave presence sensor that detects motion, breathing and subtle movements up to 6 meters away. Powered by a 5V USB connection, it has a magnetic base with 360° rotation and 45° angle adjustment, and works with the Smart Life, MOES and Tuya apps with a compatible ZigBee gateway.

You have 3 products in compare list, please remove someone and try again
  • Add to favorites products
  • Added to favorites products
  • Removed to favorites product
Add to compare
49,12 €
Product in warehouse

Guarantee
24 month

Delivery from Europe in
15 - 16
business days

Your message has been successfully sent!
Fill in the required fields*

MOES HP02 ZigBee mmWave presence sensor


MOES HP02 - ZigBee mmWave presence sensor that detects motion, breathing and slight movements up to 6 meters away. Powered via 5V USB port. The magnetic base can rotate 360°, and the tilt angle can be adjusted up to 45°. The sensor works with "Smart Life", " MOES " and "Tuya" apps using a compatible ZigBee gateway.


  • The 24 GHz mmWave radar detects movement and a stationary person, including slight breathing and micro-movements.
  • Works reliably regardless of lighting, temperature or air flow. Detection angles and distances can be adjusted.
  • ZigBee connectivity ensures integration with "Smart Life", " MOES " and "Tuya" apps, automation scenarios, and instant presence notifications.
  • The compact 49.66 mm body with magnetic base, 45° tilt adjustment and 360° rotation allows flexible mounting on a wall or ceiling.

Product information

Product type ZigBee mmWave presence sensor
Brand MOES
Model HP02
Detection technology 24 GHz mmWave radar
Power supply 5V DC, 1A via USB
Energy consumption 0.5W

Technical specifications

Radar frequency 24-24.25 GHz
Radar radiation power 7.6 dBm
Wireless frequency band 2.400-2.483 GHz
Maximum wireless transmission power < +20 dBm
Light sensitivity range 0-10,000 lux
Operating temperature from -10°C to 40°C
Operating humidity 0-95% relative humidity, non-condensing

Installation and compatibility

Installation Magnetic base for wall or ceiling mounting
Regulation 45° tilt and 360° rotation
Housing diameter 49.66mm
Compatible apps Smart Life, MOES and Tuya
Required equipment Compatible ZigBee gateway, sold separately

The set includes:

Contents
  • Presence sensor
  • Magnetic base
  • USB cable
  • User manual

Safety information

Safety warning Use the sensor only for presence detection and home automation purposes. Use the specified 5V power supply, keep away from water and high heat, do not modify or disassemble the device. A compatible ZigBee gateway is required for the device to function.

Height70 mm
Length70 mm
Weight150 g
Width70 mm
