NET CAMERA 5MP IR DOME / HDBW3541R-ZAS-27135-S2 DAHUA
Product reference: 2-6923172542267
  • −63%
NET CAMERA 5MP IR DOME / HDBW3541R-ZAS-27135-S2 DAHUA
NET CAMERA 5MP IR DOME / HDBW3541R-ZAS-27135-S2 DAHUA
NET CAMERA 5MP IR DOME / HDBW3541R-ZAS-27135-S2 DAHUA

NET CAMERA 5MP IR DOME / HDBW3541R-ZAS-27135-S2 DAHUA

Product reference: 2-6923172542267
You have 3 products in compare list, please remove someone and try again
  • Add to favorites products
  • Added to favorites products
  • Removed to favorites product
Add to compare
151,88 €
410,49 €
Product in warehouse

Guarantee
36 month

Delivery from Lithuania in
3 - 5
business days

Your message has been successfully sent!
Fill in the required fields*

  • 5MP 1/2.7" CMOS image sensor, excellent low luminance performance and high definition of images
  • Outputs max. 5 MP (2960 × 1668) @20 fps and supports 4MP (2688 × 1520) @25/30 fps
  • H.265 codec, high compression rate, ultra-low bit rate
  • Built-in IR LED, max. IR distance: 40 m
  • ROI, SMART H.264 +/H.265+, AI H.264/H.265, flexible coding, applicable to various bandwidth and storage environments
  • Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes
  • Intelligent detection: Intrusion, tripwire (support the classification and accurate detection of vehicle and human)
  • Abnormality detection: Motion detection, privacy masking, scene changing, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection
  • Alarm: 1 in, 1 out (Only - ZAS supports); audio: 1 in, 1 out (Only - ZAS supports); max. 256 G Micro SD card; built-in Mic
  • 12 VDC/PoE power supply, easy for installation
  • IP67, IK10 protection
  • SMD 4.0, AI SSA

Adjustment shutter speed Auto/Manual
Alarm input channels 1
Alarm output channels 1
Angle of rotation 355 °
Audio input channels 1.0 channels
Audio output channels 1.0 channels
Back Light Compensation (BLC) Yes
Behavior analysis Intrusion detection
Bit rate H.264: 3 kbps-8192 kbps H.265: 3 kbps-8192 kbps
Bit rate control Constant Bit Rate (CBR)/Variable Bit Rate (VBR)
Bluetooth No
Built-in HDD No
Built-in microphone Yes
Camera shutter speed 1/3 - 1/100000 s
Camera shutter type Electronic
Card reader integrated Yes
Closest focusing distance 0.8 m
Compatible memory cards MicroSD (TransFlash)
Connectivity technology Wired
DC output voltage 12
Detect distance (tele) 210 m
Detect distance (wide) 64 m
Diameter 94 mm
Dynamic range 120 dB
Ethernet interface type Fast Ethernet
Ethernet LAN Yes
Ethernet LAN (RJ-45) ports 1
Focal length range 2.7 - 13.5 mm
Focus Motorized
Fog proof Yes
Form factor Dome
Frame rate 30 fps
Gain control type Auto
Height 122 mm
Highlight Compensation (HLC) Yes
Housing material Metal
Identify distance (tele) 21 m
Identify distance (wide) 6.4 m
IK code IK10
Image stabilizer Yes
Internal memory 512 MB
International Protection (IP) code IP67
LED type IR
Lens viewing angle, diagonal 138 - 36 °
Lens viewing angle, horizontal 114 - 32 °
Lens viewing angle, vertical 58 - 17 °
Maximum memory card size 256 GB
Maximum resolution 2960 x 1668 pixels
Minimum aperture number 1.5
Mirror Yes
Mobile operating systems supported Android/iOS
Model IPC-HDBW3541R-ZAS-27135-S2
Mounting type Ceiling/wall
Networking standards IEEE 802.3af
Night vision Yes
Night vision distance 40 m
Noise reduction Yes
Noise reduction technology 3D noise reduction
Number of cameras 1
Number of illumination LEDs 3
Number of lenses 1
Number of Privacy masking areas 4
Number of sensors 1
Number of users 20 user(s)
Observe distance (tele) 84 m
Observe distance (wide) 25.6 m
Operating relative humidity (H-H) 0 - 95 %
Operating temperature (T-T) -30 - 60 °C
Optical sensor size 1/2.7 "
Package weight 986 g
Pan range 0 - 355 °
Placement supported Outdoor
Power consumption (max) 9.2 W
Power consumption (Power over Ethernet (PoE)) 4.9 W
Power consumption (typical) 4 W
Power source type DC,PoE
Privacy masking Yes
Product colour Black/White
Progressive scan Yes
Quality of Service (QoS) support Yes
Recognize distance (tele) 42 m
Recognize distance (wide) 12.8 m
Region of Interest (ROI) encoding Yes
ROM capacity 128 MB
Sensor type CMOS
Signal-to-Noise Ratio (SNR) 56 dB
Smart IR Yes
Storage temperature (T-T) -40 - 60 °C
Streaming method Multicast
Summary Dahua Technology WizSense HDBW3541R-ZAS-27135-S2. Type: IP security camera, Placement supported: Outdoor, Connectivity technology: Wired. Mounting type: Ceiling/wall, Product colour: Black, White, Form factor: Dome. Angle of rotation: 355°, Lens viewing angle, horizontal: 114 - 32°, Lens viewing angle, vertical: 58 - 17°. Sensor type: CMOS, Optical sensor size: 25.4 / 2.7 mm (1 / 2.7"). Focal length range: 2.7 - 13.5 mm, Focus: Motorized, Detect distance (wide): 64 m
Supported graphics resolutions 1280 x 720 (HD 720)/1280 x 960/1920 x 1080 (HD 1080)/2048 x 1536 (QXGA)/2304 x 1296/2560 x 1440/2688 x 1520/2880 x 1620/352 x 240/352 x 288/640 x 480 (VGA)/704 x 480/704 x 576
Supported network protocols IPv4; IPv6; HTTP;TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP;
Tilt angle range 0 - 80 °
Total megapixels 5 MP
Type IP security camera
Unit Box Height 0.165
Unit Box Length 0.19
Unit Box Width 0.19
Unit Calculated Volume 0.006868 cubm
Unit Calculated Weight 0.867 kg
Units per Shipping Box 30
Vendor Homepage https://www.dahuasecurity.com/products/All-Products/Network-Cameras/WizSense-Series/3-Series/5MP/IPC-HDBW3541R-ZAS-S2=S2
Video compression formats H.264/H.264B/H.264H/H.265/M-JPEG
Voice codecs G.711a/G.711Mu/G.723/G.726/PCM
Web browser Yes
Web-based management Yes
Weight 713 g
White balance Auto/Manual/Natural/Outdoor/Regional custom/Street lamp
Wi-Fi No
