The NVR5000-EI2 delivers superior performance and advanced recording technology for IP surveillance systems. Featuring a powerful processor with high-speed data processing and robust decoding capabilities, it ensures smooth video streaming. The device incorporates an intuitive modular GUI NVR NEXT that simplifies workflows and enhances operational efficiency. Equipped with an integrated AI chip and Dahua's deep learning algorithms, it enables precise detection, efficient analytics, and reduced false alarms. Its AcuPick technology provides industry-leading one-click accuracy search. Supporting seamless integration with third-party devices and Video Management Software (VMS), the NVR5000-EI2 offers a versatile and scalable surveillance solution.
| AC input frequency | 50/60 Hz |
| AC input voltage | 100 - 240 V |
| Alarm input channels | 16 |
| Alarm output channels | 6 |
| Audio formats supported | G.711 µ-law/G.711 A-law/G.726/PCM |
| Audio RCA inputs | 1 |
| Audio RCA outputs | 2 |
| Backup function | Yes |
| Browser supported | Chrome, IE, Safari, Edge, Firefox |
| Built-in processor | Yes |
| Compliance certificates | CE |
| Depth | 415.6 mm |
| eSATA ports quantity | 1 |
| Ethernet LAN (RJ-45) ports | 2 |
| Ethernet LAN data rates | 10/100/1000 Mbit/s |
| Face detection | Yes |
| HDD interface | SATA |
| HDMI ports quantity | 2 |
| Height | 76 mm |
| Input bandwidth | 448 Mbit/s |
| Maximum frame rate | 30 fps |
| Maximum resolution | 7680 x 4320 pixels |
| Maximum storage capacity | 26 TB |
| Mobile operating systems supported | Android/iOS |
| Model | NVR5464-EI2 |
| Model name | NVR5464-EI2 |
| Multi-screen | Yes |
| Number of HDDs supported | 4 |
| Operating relative humidity (H-H) | 10 - 93 % |
| Operating system installed | Embedded LINUX |
| Operating temperature (T-T) | -10 - 55 °C |
| Output bandwidth | 448 Mbit/s |
| Package depth | 499 mm |
| Package height | 211 mm |
| Package weight | 6300 g |
| Package width | 529 mm |
| People counting | Yes |
| Power consumption (typical) | 13 W |
| Product colour | Black |
| Product Net Weight | 4.7 kg |
| Rack capacity | 1.5U |
| Rack mounting | Yes |
| RS-232 interface | Yes |
| RS-232 ports | 1 |
| RS-485 ports | 1 |
| Shipping Box Depth | 54.5 cm |
| Shipping Box Height | 44.5 cm |
| Shipping Box Weight | 14.1999998093 kg |
| Shipping Box Width | 52 cm |
| Snapshot | Yes |
| Storage temperature (T-T) | -20 - 60 °C |
| Summary | Dahua Technology WizSense NVR5464-EI2. Video input channels: 64 channels, Maximum resolution: 7680 x 4320 pixels, Audio formats supported: G.711 A-law, G.711 μ-law, G.726, PCM. Maximum storage capacity: 26 TB, HDD interface: SATA. Ethernet LAN data rates: 10,100,1000 Mbit/s, Supported network protocols: HTTP, HTTPS, TCP/IP, IPv4, IPv6, RTSP, UDP, NTP, DHCP, DNS, SMTP, UPnP, FTP, DDNS, SNMP, P2P,.... Rack capacity: 1.5U, Product colour: Black. Power consumption (typical): 13 W, AC input voltage: 100 - 240 V, AC input frequency: 50/60 Hz |
| Supported network protocols | HTTP, HTTPS, TCP/IP, IPv4, IPv6, RTSP, UDP, NTP, DHCP, DNS, SMTP, UPnP, FTP, DDNS, SNMP, P2P, iSCSI, RTMP |
| Unit Box Height | 0.21 |
| Unit Box Length | 0.53 |
| Unit Box Width | 0.495 |
| Unit Calculated Volume | 0.06306 cubm |
| Unit Calculated Weight | 7.1 kg |
| Unit Depth | 53 cm |
| Unit Height | 21 cm |
| Unit Width | 49.5 cm |
| Units per Shipping Box | 2 |
| USB 2.0 ports quantity | 1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 2 |
| Vendor Homepage | https://www.dahuasecurity.com/products/network-products/network-recorders/wizsense-series/nvr-5-ei2-series/nvr5464-ei2 |
| VGA (D-Sub) output ports | 2 |
| Video formats supported | H.264/H.264+/H.265/H.265+/M-JPEG |
| Video input channels | 64 channels |
| Video loss detection | Yes |
| Video motion detection | Yes |
| Weight | 4270 g |
| Wi-Fi | No |
| Width | 440 mm |
