Hikvision speed dome camera DS-2DY9240IX-A(T5)

Product reference: 26-6931847123642

Hikvision speed dome camera DS-2DY9240IX-A(T5)

Product reference: 26-6931847123642

You have 3 products in compare list, please remove someone and try again

Add to compare

2 909,10 €

Last product in warehouse

Guarantee
24 month

Delivery from Lithuania in
2 - 4
business days

Your message has been successfully sent!

Fill in the required fields*

Camera
Sensor 1/1.8＂ progressive scan CMOS
Max resolution 1920 × 1080
Min. lighting 0 Lux with IR||B/W: 0.001Lux@(F1.2，AGC ON)||color: 0.005Lux @ (F1.2，AGC ON)
Shutter speed 1/1s ~ 1/30,000s
Day Night ICR
Zooming 40 × optical, 16 × digital

Lens
FOV 6.0 mm to 240 mm, 40 × optical
FOV
Horizontal field of view: 59.0 to 1.8° (wide-tele)
Vertical field of view: 33.7° to 1.1° (wide-tele),
Diagonal field of view: 63.4° to 2.1° (wide-tele)
Focusing semi-auto||manual||auto
Aperture F1.2
Zoom speed approx.5.6s

PTZ
Movement Range (Pan) 360°
Movement Range (Tilt) +40° to -90°
Pan speed pan speed: configurable from 0.1° to 120°/s; preset speed: 120°/s
Tilt speed tilt speed: configurable from 0.1° to 50°/s, preset speed 50°/s
Proportional Pan yes
Pre-saved settings 300
Stopping saved settings yes
Patrolling 8 patrols
Scanning saved modes 4 pattern scans
Park Action preset, pattern scan, patrol scan, auto scan, tilt scan, random scan, frame scan, panorama scan
3D position yes
PTZ status display yes
Task schedule preset, pattern scan, patrol scan, auto scan, tilt scan, random scan, frame scan, panorama scan, dome reboot, dome adjust, aux output
Power-off memory yes

Main stream
50Hz: 25fps (1920 × 1080, 1280 × 960, 1280 × 720)
60Hz: 30fps (1920×1080, 1280×960, 1280×720)
Secondary flow
50Hz: 25fps (704 × 576, 640 × 480, 352 × 288)
60Hz: 30fps (704 × 480, 640 × 480, 352 × 240)
Third stream
50Hz: 25fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 576, 640 × 480, 352 × 288)
60Hz: 30fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 480, 640 × 480, 352 × 240)
Image compression H.265, H.264, MJPEG
H.264 type baseline profile, main profile, high profile
H.265 type main profile
Scalable Video Coding (SVC) yes
Region of Interest (ROI) 8 fixed regions for each stream

Internet
Protocols IPv4/IPv6, HTTP, HTTPS, 802.1x, Qos, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP/IP, UDP, IGMP, ICMP, DHCP, PPPoE, Bonjour
Live video viewing Up to 20 channels
API Open-ended API, ISAPI, Hikvision SDK, Third-party management platform, Hik-Connect, ISUP, Open Network Video Interface
User/Host Up to 32 users. 3 levels: Administrator, Operator and User
Security Authenticated username and password, MAC address binding, HTTPS encryption, 802.1X authenticated access, IP address filter
Customer iVMS-4200, iVMS-4500, iVMS-5200, Hik-Connect, HikCentral Pro
Browser IE11, Chrome 57.0+, Firefox 52.0+, Safari 11+

Wide Dynamic Range (WDR) 140dB WDR
Image stabilization EIS; Built-in gyroscope to improve EIS performance.
Photo beautification BLC, HLC, 3D DNA
Privacy mask up to 24 masks, polygon region, mosaic mask, mask color configurable
Regional focus yes
Regional exposure yes

Interface
Web interface 1 RJ45 10 M/100 M Ethernet Interface
Storage location Built-in memory card slot, support Micro SD/Micro SDHC/Micro SDXC, up to 256 GB; NAS (NFS, SMB/ CIFS), ANR
Sound 1 audio input, 2.0 to 2.4Vp-p, 1k Ohm±10%, 1 audio output, line level, impedance: 600 Ω
Alarm 7 alarm inputs, 2 alarm outputs
RS-485 Half duplex, HIKVISION, Pelco-P, Pelco-D, self-adaptive

Features
Main functions motion detection, video tampering alarm, alarm input, alarm output, exception
Smart features unattended baggage detection, object removal detection, Intrusion Detection, Line Crossing Detection, Region Entrance Detection, Region Exiting Detection, Audio Exception Detection
Interface Alarm actions, such as Preset, Patrol Scan, Pattern Scan, Memory Card Video Record, Trigger Recording, Notify Surveillance Center, Upload to FTP/Memory Card/NAS, Send Email, etc.
Smart tracking manual tracking, event tracking

Smart features
Facial recognition Support detecting up to 30 faces at the same time. Support detecting, tracking, capturing, grading, selecting of face in motion, and output the best face picture of the face.

Home
System parameters 24 VAC ± 25%, max. 100 W
Size 460 mm × 390 mm × 491 mm (18.11" × 15.35" × 19.33")
Weight Approx. 15 kg (33.07 lb)
Material Aluminum alloy ADC12
Working conditions Temperature: -40°C to 70°C (-40°F to 158°F)，Humidity: ≤ 95%
Main functions mirror, password protection, watermark, IP address filter
Vandal-proof Alarm yes
Wiper Yes. Rain-sensing auto control
Language 32 languages: English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil)

Approvals
Protection IP66 Standard, 6000V Lightning Protection, Surge Protection and Voltage Transient Protection
