Guarantee
24 month
Delivery from Lithuania in
3 - 5
business days
Guiding video to top-tier security
NVR brings the synergy of video surveillance and Ajax systems. Experience unparalleled system response speed, ensuring instant access to video archive, even on the go. Wide compatibility makes almost any IP camera integrated with intrusion protection and automation. NVR carries the legacy of a professional security system trusted by millions of users worldwide.
A device with no hidden agenda
All system data is securely stored within the European Union and is in full compliance with European data protection standards.Ajax NVR is NDAA-compliant, with every component sourced from manufacturers trusted and approved by the US government. It is versatile and can be installed in any location. Additionally, Ajax NVR has undergone independent cybersecurity tests to ensure its safety and reliability.
Customizable videowall for simultaneous monitoring
Integrate all your visual data in a streamlined interface. The Videowall tab combines the latest snippets from IP cameras and MotionCam series detectors, offering a comprehensive view of your space. Rearrange tiles according to your preference. The videowall is accessible on both mobile and desktop apps.
Smooth archive search
Effortlessly access the archive by clicking on an event in the notification log, instantly directing you to the precise camera recording at the event's timestamp. Everything is one click away with our advanced features
Rapid and encrypted data transfer
Ajax JetSparrow is the heart and brain of the Ajax video. It is responsible for all the video transmission, storage, and management.
We have developed JetSparrow — our proprietary video transmission technology to deliver an ultra-fast VMS experience. Thanks to this streaming technology, navigating through the local HDD archive feels as smooth as browsing cloud storage. As a result, browsing the archive becomes remarkably efficient, and the live view initiates without any delay.
Built-in motion detection
Optimize your video archive by setting up the pixel movement detection feature. Define specific zones to ensure recordings are triggered only when movement occurs in the selected area. This conserves HDD space and streamlines archive navigation.
| AC įėjimo dažnis | 50/60 Hz |
| AC įėjimo įtampa | 110 - 240 V |
| Aukštis | 193 mm |
| Bruto svoris | 0.883 kg |
| Darbo santykinės drėgmės diapazonas | 0 - 75 % |
| Darbo temperatūros diapazonas (TT) | 0 - 40 °C |
| Didžiausia atminties apimtis | 16 TB |
| Eterneto LAN duomenų perdavimo norma | 10/100 Mbit/ai |
| Ethernet LAN (RJ-45) portų kiekis | 1 |
| Galios suvartojimas (maks.) | 24 W |
| Greito diegimo vadovas | Taip |
| Ilgis | 47 mm |
| Išėjimo srovė | 0.6 A |
| Kietojo disko dydis | 3.5 " |
| Kietojo disko sąsaja | SATA |
| LED indikatoriai | Taip |
| Model name | NVR DC (16-ch) |
| Modelio suderinamumas | Ajax |
| Neto svoris | 0.8 kg |
| Palaikomi audio formatai | RTSP |
| Palaikomi vaizdo formatai | H.264/H.265 |
| Palaikomų kietūjų diskų skaičius | 1 |
| Plotis | 193 mm |
| Pridėti kabeliai | Energija/LAN (RJ-45) |
| Produkto spalva | Juoda |
| Shipping Box Depth | 25 cm |
| Shipping Box Height | 5 cm |
| Shipping Box Weight | 0.883 kg |
| Shipping Box Width | 21 cm |
| Suderinami produktai | Hub Hub Plus Hub 2 (2G) Hub 2 (4G) Hub 2 Plus Hub Hybrid (2G) Hub Hybrid (4G) |
| Summary | Ajax NVR DC (16-ch). Video input channels: 16 channels, Audio formats supported: RTSP, Video formats supported: H.264, H.265. Maximum storage capacity: 16 TB, HDD interface: SATA, HDD size: 3.5". Ethernet LAN data rates: 10,100 Mbit/s. Brand compatibility: Ajax, Product colour: Black, Compatible products: Hub Hub Plus Hub 2 (2G) Hub 2 (4G) Hub 2 Plus Hub Hybrid (2G) Hub Hybrid (4G). Power consumption (max): 24 W, AC input voltage: 110 - 240 V, AC input frequency: 50/60 Hz |
| Svoris | 700 g |
| Unit Box Height | 0.05 |
| Unit Box Length | 0.25 |
| Unit Box Width | 0.21 |
| Unit Brutto Volume | 0.002625 cubm |
| Vaizdo judesio detekcija | Taip |
| Vaizdo signalo įvesties kanalai | 16 kanalai |
| Vendor Homepage | https://ajax.systems/products/specs/nvr-16-ch-dc/ |
| Vieneto aukštis | 5 cm |
| Vieneto gylis | 25 cm |
| Vieneto plotis | 21 cm |
| Vienetų skaičius vienoje siuntimo dėžėje | 1 |
