Digitus DS-72220-3GE rack console

Digitus 17" HD LCD KVM Console, 16-Port VGA, german Keyboard. Display diagonal: 43.2 cm (17"), Display resolution: 1920 x 1080 pixels, Contrast ratio (typical): 1000:1. Video port type: VGA. Keyboard language: German, Keyboard layout: QWERTZ. Width: 509 mm, Height: 45 mm, Depth: 445 mm. Package weight: 19.1 kg, Package width: 755 mm, Package depth: 625 mm
Maximum flexibility in the administration of the server farm
- TFT monitor 43.2 cm (17"), with anti-reflective, shatter-proof protective glass pane
- The console can be completely pulled out of the server cabinet and the TFT screen can be tilted by 120 degrees
- Supports various cabinets from 800mm to 1200mm depth All KVM cables are included in the scope of delivery
- Full HD 1080P resolution
- 1x USB peripheral port in the console area
- LED display for the connection status
- TFT monitor 43.2 cm (17"), with anti-reflective, shatter-proof protective glass pane
- The console can be completely pulled out of the server cabinet and the TFT screen can be tilted by 120 degrees
The Digitus HD LCD KVM console - with a 17" TFT monitor with anti-reflective and shatterproof protective glass panel. The console can be completely pulled out of the server cabinet and the TFT screen can be tilted by 120 degrees. This console supports various cabinets from 800mm to 1200mm depth and comes complete with all KVM cables. With full HD 1080P resolution and LED indicator for connection status, this console also features a USB peripheral port in the console area. Enjoy up to 85% more space with this console and a contrast rate of 1000:1 as well as support for 16.7 million colors. The package includes a 16-port VGA adapter, a keyboard and a touch-board mouse with two function buttons. With a modular and expandable design, this console is also cascadable.

Display

Display diagonal: 43.2 cm (17")
Display resolution: 1920 x 1080 pixels
Contrast ratio (typical): 1000:1
Aspect ratio: 16:9
Display type: TFT
Display number of colours: 16.78 million colours

Technical details

Product colour: Black
Rack capacity: 1U

Ports interfaces

VGA (D-Sub) ports quantity: 16
Video port type: VGA
USB 2.0 Type-A ports quantity: 1
DC-in jack: Yes

Keyboard

Built-in touchpad: Yes
Keyboard language: German
Keyboard layout: QWERTZ

Weight dimensions

Width: 509 mm
Height: 45 mm
Depth: 445 mm
Mounting depth (min): 80 cm
Mounting depth (max): 120 cm

Packaging data

Package weight: 19.1 kg
Package width: 755 mm
Package depth: 625 mm
Package height: 186 mm
Package volume: 87768.8 cm³

Packaging content

Mounting brackets included: Yes
Quick installation guide: Yes
AC adapter included: Yes
