MOES HP02 - ZigBee millimeter wave presence sensor that detects motion, breathing and subtle movements up to 6 meters away. Powered by a 5V USB connection, it has a magnetic base with 360° rotation and 45° angle adjustment, and works with the Smart Life, MOES and Tuya apps with a compatible ZigBee gateway.
MOES HP02 - ZigBee millimeter wave presence sensor that detects motion, breathing and subtle movements up to 6 meters away. Powered by a 5V USB connection, it has a magnetic base with 360° rotation and 45° angle adjustment, and works with the Smart Life, MOES and Tuya apps with a compatible ZigBee gateway.





MOES HP02 - ZigBee millimeter wave presence sensor that detects motion, breathing and subtle movements up to 6 meters away. Powered by a 5V USB connection, it has a magnetic base with 360° rotation and 45° angle adjustment, and works with the Smart Life, MOES and Tuya apps with a compatible ZigBee gateway.
Guarantee
24 month
Delivery from Europe in
15 - 16
business days
MOES HP02 - ZigBee mmWave presence sensor that detects motion, breathing and slight movements up to 6 meters away. Powered via 5V USB port. The magnetic base can rotate 360°, and the tilt angle can be adjusted up to 45°. The sensor works with "Smart Life", " MOES " and "Tuya" apps using a compatible ZigBee gateway.
Product information | |
|---|---|
| Product type | ZigBee mmWave presence sensor |
| Brand | MOES |
| Model | HP02 |
| Detection technology | 24 GHz mmWave radar |
| Power supply | 5V DC, 1A via USB |
| Energy consumption | 0.5W |
Technical specifications | |
| Radar frequency | 24-24.25 GHz |
| Radar radiation power | 7.6 dBm |
| Wireless frequency band | 2.400-2.483 GHz |
| Maximum wireless transmission power | < +20 dBm |
| Light sensitivity range | 0-10,000 lux |
| Operating temperature | from -10°C to 40°C |
| Operating humidity | 0-95% relative humidity, non-condensing |
Installation and compatibility | |
| Installation | Magnetic base for wall or ceiling mounting |
| Regulation | 45° tilt and 360° rotation |
| Housing diameter | 49.66mm |
| Compatible apps | Smart Life, MOES and Tuya |
| Required equipment | Compatible ZigBee gateway, sold separately |
The set includes: | |
| Contents |
|
Safety information | |
| Safety warning | Use the sensor only for presence detection and home automation purposes. Use the specified 5V power supply, keep away from water and high heat, do not modify or disassemble the device. A compatible ZigBee gateway is required for the device to function. |
| Height | 70 mm |
| Length | 70 mm |
| Weight | 150 g |
| Width | 70 mm |
