6MP WizColor Fixed-focal Dome WizMind Network Camera
Launched by Dahua Technology, Dahua WizMind is a full portfolio of solutions composed of project-oriented products including IPC, IVSS,NVR, PTZ, XVR, Thermal and software platform which adopts industry-leading deep learning algorithms. Focusing on customer's requirements, WizMind provides precise, reliable and comprehensive AI solutions for verticals.

Series Overview
With its deep learning algorithms, the WizMind 5 Series camera offers advanced analytical capabilities for both audio and video. It integrates intelligent features such as video metadata, AcuPick, face detection, perimeter protection, and people counting. Powered by the Xinghan Large-Scale AI Models-Vision, the camera outstandingly delivers on its object detection, recognition, and scene adaptation functions. Equipped with AI-ISP imaging technology, it offers excellent night vision performance. The series is designed for durability, being dust-proof, waterproof, and vandal-proof, in compliance with IP67 and IK10 standards, though support for these certifications may vary across models.

Xinghan Large-Scale AI Models-Vision
Xinghan Large-Scale AI Models-Vision seamlessly expands the storage and operational capacity of algorithmic models through the powerful integration of edge AI model algorithms and NPU computing power. Engineered with a lightweight transformer architecture and enhanced by model distillation and quantization techniques, it optimizes the computing power consumption of ViT operators. This enables the system to collaborate on multiple tasks simultaneously through joint inference between small and large models optimized for edge devices.

Self-Learning
Empowered by deep learning technology, the device recognizes different types of targets and their statuses through learning and analyzing target features to detect targets and filter out false alarms.

WizColor Technology
Dahua WizColor Technology seamlessly combines with the powerful AIISP, large pixel size sensor and large aperture in cameras. This unique integration enables cameras to effortlessly capture high-quality images with vibrant colors during nighttime scenarios, ensuring fine details are preserved and minimizing motion blur. Unlike traditional self-illuminating cameras, Dahua WizColor Technology maximizes the utilization of weak light sources, such as moonlight and city lights reflected in the sky, delivering captivating full-color images of the entire scene. It also ensures that monitoring distances are not compromised at night due to limited illumination ranges, facilitating full-color image capture even over long distances.

AcuPick
This industry-leading search technology effectively utilizes both front-end and back-end intelligence to help with searching through massive video data to quickly and conveniently locate targets with greater precision.

Protection (IP67, IK10, Wide Voltage)
P67: The camera passes a series of strict test on dust and soak. It has dust-proof function, and the enclosure can work normally after soaking in 1 m deep water for 30 minutes. IK10: The enclosure can stand the punch more than 5 times from a 5 kg hammer falling from a height of 40 cm (Impact energy is 20J). Wide voltage: The camera allows ±30% (for some power supplies) input voltage tolerance (wide voltage range), and it is widely applied to outdoor environment with instable voltage.

  • 1/1.8" CMOS image sensor, low luminance, and high definition image
  • Outputs max. 6 MP (3072 × 2048) @25/30 fps
  • Built-in multi-core light, the max. IR distance is 60 m and the max. warm light distance is 50 m
  • ROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding after filter, flexible coding, applicable to various bandwidth and storage environments
  • Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes
  • Powered by the Xinghan Large-Scale AI Models-Vision, the camera outstandingly delivers on its object detection, recognition, and scene adaptation functions
  • With deep learning algorithm, it supports: AcuPick, video metadata, IVS, face detection, and people counting, etc
  • Alarm: 1 in, 1 out; audio: 1 in, 1 out; RS-485; supports max. 1 TB Micro SD card; built-in dual Mic; 1-ch speaker; support two-way talk
  • 12 VDC/PoE power supply; ePoE; 12 VDC power output, and max. current 165mA, easy for installation
  • IP67 and IK10 protection

Apsaugos ypatybės Atsparus korozijai/Atsparus vandeniui
Aptikimo atstumas 124 m
Aptikties atstumas 85.6 m
Apšvietimo LED diodų skaičius 4
Atitikties sertifikatai CE/Elektromagnetinis suderinamumas (EMS)/Žemos įtampos direktyva (LVD)
Atminties kortelė įtraukta MicroSD
Atpažinimo atstumas 17.1 m
Audio detekcija Taip
Aukštis 105 mm
Automatinis panoraminio vaizdo režimas Taip
Automatinis sekimas Taip
Baltos spalvos balansas Automatinis
Bluetooth Ne
Bruto svoris 0.99 kg
Darbo santykinės drėgmės diapazonas 0 - 95 %
Darbo temperatūros diapazonas (TT) -40 - 60 °C
DC išeigos įtampa 12
Dienos / nakties režimas Taip
Ethernet LAN (RJ-45) portų kiekis 1
Ethernet LAN jungtis Taip
Fiksuotas fokusavimas Taip
Fiksuotas židinio nuotolis 3.6 mm
Foninio apšvietimo kompensavimas Taip
Forma Sferinis
Fotoaparatų skaičius 2
Galios suvartojimas (maitinimas per Eternetą (PoE)) 23.9 W
Galios suvartojimas (maks.) 21.7 W
Identifikavimo atstumas 86 m
IK kodas IK10
Ilgis 126 mm
Infraraudonųjų spindulių (IR) atjungimo filtras Taip
Integruotas kietasis diskas Taip
Integruotas SSD diskas Taip
Iš viso megapikselių 4 MP
Išplėstinis dinaminis diapazonas (WDR) Taip
Judesių jutiklis Taip
Jutiklio tipas CMOS
Kadrų sparta 30 fps
Kameros išlaikymo tipas Elektroninis
Kameros pakėlimo valdymas Taip
Kameros panoramavimo valdymas Taip
Kameros užrakto greitis 1/3 - 1/100000 s
Korpuso medžiaga Metalas
LED tipas Infraraudonieji / balti
Lęšio montavimo sąsaja M16
Maitinimo šaltinio tipas DC
Maksimali rezoliucija 3072 x 2048 pikseliai
Maksimalus apertūros skaičius 1
Maksimalus veikimo nuotolis 124 m
Mažiausias fokusavimo atstumas 3.2 m
Mikrofonų kiekis 1
Montavimo tipas Lubos
Naktinio matymo atstumas 40 m
Naktinis matymas Taip
Neto svoris 0.73 kg
Objektyvo vaizdo kampas, horizontalus 93 °
Objektyvo vaizdo kampas, vertikalus 50 °
Objektyvo vaizdo kampas, įstrižainė 111 °
Optinio sensoriaus dydis 1/1.8 "
Paketo svoris 940 g
Palaikomi tinklo protokolai IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; SAMBA; PPPoE; SNMP; P2P
Palaikomi vaizdo režimai 1080p/720p
Palaikomos grafikos rezoliucijos 1280 x 720 (HD 720)/1280 x 960/1920 x 1080 (HD 1080)/2048 x 1536 (QXGA)/2304 x 1296/2560 x 1440/2688 x 1520/3072 x 2048/352 x 240/352 x 288/640 x 480 (VGA)/704 x 480/704 x 576
Plotis 126 mm
Posvyrio kampo intervalas 0 - 75 °
Produkto spalva Juoda
Progresyvus nuskaitymas Taip
PTZ kontrolė Taip
RAM talpa 2000 MB
ROM talpa 4000 MB
Ryšio technologija Vielinis
Sandėliavimo santykinis drėgmės diapazonas 0 - 95 %
Sandėliavimo temperatūros norma (T-T) -40 - 60 °C
Sertifikavimas CE-LVD: EN62368-1;
CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU;
Shipping Box Depth 16 cm
Shipping Box Height 13.5 cm
Shipping Box Weight 0.99 kg
Shipping Box Width 16 cm
Signalo ir triukšmo santykis (SNR) 56 dB
Signalo įvestis / išvestis Taip
Stebėjimo atstumas 34.3 m
Sukimosi kampas 360 °
Summary Dahua Technology WizMind IPC-HDBW5659R1-ASE-PV-PRO. Type: CCTV security camera, Placement supported: Indoor & outdoor, Connectivity technology: Wired. Mounting type: Ceiling, Product colour: Black, Form factor: Spherical. Angle of rotation: 360°, Lens viewing angle, horizontal: 93°, Lens viewing angle, vertical: 50°. Sensor type: CMOS, Optical sensor size: 25.4 / 1.8 mm (1 / 1.8"). Detect distance: 85.6 m, Observe distance: 34.3 m, Recognize distance: 17.1 m
Svoris 730 g
Talpinimas palaikomas Vidaus ir lauko
Tarptautinės apsaugos (IP) kodas IP67
Tipas CCTV stebėjimo kamera
Triukšmo mažinimas Taip
Triukšmo sumažinimo technologija 3D triukšmo mažinimas
Unit Box Height 0.135
Unit Box Length 0.16
Unit Box Width 0.16
Unit Brutto Volume 0.003456 cubm
Vaizdo kokybės koregavimas Gain/Veidrodis
Valdymo sustiprinimo tipas Automatinis
Veidrodis Taip
Vendor Homepage https://www.dahuasecurity.com/ceen/products/All-Products/Network-Cameras/WizMind-5-Series/Pro/6MP/IPC-HDBW5659R1-ASE-PV-PRO
Video suspaudimo formatai H.264/H.264B/H.264H/H.265/M-JPEG
Vieneto aukštis 13.5 cm
Vieneto gylis 16 cm
Vieneto plotis 16 cm
Vienetų skaičius vienoje siuntimo dėžėje 1
Viso diapozonas 0 - 355 °
Įmontuota lemputė Taip
Įmontuotas mikrofonas Taip
Įmontuoti garsiakalbiai Taip
Šviesos efekto kompensavimas (HLC) Taip
Žmonių skaičiavimo funkcija Taip
"Smart IR" įtaisas Taip
"Wi-Fi" Ne
