Lens typeFixed focal length lens, selectable 2.8mm or 4mm
Focal length and field of view2.8 mm: horizontal viewing angle 108.8°, vertical 56.4°, diagonal 134.3°; 4 mm: horizontal viewing angle 93.3°, vertical 47.2°, diagonal 114.2°
Lens mountM16
Aperture typeFixed
ApertureF1.0
Depth of field2.8 mm: 3.3 m to ∞; 4mm: 3.8m to ∞
DORI distances2.8 mm: detection (D) 89 m, observation (O) 35 m, recognition (R) 17 m, identification (I) 8 m; 4 mm: detection (D) 109 m, observation (O) 43 m, recognition (R) 21 m, identification (I) 10 m
Additional lighting typeWhite light and IR
Additional lighting rangeUp to 30 m
Smart additional lightingYes
IR wavelength850 nm
Main video stream50Hz: 25fps (3840×2160, 3200×1800, 2688×1520, 1920×1080, 1280×720); 60Hz: 30fps (3840×2160, 3200×1800, 2688×1520, 1920×1080, 1280×720)
Third video stream50 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360); 60 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360); only supported at certain settings
Image compressionMain stream: H.265/H.264/H.264+/H.265+; Sub stream: H.265/H.264/MJPEG; Tertiary stream: H.265/H.264 (only supported under certain settings)
Video bitrate32 Kbps-16 Mbps
H.264 profileBaseline Profile, Main Profile, High Profile
H.265 profileMain Profile
Bitrate controlCBR, VBR
Scalable Video Coding (SVC)H.264 and H.265 encoding
Region of Interest (ROI)1 fixed area in the main video stream
Browser supportLive preview without plugin: Chrome 80 and above, Firefox 80 and above, Edge 89 and above; local service: Chrome 80 and above, Firefox 80 and above, Edge 89 and above
Adjusting image parametersYes
Image settingsImage rotation mode, saturation, brightness, contrast, detail, gain, white balance; adjustable via client software or web browser
Switching between day and night modesDay, night, automatic, schedule
Image enhancement featuresBLC, HLC, 3D DNA, distortion correction, fog reduction (Defog)
Signaling interfaces-S model: 1 input, 1 output (max. 24 V AC / 24 V DC, 1 A)
Playback buttonYes
Main eventsMotion detection (the ability to trigger an alarm based on specified object types - people and vehicles), image tampering detection, exception detection
Event notifications and actionsUpload to FTP server, NAS or memory card, notify monitoring center, trigger recording, trigger photo capture, send email; -S model: trigger alarm output
Smart eventsScene change detection
Facial recognitionYes
Perimeter securityDetection of line crossing, intrusion, zone entry and zone exit; ability to trigger an alarm based on specified object types - people and vehicles
Power supply12 V DC ± 25 %, 0.75 A, maximum power 9 W, Ø5.5 mm coaxial power plug, reverse polarity protection; PoE: IEEE 802.3af, Class 3, maximum power 10.5 W
