DVR 16CH HDCVI PENTABRID AI / XVR5216AN-I3 / T DAHUA
Product reference:
2-6937552415041
DVR 16CH HDCVI PENTABRID AI / XVR5216AN-I3 / T DAHUA
Product reference:
2-6937552415041
You have 3 products in compare list, please remove someone and try again
- Add to favorites products
- Added to favorites products
- Removed to favorites product
Guarantee
36 month
Delivery from Lithuania in
3 - 5
business days
XVR5216AN-I3/T
16CH Penta-brid 5MP Value/1080P 1U 2HDDs WizSense Digital Video Recorder
- 16-ch Analog Video Input, Max. 5M-N@20fps/1080p@25fps Encoding Capability
- Max. 24-ch IP Video Input (Up to 6MP)
- 16-ch Two-way Talk
- AI Functions: 2-ch AcuPick, 2-ch FR, 4-ch Perimeter Protection, 16-ch SMD, 16-ch AI Coding
- 2 Bays. Up to 16TB for Each HDD Storage Capacity
| Audio bitrate | 64 Kbit/s |
| Audio formats supported | G.711/G.711u/PCM |
| Audio input channels | 16 channels |
| Audio output channels | 1.0 channels |
| Backup function | Yes |
| BNC input ports | 16 |
| Certification | CE-LVD: IEC 62368-1:2014 CE-EMC: EN IEC 61000-3-2:2019, EN 61000-3-3:2013+A1:2019, EN 55032:2015+A11:2020, EN 55035:2017+A11:2020, EN 55024:2010+A1:2015, EN 50130-4:2011+A1:2014 |
| Compliance certificates | CE |
| DC voltage | 12 V |
| Depth | 289.6 mm |
| Dual stream support | Yes |
| Ethernet interface type | Fast Ethernet/Gigabit Ethernet |
| Ethernet LAN | Yes |
| Ethernet LAN (RJ-45) ports | 1 |
| Ethernet LAN data rates | 10/100/1000 Mbit/s |
| Graphical user interface (GUI) | Yes |
| HDD interface | SATA |
| HDMI ports quantity | 1 |
| Height | 53 mm |
| Maximum HDD capacity | 16000 GB |
| Maximum video resolution | 3840 x 2160 pixels |
| Multi-display modes | 1/16/25/4/8/9 |
| Multi-display supported | Yes |
| Number of HDDs supported | 2 |
| Number of simultaneously playbacked channels | 16 channels |
| Operating relative humidity (H-H) | 10 - 90 % |
| Operating system installed | Embedded LINUX |
| Operating temperature (T-T) | -10 - 55 °C |
| Package depth | 137 mm |
| Package height | 356 mm |
| Package weight | 2950 g |
| Package width | 427 mm |
| Playback modes | Event/General/Instant/Smart/Tag |
| Power consumption (typical) | 12 W |
| Power supply type | DC |
| Product colour | Black |
| Product Net Weight | 1.8 kg |
| Quick start guide | Yes |
| Rack capacity | 1U |
| RS-485 ports | 1 |
| Shipping Box Depth | 56 cm |
| Shipping Box Height | 37.5 cm |
| Shipping Box Weight | 12.5 kg |
| Shipping Box Width | 44 cm |
| Storage temperature (T-T) | -20 - 60 °C |
| Summary | Dahua Technology XVR5216AN-I3/T. Product colour: Black, Maximum video resolution: 3840 x 2160 pixels, Video compression formats: H.264, H.264+, H.265, H.265+. Video resolutions: 3840 x 2160,1920 x 1080,1280 x 720,1280 x 1024. Video input channels: 24 channels. Ethernet interface type: Fast Ethernet, Gigabit Ethernet, Supported network protocols: HTTP; HTTPS; TCP/IP; IPv4; IPv6; RTSP; UDP; NTP; DHCP; DNS; SMTP; UPnP; IP Filter; FTP; DDNS; SNMP;, Ethernet LAN data rates: 10,100,1000 Mbit/s. HDD interface: SATA, Maximum HDD capacity: 16 TB |
| Supported network protocols | HTTP; HTTPS; TCP/IP; IPv4; IPv6; RTSP; UDP; NTP; DHCP; DNS; SMTP; UPnP; IP Filter; FTP; DDNS; SNMP; |
| Unit Box Height | 0.35 |
| Unit Box Length | 0.42 |
| Unit Box Width | 0.13 |
| Unit Calculated Volume | 0.0231 cubm |
| Unit Calculated Weight | 3.13 kg |
| Units per Shipping Box | 4 |
| USB 2.0 ports quantity | 1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 1 |
| USB connectivity | Yes |
| Vendor Homepage | https://www.dahuasecurity.com/products/hdcvi-products/hdcvi-recorders/5mp-value-1080p-series/xvr5216an-i3/t |
| VGA (D-Sub) output ports | 1 |
| Video compression formats | H.264/H.264+/H.265/H.265+ |
| Video input channels | 24 channels |
| Video loss detection | Yes |
| Video motion detection | Yes |
| Video RCA outputs | 1 |
| Video resolutions | 1280 x 1024/1280 x 720/1920 x 1080/3840 x 2160 pixels |
| Weight | 1800 g |
| Width | 375 mm |
