DVR 16CH HDCVI PENTABRID AI / XVR5116HS-I3 / T DAHUA
Product reference: 2-6937552414990

DVR 16CH HDCVI PENTABRID AI / XVR5116HS-I3 / T DAHUA

Product reference: 2-6937552414990
You have 3 products in compare list, please remove someone and try again
  • Add to favorites products
  • Added to favorites products
  • Removed to favorites product
Add to compare
378,16 €
Product in warehouse

Guarantee
36 month

Delivery from Lithuania in
3 - 5
business days

Your message has been successfully sent!
Fill in the required fields*

Launched by Dahua Technology, WizSense is a series of AI products and solutions that adopt independent AI chip and deep learning algorithm. It focuses on human and vehicle with high accuracy, enabling users to fast act on defined targets. Based on Dahua's advanced technologies, WizSense provides intelligent, simple and inclusive products and solutions.

Dahua Technology, a world-leading video-centric smart IoT solution and service provider, debuted its new XVR series, XVR5000-I3 Series featuring max.full-channel SMD Plus to benefit customers from AI upgrade (The number of channels differs depending on the model. Please refer to the specifications below for information on the number of channels.). This series has been developed to reduce false-alarm rates and the cost of human surveillance, thus bringing great value to customers in search of products with accurate human/vehicle alarm to raise the security level of various indoor and outdoor facilities.

  • H.265+/H.265 dual-stream video compression
  • Supports Full-channel AI Coding
  • Supports HDCVI/AHD/TVI/CVBS/IP video inputs
  • Max 24 channels IP camera inputs, each channel up to 6MP; Max 128Mbps incoming bandwidth
  • Up to 2 channels video stream (analog channel) Perimeter Protection
  • Up to 16 channels video stream (analog channel) SMD Plus
  • Up to 2 channels video stream (analog channel) human face recognition
  • IoT & POS functionalities

Analoginio signalo formato sistema NTSC/PAL
Atsarginio atkūrimo funkcija Taip
Audio išeiga 1 RCA
Audio įėjimas 1 RCA
Aukštis 47.6 mm
Bitų perdavimo sparta 32 Kbit/ai
BNC įvesties prievadai 16
Bruto svoris 1.58 kg
Darbo santykinės drėgmės diapazonas 10 - 90 %
Darbo temperatūros diapazonas (TT) -10 - 55 °C
DC įtampa 12 V
Dvigubo srauto palaikymas Taip
Eterneto sąsajos tipas Greitas eternetas
Ethernet LAN (RJ-45) portų kiekis 1
Ethernet LAN jungtis Taip
HDMI portų kiekis 1
Ilgis 237.4 mm
Kanalų kiekis 16 kanalai
Kietojo disko sąsaja SATA
Maitinimo tipas DC
Maksimali kietojo disko talpa 16000 GB
Maksimali vaizdo raiška 3840 x 2160 pikseliai
Model XVR5116HS-I3/T
Neto svoris 1 kg
Numatyta operacinė sistema Įdiegta "LINUX"
Pakuotės aukštis 315 mm
Pakuotės gylis 333 mm
Pakuotės plotis 89 mm
Palaikomi audio formatai G.711 µ-law/G.711 A-law/PCM
Palaikomi tinklo protokolai HTTP, HTTPS, TCP / IP, IPv4, RTSP, UDP, SMTP, NTP, DHCP, DNS, DDNS, P2P
Plotis 260 mm
Produkto spalva Juoda
PTZ kontrolė Taip
RS-485 prievadai 1
Rėmo pajėgumas 1U
Sertifikavimas CE: CE-LVD: EN 60950-1/IEC 60950-1
CE-EMC: EN 61000-3-2, EN 61000-3-3, EN 55032, EN
50130, EN 55024
FCC: Part 15 Subpart B
Shipping Box Depth 34.4 cm
Shipping Box Height 8.6 cm
Shipping Box Weight 1.58 kg
Shipping Box Width 28.5 cm
Summary Dahua Technology XVR5116HS-I3/T. Product colour: Black, Maximum video resolution: 3840 x 2160 pixels, Video compression formats: H.264, H.264+, H.265, H.265+. Audio input: 1 RCA, Audio output: 1 RCA, Video in: HDCVI/AHD/TVI/CVBS/IP. Ethernet interface type: Fast Ethernet, Supported network protocols: HTTP, HTTPS, TCP / IP, IPv4, RTSP, UDP, SMTP, NTP, DHCP, DNS, DDNS, P2P. HDD interface: SATA, Maximum HDD capacity: 16 TB. Power supply type: DC, DC voltage: 12 V
Svoris 1170 g
Unit Box Height 0.086
Unit Box Length 0.344
Unit Box Width 0.285
Unit Brutto Volume 0.008431 cubm
USB 2.0 portų kiekis 1
USB 3.2 (3.1 1 kart.) A tipo prievadų skaičius 1
Vaizdo fiksavimo greitis (NTSC) 30 fps
Vaizdo fiksavimo greitis (PAL) 25 fps
Vaizdo judesio detekcija Taip
Vaizdo signalo dingimo aptiktis Taip
Vaizdo transliavimas Taip
Vaizdo "in" jungtis HDCVI/AHD/TVI/CVBS/IP
Vendor Homepage https://www.dahuasecurity.com/products/All-Products/HDCVI-Recorders/5MP-Value1080p-Series/XVR5116HS-I3/T
VGA ("D-Sub") išvesties prievadai 1
Video suspaudimo formatai H.264/H.264+/H.265/H.265+
Vieneto aukštis 8.6 cm
Vieneto gylis 34.4 cm
Vieneto plotis 28.5 cm
Vienetų skaičius vienoje siuntimo dėžėje 1
