Homematic IP 157662A0 LED lighting controller

Homematic IP 157662A0. Housing colour: White, Wireless range: 260 m, Operating frequency: 868.0-868.6/869.4-869.65 MHz. Input voltage: 12 - 24 V. Width: 170 mm, Depth: 40 mm, Height: 26 mm
Control LED strips smart - for individual light
Colorful lights for the birthday party or an adjusted brightness progression with LED strips in the home office: smart light scenes always provide exactly the atmosphere you want. Adjust the LEDs to the course of the day or recreate the light of classic light bulbs. You can control your LED strips individually via the Homematic IP LED controller in your smart home. Up to four channels are available for this purpose. Via the Homematic IP app, you can set up brightness, color and time profiles individually and operate the entire system conveniently. You can also operate the LED controller with the Homematic IP wireless remote control and voice control with Amazon Alexa or Google Assistant.
Individual setting of light and color moods
In the app, you can, among other things, configure switch-on times of the LED strips and set individual dimming times. This allows you to control the brightness of the LED strips depending on the time of day. In addition, you can also define the light temperature (Tunable White) and color moods (RGB, RGBW) with the LED controller.
Adapted to the course of daylight
Using the "Dynamic Daylight" mode of the LED controller, the light adapts to the natural course of daylight. Thus, the light changes from reddish to bluish light during the day and back again in the evening.
Dim2Warm
With Dim2Warm, the dimming behavior of a classic incandescent lamp is replicated. The darker the LED strip is set, the warmer the light becomes. The brighter the LED is set, the colder the light appears.
Easy assembly
The Homematic IP LED controller is simply mounted on the wall or in the false ceiling. Suitable for the LED strips used, a corresponding power supply unit must be purchased separately.

Features

Housing colour: White
Wireless range: 260 m
Operating frequency: 868.0-868.6/869.4-869.65 MHz
International Protection (IP) code: IP20

Power

Input voltage: 12 - 24 V

Weight dimensions

Width: 170 mm
Depth: 40 mm
Height: 26 mm
Weight: 79 g
