Digitus DN-95426 power distribution unit (PDU)

Digitus Socket strip with aluminum profile, 12-way, 2 m supply cable with earthing contact plug. Rack capacity: 1U, Type: Single-phase, Mounting: Horizontal. AC outlets quantity: 12 AC outlet(s), AC outlet types: C13 coupler, Power plug: Type F. Cable length: 2 m, Cable type: 1.5 mm². Nominal input voltage: 230 V, Maximum current: 16 A, AC input frequency: 50 - 60 Hz. Width: 45 mm, Depth: 45 mm, Height: 482.6 mm

Safe and professional power supply in the 482.6 mm (19") range

- Perfect power distribution for your network and IT rack
- Compact design, 19" 1U housing
- The sockets offer optimum space management and easy access

The DIGITUS® power strips are the perfect solution for your network or server cabinet. In terms of power distribution, the PDU meets the requirements of many applications in IT, network technology, laboratories and the home. The power strip can be mounted in the 19" area of the cabinet in a space-saving 1U.

Design

Type: Single-phase
Rack capacity: 1U
Mounting: Horizontal
Housing material: Aluminium, Plastic

Ports & interfaces

AC outlets quantity: 12 AC outlet(s)
Power plug: Type F
AC outlet types: C13 coupler
Master AC outlets quantity: 12

Features

Cable length: 2 m
Cable type: 1.5 mm²

Power

Nominal input voltage: 230 V
AC input frequency: 50 - 60 Hz
Maximum current: 16 A
Block 1 output current: 10 A
Output voltage: 230 V
Load capacity: 3600 VA
Number of phases: 1

Weight & dimensions

Width: 45 mm
Depth: 45 mm
Height: 482.6 mm
Size (imperial): 48.3 cm (19")

Packaging content

Feature: Manual
Feature: Rack mount kit

Packaging data

Package weight: 100 g
Package width: 0 mm
Package depth: 0 mm
Package volume: 0 cm³

Logistics data

Country of origin: China
