This top-of-the-line camera offers remote pan-tilt-roll-zoom functionality so it's quick and easy to adjust and later readjust the camera view. Plus, it offers support for advanced analytics based on deep learning on the edge.

Remotely adjust the field of view
This advanced camera offers easy installation, maintenance, and operation. Thanks to remote pan-tilt-roll-zoom (PTRZ) functionality you can quickly adjust and later readjust the camera view remotely over the network saving time and effort. Remote PTRZ also gives you the flexibility and possibility to respond to future changes- without the need to dispatch a technician ensuring less disruption and downtime.

Outstanding image quality
AXIS Q3628-VE offers outstanding image quality and forensic details in 8 MP resolution—even in low light. Plus, Lightfinder 2.0 and Forensic WDR ensure true colors and great detail in challenging light or near darkness. Built on the latest Axis system-on-chip (SoC), it features a deep learning processing unit for improved processing capabilities. This allows you to collect and analyze even more data than before—on the edge. It also delivers valuable metadata facilitating fast, easy, and efficient forensic search capabilities. Furthermore, AXIS Object Analytics makes it possible to detect and classify moving objects.

Robust and ready for tough environments
This robust, IK10-rated, vandal-resistant camera is ideal for tough environments and rough weather. Electronic image stabilization ensures smooth video in situations where the camera is subject to vibrations. Plus, it includes sensors for shock-, vibration-, and case-open detection. And a conduit connection ensures flexible cable management. Furthermore, built-in cybersecurity features help prevent unauthorized access and safeguard your system. For instance, Axis Edge Vault protects your Axis device ID and simplifies authorization of Axis products on your network. Plus, it offers secure key storage with FIPS 140-2 level 2 certification.

  • Outstanding image quality in 8 MP
  • Remote adjustment of the camera angle
  • Analytics with deep learning
  • Electronic image stabilization
  • Axis Edge Vault

Alert notification type E-mail
Audio detection Yes
Audio formats supported AAC-LC/ADPCM/G.711/G.726/LPCM/OPUS
Audio system 2-way
Audio system full duplex Yes
Bluetooth No
Built-in HDD No
Camera pan control Yes
Camera shutter speed 1/66500 - 2 s
Camera tilt control Yes
Card reader integrated Yes
Compatible memory cards MicroSD (TransFlash)/MicroSDHC/MicroSDXC/SD
Compliance certificates CE/KC/REACH/RoHS/UKCA
Connectivity technology Wired
Day/night mode Yes
DC output voltage 10,28
DC-in jack Yes
Digest authentication Yes
Doesn't contain BFR/PVC
Ethernet LAN Yes
Ethernet LAN (RJ-45) ports 1
Flash memory 8192 MB
Focal length range 6.2-12.9 mm
Form factor Dome
Frame rate 30 fps
Housing material Aluminium/Polycarbonate (PC)
HTTPS encryption Yes
IK code IK10
Image quality adjustment Brightness/Contrast/Saturation/Sharpness
Image stabilizer Yes
Infrared (IR) cut-off filter Yes
Internal memory 2048 MB
International Protection (IP) code IP66
IP address filtering Yes
Languages support Czech/Dutch/English/Finnish/French/German/Italian/Japanese/Korean/Polish/Portuguese/Russian/Simplified Chinese/Spanish/Swedish/Thai/Traditional Chinese/Turkish/Vietnamese
Lens viewing angle, horizontal 103 - 48 °
Lens viewing angle, vertical 56.4 - 27.4 °
Manual Yes
Maximum aperture number 2.9
Maximum resolution 3840 x 2160 pixels
Microphone in Yes
Minimum aperture number 1.6
Minimum illumination 0.07 lx
Model Q3628-VE
Mounting brackets included Yes
Mounting type Wall/Pole
Networking standards IEEE 802.3at
Night vision Yes
Number of cameras 1
Number of languages 19
Number of sensors 1
Optical sensor size 1/1.2 "
Pan range 0 - 190 °
Password protection Yes
Pixel counter Yes
Placement supported Outdoor
Power consumption (max) 25 W
Power consumption (typical) 8 W
Power source type DC,PoE
Preset points Yes
Privacy masking Yes
Processor model ARTPEC-8
Product colour White
Progressive scan Yes
PTZ control Yes
PTZ modes Digital PTZ
Quality of Service (QoS) support Yes
Sample rate 48 kHz
Screws included Yes
Sensor type CMOS
Signal-to-Noise Ratio (SNR) (panoramic camera) 55 dB
Summary Axis 02617-001. Type: IP security camera, Placement supported: Outdoor, Connectivity technology: Wired. Mounting type: Wall/Pole, Product colour: White, Form factor: Dome. Minimum illumination: 0.07 lx, Lens viewing angle, horizontal: 103 - 48, Lens viewing angle, vertical: 56.4 - 27.4°. Sensor type: CMOS, Optical sensor size: 25.4 / 1.2 mm (1 / 1.2"). Signal-to-Noise Ratio (SNR) (panoramic camera): 55 dB
Supported graphics resolutions 1280 x 800/160 x 120/160 x 90/2880 x 2160/3840 x 2160
Supported network protocols IPv4, IPv6 USGv6, ICMPv4/ICMPv6, HTTP, HTTPSb , HTTP/2, TLSb , QoS Layer 3 DiffServ, FTP, SFTP, CIFS/SMB, SMTP, mDNS (Bonjour), UPnP® , SNMP v1/v2c/v3 (MIB-II), DNS/DNSv6, DDNS, NTP, NTS, RTSP, RTP, SRTP/RTSPS, TCP, UDP, IGMPv1/v2/v3, RTCP, ICMP, DHCPv4/v
Sustainability compliance Yes
Terminal block port Yes
Text caption overlay Yes
Tilt angle range -8 - 75 °
Total megapixels 8 MP
Type IP security camera
Unit Box Height 0.195
Unit Box Length 0.27
Unit Box Width 0.225
Unit Calculated Volume 0.01185 cubm
Unit Calculated Weight 2.82 kg
Units per Shipping Box 1
Vendor Homepage https://www.axis.com/products/axis-q3628-ve
Video compression formats H.264/H.265/M-JPEG
Video motion detection Yes
Video streaming Yes
Voice codecs AGC
Wi-Fi No
Wide Dynamic Range (WDR) Yes
