Ubiquiti Dream Wall gateway / controller

Ubiquiti Dream Wall. Product colour: White, Enclosure material: Metal, Mounting type: Wall mounting. Antenna type: Internal, Antenna gain level (max): 6 dBi, Compatible memory cards: MicroSD (TransFlash), MicroSDHC, MicroSDXC. Display type: LCD, Processor manufacturer: ARM, Processor frequency: 1.7 MHz. Ethernet LAN data rates: 1000,10000 Mbit/s, Networking standards: IEEE 802.11a, IEEE 802.11b, IEEE 802.11g. Security algorithms: WEP, WPA, WPA-PSK, WPA2, WPA3

All-in-one internet gateway, WiFi access point, and UniFi Console with an abundance of PoE ports.

Design

Product colour: White
Enclosure material: Metal
Mounting type: Wall mounting
LED indicators: Power, Yes

Features

Antenna type: Internal
Antenna gain level (max): 6 dBi
Feature: Card reader integrated
Compatible memory cards: MicroSD (TransFlash), MicroSDHC, MicroSDXC

Performance

Feature: Control display unit
Display type: LCD
Feature: Built-in processor
Processor manufacturer: ARM
Processor frequency: 1.7 MHz
Number of processors installed: 1
Internal memory: 4000 MB
Internal memory type: DDR4
SSD capacity: 128 GB
Flash memory: 16 MB

Network

Ethernet LAN data rates: 1000,10000 Mbit/s
Networking standards: IEEE 802.11a, IEEE 802.11b, IEEE 802.11g
Feature: Wi-Fi

Security

Security algorithms: WEP, WPA, WPA-PSK, WPA2, WPA3
Feature: VLAN support

Ports & interfaces

WAN connection: Ethernet (RJ-45), SFP

Management features

Feature: Quality of Service (QoS) support
Feature: Reset button

Power

Power consumption (max): 532 W
Input voltage: 100 - 240 V
Input frequency: 50/60 Hz
Input current: 7 A
Power supply: 550 W
Feature: Power over Ethernet (PoE)

Weight & dimensions

Width: 549 mm
Depth: 62 mm
Height: 342 mm
Weight: 8.6 kg

Packaging content

Cables included: AC

Operational conditions

Operating temperature (T-T): -10 - 40 °C
Operating relative humidity (H-H): 5 - 95%

Certificates

Certification: CE, FCC, IC
