NET CAMERA 5MP BULLET / HFW3549T1-ZASPV27135S5-B DAHUA
Product reference: 2-6939554994265

NET CAMERA 5MP BULLET / HFW3549T1-ZASPV27135S5-B DAHUA

Product reference: 2-6939554994265
You have 3 products in compare list, please remove someone and try again
  • Add to favorites products
  • Added to favorites products
  • Removed to favorites product
Add to compare
575,36 €
Product in warehouse

Guarantee
36 month

Delivery from Lithuania in
3 - 5
business days

Your message has been successfully sent!
Fill in the required fields*

Launched by Dahua Technology, WizSense is a series of AI products and solutions that adopt independent AI chip and deep learning algorithm. It focuses on human and vehicle with high accuracy, enabling users to fast act on defined targets. Based on Dahua's advanced technologies, WizSense provides intelligent, simple and inclusive products and solutions.

Siren And Light Active Deterrence
Dahua siren and light active deterrence network camera supports the light alarm and voice alarm when perimeter event occurs, to realize the deterrence and effective intervention. The camera is built in multiple voices for selection, and supports customized voice importing.

Smart Dual Light
Dahua Smart Dual Light technology adopts smart algorithm to detect targets. Usually, the IR illuminator is on at night; when the target appears in the monitoring area, the warm light is on, and the camera records the full-color video and information of key events. That is, the camera links snapshot and video with full-color image. When the target is out of the monitoring area, the warm light is off and the IR illuminator is on, which reduces light pollution efficiently.

SMD 4.0
Dahua Smart Motion Detection technology works with intelligent algorithms to classify targets that trigger motion detection alarms. It filters out objects that are not targets, such as small and large animals, to avoid triggering false alarms. With an AI NVR, Quick Pick technology becomes available, allowing you to easily search for and pick out human and vehicle targets from SMD event videos, prioritizing the highest matches.

One-tap Disarming
Dahua One-tap Disarming function, which is convenient and easy for operation, is the switch for event linkage. Customers can close and recover event linkage through mobile App, which meets multi-scenarios needs.

Cyber Security
Dahua network cameras employ a series of security technologies, including security authentication and authorization, access control protocols, trusted protection, encrypted transmission and encrypted storage. These technologies improve the camera's defense against external cyber threats and prevent malicious programs from compromising the device.

Protection (IP67, wide voltage)
IP67: The camera passes a series of strict test on dust and soak. It has dust-proof function, and the enclosure can works normal after soaking in 1 m deep water for 30 minutes. Wide voltage: The camera allows ±30% input voltage tolerance (wide voltage range), and it is widely applied to outdoor environment with instable voltage.

  • 5-MP 1/2.7" CMOS image sensor, low luminance, and high definition image
  • Outputs max. 5 MP (2960 × 1668) @20 fps and supports 4 MP (2688 × 1520) @25/30 fps
  • H.265 codec, high compression rate, ultra-low bit rate
  • Built-in warm light and IR LED; the max. IR illumination distance is 50 m and warm light distance is 40 m
  • ROI, SMART H.264+/H.265+, AI H.264/H.265, flexible coding, applicable to various bandwidth and storage environments
  • Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes
  • Intelligent monitoring: Intrusion, tripwire (the two function support the classification and accurate detection of vehicle and human)
  • Abnormality detection: Motion detection, privacy masking, scene changing, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection
  • Alarm: 1 in, 1 out; audio: 1 in, 1 out; supports max. 256 G Micro SD card; built-in dual MICs; 1-ch speaker; support two-way talk
  • 12 VDC/PoE power supply
  • IP67 protection
  • Sound and light alarm (red and blue lights)
  • SMD 4.0
  • One-tap arming/disarming through alarm input

Aptikties atstumas ("tele") 186.6 m
Aptikties atstumas ("wide") 65.2 m
Audio detekcija Taip
Audio sistema 2 krypčių
Aukštis 84.7 mm
Baltos spalvos balansas Automatinis/Lauke/Lempa/Rankinis
Bluetooth Ne
Bruto svoris 1.38 kg
Darbo temperatūros diapazonas (TT) -30 - 60 °C
DC išeigos įtampa 12
Dienos / nakties režimas Taip
Energijos suvartojimas 3.3 W
Eterneto sąsajos tipas Gigabitinis eternetas/Greitas eternetas
Ethernet LAN (RJ-45) portų kiekis 1
Ethernet LAN jungtis Taip
Forma Kulka (forma)
Galios suvartojimas (maitinimas per Eternetą (PoE)) 8.7 W
Galios suvartojimas (maks.) 7.4 W
Garso išvesties kanalai 2.0 kanalai
Garso įvesties kanalai 2.0 kanalai
Ilgis 288.4 mm
Integruotas kietasis diskas Ne
Integruotas kortelių skaitytuvas Taip
Iš viso megapikselių 5 MP
Išplėstinis dinaminis diapazonas (WDR) Taip
Jutiklio tipas CMOS
Jutiklių skaičius 1
Kameros pakėlimo valdymas Ne
Kameros panoramavimo valdymas Ne
Kameros užrakto greitis 1/3 - 1/100000 s
Korpuso medžiaga Metalas/Plastikas
Lęšių skaičius 1
Maitinimo šaltinio tipas DC,PoE
Maksimali rezoliucija 2592 x 1944 pikseliai
Maksimalus atminties kortelės dydis 256 GB
Minimalus apšviestumas 0.0003 lx
Model HFW3549T1-ZASPV27135S5-B
Montavimo tipas Lubos / siena
Naktinio matymo atstumas 30 m
Naktinis matymas Taip
Neto svoris 1.05 kg
Objektyvo vaizdo kampas, horizontalus 113 - 36 °
Objektyvo vaizdo kampas, vertikalus 57 - 20 °
Objektyvo vaizdo kampas, įstrižainė 137 - 40 °
Optinio sensoriaus dydis 1/2.7 "
Paketo svoris 1350 g
Palaikomi audio formatai G.711/G.726
Palaikomos grafikos rezoliucijos 1280 x 720 (HD 720)/1280 x 960/1920 x 1080 (HD 1080)/2592 x 1944/2688 x 1520/640 x 480 (VGA)
Palaikomos mobiliosios operacinės sistemos Android/iOS
Plotis 94.4 mm
Posvyrio kampo intervalas 0 - 90 °
Privatumo maskavimas Taip
Privatumo maskavimo sričių skaičius 4
Produkto spalva Juoda
Progresyvus nuskaitymas Taip
Reguliuojamas užrakto greitis Automatinis / rankinis
ROM talpa 128 MB
Ryšio technologija Vielinis
Sandėliavimo temperatūros norma (T-T) -30 - 60 °C
Sertifikavimas CE-LVD: EN 62368-1; CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU; FCC: 47 CFR FCC Part 15, Subpart B; UL/CUL:UL62368-1 & CAN/CSA C22.2 No. 62368-1-14
Shipping Box Depth 57.5 cm
Shipping Box Height 32.8 cm
Shipping Box Weight 11 kg
Shipping Box Width 35.8 cm
Signalo išvesties kanalai 2
Signalo įvesties kanalai 2
Stebėjimo atstumas ("tele") 37.3 m
Stebėjimo atstumas ("wide") 26.1 m
Suderinamos atminties kortelės MicroSD (TransFlash)
Summary Dahua Technology WizSense IPC-HFW3549T1-ZAS-PV. Type: IP security camera, Placement supported: Indoor & outdoor, Connectivity technology: Wired. Mounting type: Ceiling/wall, Product colour: Black, Form factor: Bullet. Minimum illumination: 0.0003 lx, Lens viewing angle, horizontal: 113 - 36°, Lens viewing angle, vertical: 57 - 20°. Sensor type: CMOS, Optical sensor size: 25.4 / 2.7 mm (1 / 2.7"). Focal length range: 2.7 - 13.5 mm, Detect distance (wide): 65.2 m, Detect distance (tele): 186.6 m
Svoris 1050 g
Talpinimas palaikomas Vidaus ir lauko
Tarptautinės apsaugos (IP) kodas IP67
Tipas IP apsaugos kamera
Triukšmo mažinimas Taip
Triukšmo sumažinimo technologija 3D triukšmo mažinimas
Unit Box Height 0.135
Unit Box Length 0.34
Unit Box Width 0.145
Unit Brutto Volume 0.00844 cubm
Veidrodis Taip
Vendor Homepage https://www.dahuasecurity.com/products/All-Products/Network-Cameras/WizSense-Series/3-Series/TiOC/IPC-HFW3549T1-ZAS-PV=S5
Video suspaudimo formatai H.264/H.264B/H.264H/H.265
Vidinė atmintis 512 MB
Vieneto aukštis 13.5 cm
Vieneto gylis 34 cm
Vieneto plotis 14.5 cm
Vienetų skaičius vienoje siuntimo dėžėje 8
Viso diapozonas 0 - 360 °
Web pagrįstas valdymas Taip
Įmontuotas mikrofonas Taip
Įmontuoti garsiakalbiai Taip
Židinio nuotolis 2.7 - 13.5 mm
Žiniatinklio naršyklė Taip
"Wi-Fi" Ne
