Smart Home Controller - Shelly 2PM Gen3, 4-Piece Set, Wi-Fi / Bluetooth, Black
Product reference:
14-3800235261927
" Shelly 2PM Gen3" - a black two-channel smart controller designed to remotely turn on and off two electrical circuits or control blinds and other two-way motors, monitoring the energy consumption of each channel. The set includes four controllers with Wi-Fi and Bluetooth connectivity, temperature, voltage and current monitoring, automation functions, and protection against overheating, overvoltage and overload.
Smart Home Controller - Shelly 2PM Gen3, 4-Piece Set, Wi-Fi / Bluetooth, Black
Product reference:
14-3800235261927
" Shelly 2PM Gen3" - a black two-channel smart controller designed to remotely turn on and off two electrical circuits or control blinds and other two-way motors, monitoring the energy consumption of each channel. The set includes four controllers with Wi-Fi and Bluetooth connectivity, temperature, voltage and current monitoring, automation functions, and protection against overheating, overvoltage and overload.
You have 3 products in compare list, please remove someone and try again
- Add to favorites products
- Added to favorites products
- Removed to favorites product
Guarantee
24 month
Delivery from Europe in
15 - 16
business days
Shelly 2PM Gen3, 4-piece set
Shelly 2PM Gen3 - black two-channel smart controller for remotely turning on and off two electrical circuits or controlling blinds and other two-way motors. Each channel has an energy monitoring function. The set includes four controllers with Wi-Fi and Bluetooth connectivity, integrated temperature, voltage and current monitoring, automation support, and protection against overheating, overvoltage and overload.
- 4 Shelly 2PM Gen3 smart two-channel controller set for remotely turning on and off two electrical circuits or controlling blinds, awnings and other two-way motors.
- Monitor the energy consumption of each channel and control connected devices via Wi-Fi or Bluetooth using the " Shelly " app and compatible smart home systems.
- Supports Cover Control, which provides precise positioning, obstacle detection, and automatic stopping to make motorized blinds and shutters operate more safely.
- Compact design for installation in a flush-mounted box, with integrated protection against overheating, overvoltage, overload and excessive power consumption.
Product information | |
|---|---|
| Product type | Smart two-channel controller |
| Brand | Shelly |
| Model | Shelly 2PM Gen3 |
| Set quantity | 4 controls |
| Color | Black |
| Housing material | Plastic |
| 37 × 42 × 16 mm per controller | |
| Weight | 30g per controller |
Electrical specifications | |
| Power supply | 110-240 V AC or 24 V DC ±10% |
| Energy consumption | Less than 1.4 W |
| Maximum voltage | 240V AC / 30V DC |
| Maximum switching current | 16 A at 240 V AC / 10 A at 30 V DC |
| Channel configuration | Two channels in the same phase |
| Supported conductor cross-section | 0.2-2.5 mm² / 24-14 AWG |
| Maximum terminal tightening torque | 0.4 Nm |
| Installation | Flush-mounted box or wall-mounted box |
Communication and processing | |
| Wi-Fi standard | 802.11 b/g/n, 2.4 GHz |
| Wi-Fi range | Up to 50 m outdoors or 30 m indoors, depending on local conditions |
| Bluetooth | Bluetooth 4.2 |
| Bluetooth operating range | Up to 30 m outdoors or 10 m indoors, depending on local conditions |
| Processor | ESP- Shelly -C38F |
| Flash memory | 8MB |
| Wireless features | Wi-Fi range extender and Bluetooth gateway |
Control and automation | |
| Engine control | Cover Control for blinds, awnings, curtains, shutters, sliding doors and other two-way motors |
| Positioning | Precise control of motor and blind position |
| Schedules | Up to 20 |
| Web notifications | Up to 20, up to 5 URLs per message |
| Automation support | Scripting, MQTT, WebSocket, HTTPS, UDP, TLS and KNXnet/IP |
| Encryption | Supported |
Monitoring and protection | |
| Energy measurement | Monitoring voltage, current and energy for each channel |
| Temperature sensor | Integrated |
| Protection | Protection against overheating, overvoltage, overload and excessive power consumption |
| Obstacle detection | Supported in Cover Control mode |
| Automatic engine stop | Supported when obstacles are detected or unsafe operating conditions occur |
Operating conditions | |
| Operating temperature | −20-40 °C |
| Relative humidity | 30-70% |
| 2,000 m | |
| Safety warning | Installation and wiring work involves mains voltage and should be carried out by a qualified electrician with the power disconnected. Use only within the electrical specifications and only for compatible circuits or bi-directional motors. Do not install or use a damaged controller. |
| Height | 60mm |
| Length | 200mm |
| Weight | 180 g |
| Width | 120mm |
