NET VIDEO RECORDER 32CH / NVR4232-4KS3 DAHUA
Product reference:
2-6923172569370
NET VIDEO RECORDER 32CH / NVR4232-4KS3 DAHUA
Product reference:
2-6923172569370
You have 3 products in compare list, please remove someone and try again
- Add to favorites products
- Added to favorites products
- Removed to favorites product
Guarantee
36 month
Delivery from Lithuania in
3 - 5
business days
- Supports Smart H.265+, H.265, Smart H.264+, H.264 and MJPEG decoding formats
- Max. decoding capability: 8 × 1080p@30 fps or 2 × 8 MP@30 fps
- Max. 160/128/60 Mbps incoming/recording/outgoing bandwidth
- Supports IP cameras with a resolution up to 12 MP
- AI by Recorder supports 2-channel SMD Plus
- AI by Camera supports face detection and recognition, perimeter protection, SMD Plus, people counting, stereo analysis and heat map
- Supports EPTZ, and one-click arming and disarming
| Alarm input channels | 4 |
| Backup function | Yes |
| Bit rate | 20000 Kbit/s |
| Built-in processor | Yes |
| Certification | CE, FCC, UL |
| Depth | 283 mm |
| Ethernet LAN (RJ-45) ports | 1 |
| Ethernet LAN data rates | 10/100/1000 Mbit/s |
| HDMI ports quantity | 1 |
| Height | 53 mm |
| Internal SATA ports quantity | 2 |
| Maximum resolution | 1920 x 1080 pixels |
| Maximum storage capacity | 6 TB |
| Mobile operating systems supported | Android |
| Model name | NVR4232-4KS3 |
| Multi-screen | Yes |
| Networking standards | IEEE 802.3af/IEEE 802.3at |
| Number of HDDs supported | 2 |
| Number of motion detection zones | 396 |
| Number of users | 128 user(s) |
| On Screen Display (OSD) | Yes |
| Operating relative humidity (H-H) | 10 - 93 % |
| Operating system installed | Embedded LINUX |
| Operating temperature (T-T) | -10 - 55 °C |
| Output current | 4 A |
| Output voltage | 12 V |
| Package depth | 141 mm |
| Package height | 366 mm |
| Package weight | 2770 g |
| Package width | 433 mm |
| Playback controls | Yes |
| Playback modes | Backup selection,Digital zoom,Forward,Next camera,Pause,Play,Previous camera,Repeat,Shuffle,Stop |
| Power consumption (typical) | 10 W |
| Power over Ethernet (PoE) | No |
| Processor cores | 2 |
| Product colour | Black |
| Product Net Weight | 1.49 kg |
| PTZ control | Yes |
| Rack capacity | 1U |
| Rack mounting | Yes |
| Recording modes | Manual,Schedule |
| Recording time | 60 min |
| RS-232 interface | Yes |
| RS-485 ports | 1 |
| Shipping Box Depth | 43 cm |
| Shipping Box Height | 36.5 cm |
| Shipping Box Weight | 2.8 kg |
| Shipping Box Width | 14 cm |
| Storage temperature (T-T) | -20 - 60 °C |
| Summary | Dahua Technology Lite NVR4232-4KS3. Video input channels: 32 channels, Maximum resolution: 1920 x 1080 pixels, Supported resolutions: 1920 x 1080 1280 x 1024 1280 x 720 1024 x 768. Maximum storage capacity: 6 TB. Ethernet LAN data rates: 10,100,1000 Mbit/s, Networking standards: IEEE 802.3af, IEEE 802.3at, Supported network protocols: HTTP, TCP/IP, IPv4/IPv6, UPnP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPoE,DDNS, FTP, Alarm.... Rack capacity: 1U, Product colour: Black, Certification: CE, FCC, UL. Power consumption (typical): 10 W, Output current: 4 A, Output voltage: 12 V |
| Supported network protocols | HTTP, TCP/IP, IPv4/IPv6, UPnP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPoE,DDNS, FTP, Alarm Server, IP Search (Support Dahua IP camera, DVR, NVS |
| Supported resolutions | 1920 x 1080 1280 x 1024 1280 x 720 1024 x 768 |
| Two-way talk | Yes |
| Unit Box Height | 0.365 |
| Unit Box Length | 0.43 |
| Unit Box Width | 0.14 |
| Unit Calculated Volume | 0.02197 cubm |
| Unit Calculated Weight | 2.8 kg |
| Unit Depth | 43 cm |
| Unit Height | 36.5 cm |
| Unit Width | 14 cm |
| Units per Shipping Box | 1 |
| USB 2.0 ports quantity | 1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 1 |
| Vendor Homepage | https://www.dahuasecurity.com/products/All-Products/Network-Recorders/Lite-Series/NVR4-4KS3-Series/2HDD/NVR4232-4KS3 |
| VGA (D-Sub) output ports | 1 |
| Video formats supported | H.264/H.264+/M-JPEG |
| Video input channels | 32 channels |
| Video loss detection | Yes |
| Video motion detection | Yes |
| Weight | 1490 g |
| Width | 375 mm |
