Hikvision dome DS-2CD2686G2-IZS (white, 8 MP, 60 IR, AcuSense)
Product reference:
26-6941264088578
- MP (MegaPixel): 8 MP
- Lens: 2.8 - 12 mm, horizontal FOV: 108° - 46°
- Technology: AcuSense
- Built-in microphone: No, there is a microphone input
- Built-in speaker: No, there is an audio input
- Night illumination: 60 m. IR
- microSD slot: Yes, 256GB
- Operating conditions: -30 °C to 60 °C
- Safety level: IP66
- Video compression: H.265+
- WiFi: No
- Bracket/base (optional): DS-1476ZJ-SUS
- Outdoor/Indoor: Outdoor
Hikvision dome DS-2CD2686G2-IZS (white, 8 MP, 60 IR, AcuSense)
Product reference:
26-6941264088578
- MP (MegaPixel): 8 MP
- Lens: 2.8 - 12 mm, horizontal FOV: 108° - 46°
- Technology: AcuSense
- Built-in microphone: No, there is a microphone input
- Built-in speaker: No, there is an audio input
- Night illumination: 60 m. IR
- microSD slot: Yes, 256GB
- Operating conditions: -30 °C to 60 °C
- Safety level: IP66
- Video compression: H.265+
- WiFi: No
- Bracket/base (optional): DS-1476ZJ-SUS
- Outdoor/Indoor: Outdoor
You have 3 products in compare list, please remove someone and try again
- Add to favorites products
- Added to favorites products
- Removed to favorites product
Guarantee
24 month
Delivery from Lithuania in
2 - 4
business days
| Name | Description |
| Sensor | 1/1.8" Progressive Scan CMOS |
| Min. lighting | Color: 0.003 Lux @ (F1.6, AGC ON), 0 Lux with IR |
| Shutter speed | 1/3 s to 1/100,000 s |
| Exposure | Yes |
| Day/night | IR Cut Filter |
| Angle control | Pan: 0° to 355°, tilt: 0° to 90°, rotate: 0° to 360° |
| WDR | 120dB |
| Lens | 2.8 to 12 mm |
| Aperture | F1.4 |
| FOV | Horizontal FOV: 108.1° to 45.5°, vertical FOV: 58.4° to 25.7°, diagonal FOV: 127.3° to 52.1° |
| Installation | Φ14 |
| IR distance | Up to 60 m |
| Wavelength | 850 nm |
| Max resolution | 3840 × 2160 |
| Main stream | 50Hz: 20fps (3840×2160, 3072×1728), 25fps (2688×1520,1920×1080, 1280×720) 60Hz: 20fps (3840×2160, 3072×1728), 30fps (2688× 1520,1920×1080, 1280×720) |
| Secondary flow | 50Hz: 25fps (640×480, 640×360, 320×240) 60Hz: 30fps (640×480, 640×360, 320×240) |
| Tertiary flow | 50Hz: 25fps (1280×720, 640×480, 640×360, 320×240) 60Hz: 30fps (1280×720, 640×480, 640×360, 320×240) |
| Image compression | Main stream: H.265+/H.264+/H.265/H.264 Sub-stream: H.265/H.264/MJPEG Third stream: H.265/H.264 |
| H.264 type | Baseline Profile/Main Profile/High Profile |
| H.265 type | Main Profile |
| Video bit rate | 32 Kbps to 16 Mbps |
| SVC | H.264 and H.265 encoding support |
| Audio compression | G.711/G.722.1/G.726/MP2L2/PCM/MP3 |
| Audio bit rate | 64Kbps(G.711)/16Kbps(G.722.1)/16Kbps(G.726)/32-192Kbps(MP2L2)/8Kbps-320Kbps(MP3) |
| Ambient noise cancellation | Yes |
| Audio sample rate | 8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz |
| Main events | Motion detection, video tampering alarm, exception (network disconnected, IP address conflict, illegal login, HDD full, HDD error), scene change detection |
| Additional protection | Line crossing detection, intrusion detection, region entrance detection, region exiting detection (HumanVehicle classification) |
| ROI | 1 fixed region for main stream, sub-stream and third stream |
| Linking method | Upload to FTP/NAS/memory card, notify surveillance center, send email, alarm output, audible warning, trigger capture |
| Image enhancement | BLC, HLC, 3D DNA |
| Image settings | Saturation, brightness, contrast, sharpness, AGC and white balance adjustable by client software or web browser |
| Day/night switching | Day/Night/Auto/Schedule/Triggered by Alarm In |
| Network storage | microSD/SDHC/SDXC card (256 GB), local storage and NAS (NFS,SMB/CIFS), ANR |
| Protocols | TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour, SSL/TLS |
| API | ONVIF (PROFILE S, PROFILE G), ISAPI, SDK |
| Protection | Password protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for ONVIF, TLS1.2 |
| Broadcast | Up to 6 channels |
| User/Host | Up to 32 users, 3 levels: administrator, operator and user |
| Software | iVMS-4200, Hik-Connect, Hik-Central |
| Browser | Plug-in required live view: IE8+, Chrome 41.0-44, Firefox30.0-51, Safari8.0-11 Plug-in free live view: Chrome 57.0+, Firefox 52.0+ |
| Communication certificates | 1 RJ45 10M/100M self-adaptive Ethernet port |
| Sound | 1 audio input (line in), two-core terminal block; 1 audio output (line out), two-core terminal block |
| Warning signs | 1 alarm input, 1 alarm output (max. 24 VAC/24 VDC@500 mA) |
| Internal memory | Built-in micro SD slot, up to 256 GB |
| Languages | 32 languages English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil) |
| Main functions | Anti-flicker, three streams, heartbeat, mirror, privacy masks, pixel counter |
| Reloading | Reset via reset button on camera body, web browser and client software |
| Start and working conditions | -30 °C to 60 °C (-22 °F to 140 °F), humidity 95% or less (non-condensing) |
| Storage operating conditions | -30 °C to 60 °C (-22 °F to 140 °F), humidity 95% or less (non-condensing) |
| Power supply | 12 VDC ± 25%, two-core terminal block; reverse polarity protection; PoE (802.3at, class 4) |
| Power and current | 12 VDC, 1.12 A, max. 13.5 W; PoE (802.3at, 42.5 V to 57 V), 0.5 A to 0.3 A, max. 15 W |
| Material | Metal |
| Measurements | Camera: Φ 144 × 333 mm (Φ 5.7" × 13.1") With package: 385 × 190 × 180 mm (15.2" × 7.5" × 7.1") |
| Weight | Camera: approx. 1430 g (3.2 lb.) With package: approx. 2490 g (5.5 lb.) |
| EMC | FCC (47 CFR Part 15, Subpart B); CE-EMC (EN 55032: 2015, EN 61000-3-2: 2014, EN 61000-3-3: 2013, EN 50130-4: 2011 +A1: 2014); RCM (AS/NZS CISPR 32: 2015); IC (ICES-003: Issue 6, 2016); KC (KN 32: 2015, KN 35: 2015) |
| Security | UL (UL 60950-1); CB (IEC 60950-1:2005 + Am 1:2009 + Am 2:2013); CE-LVD (EN 60950-1:2005 + Am 1:2009 + Am 2:2013); BIS (IS 13252(Part 1):2010+A1:2013+A2:2015); LOA (IEC/EN 60950-1) |
| Environmental protection | CE-RoHS (2011/65/EU); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2006) |
| Protection | Ingress protection: IP66 (IEC 60529-2013), IK10 (IEC 62262:2002) |
| Weight | 1.917 kg |
