Power Supply 12v, 4.5a, 60w, Din
Product reference:
14-9990000700509
This product is a 12V, 4.5A, 60W pulse shunt diode. It is used to regulate voltage and current in electronic circuits. The main purpose of the product is to regulate voltage and current in electronic circuits. The main features include a maximum output power of 54W, a 9%/+10% input voltage range, and a temperature range of -20°C to +60°C.
Power Supply 12v, 4.5a, 60w, Din
Product reference:
14-9990000700509
This product is a 12V, 4.5A, 60W pulse shunt diode. It is used to regulate voltage and current in electronic circuits. The main purpose of the product is to regulate voltage and current in electronic circuits. The main features include a maximum output power of 54W, a 9%/+10% input voltage range, and a temperature range of -20°C to +60°C.
You have 3 products in compare list, please remove someone and try again
- Add to favorites products
- Added to favorites products
- Removed to favorites product
Guarantee
24 month
Delivery from Europe in
4 - 5
business days
Not available
Switching power supply 12V, 4.5A, 60W, DIN.
Features:
- The power supply operating in pulse mode can be mounted on a 35mm DIN rail.
- Protection: against overload, voltage surge, short circuit.
- Cooling by free air convection.
- Small volume, low weight, high efficiency.
Technical data:
- Power supply type: switching.
- Input voltage: AC 90-264V. Frequency: 47-63Hz.
- Output voltage: DC 12V.
- Ability to adjust the output voltage within -9% /+10%.
- Maximum output current: 4.5A.
- Maximum power: 54W.
- Irregularities and noise: 100mV pp.
- AC voltage: 1.2A/115V, 0.65A/230V.
- Efficiency: 82%.
- Leakage current in the input circuit at AC 240V: to 1mA.
- Operating temperature: from -20°C to +60°C.
- Operating humidity: 20%-90%RH.
- Dimensions: 65.5x125.2x100mm.
- Weight: 0.8kg.
| Height | 100mm |
| Length | 120mm |
| Weight | 250 g |
| Width | 50mm |
