Digitus DN-80114 network switch

Digitus 10" Gigabit 8-Port Unmanaged Switch. Switch type: Unmanaged. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 8. Full duplex. MAC address table: 8000 entries, Switching capacity: 16 Gbit/s. Networking standards: IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3x. Rack mounting
Simplifies the setup of small Gigabit networks in 10" wall-mounted housings - quietly, efficiently and without configuration effort.
- Eight full Gigabit ports for flexible network expansion
- Compact 10" design - ideal for wall-mounted enclosures and small distribution cabinets
- Non-blocking, non-head-of-line forwarding for efficient data transmission
- Only 5 W power consumption - very energy efficient
- Fanless design for silent operation
- Auto MDI/MDI-X - no crossover cables required
- Supports up to 8K MAC addresses - suitable for growing networks
- Store-and-forward technology increases transmission security
- Supports IEEE 802.3, 802.3u, 802.3ab, 802.3x - high compatibility
- Simple plug-and-play installation without management know-how
The DIGITUS® DN-80114 is a compact 8-port Gigabit switch in a 10" form factor that has been specially developed for small to medium-sized networks and installation in 10" wall-mounted housings. With eight 10/100/1000Base-T ports, it offers enough connections to connect PCs, printers, access points, media players or other network devices reliably and with high bandwidth. The switch is completely unmanaged and supports auto-negotiation and Auto MDI/MDI-X, which eliminates cabling errors and reduces installation time. The non-blocking, non-head-of-line architecture combined with a 16 Gbps backplane ensures fast and efficient data transmission without bottlenecks. Store-and-forward technology checks each packet before forwarding, thus increasing transmission security. With a very low power consumption of just 5 watts, fanless design and compact dimensions, the DN-80114 is ideal for use in quiet environments such as offices, meeting rooms, home offices or small technology cabinets. Top USP: Compact, energy-efficient 10" Gigabit switch with eight ports for simple, reliable networking.

Management features

Switch type: Unmanaged

Ports interfaces

Basic switching RJ-45 Ethernet ports quantity: 8
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)

Network

Networking standards: IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3x
10G support: No
Full duplex: Yes
Auto MDI/MDI-X: Yes
VLAN support: No

Data transmission

Switching capacity: 16 Gbit/s
MAC address table: 8000 entries
Store-and-forward: Yes

Design

Rack mounting: Yes
Product colour: Grey
Vandal-proof: No
Suitable for outdoor use: No

Power

Power consumption (typical): 5 W

Power over Ethernet (PoE)

Power over Ethernet (PoE): No

Other features

Ethernet interface type: Gigabit Ethernet

Operational conditions

Operating temperature (T-T): 0 - 40 °C

Weight dimensions

Width: 250 mm
Depth: 150 mm
Height: 42 mm

Packaging data

Package width: 320 mm
Package depth: 240 mm
Package volume: 5145.6 cm³
Package weight: 1.44 kg

Logistics data

UK Trade Tariff code: 85176200
Country of origin: China
Harmonized System (HS) code: 85176990
