Ubiquiti Dream Machine Special Edition gateway / controller

Ubiquiti Dream Machine Special Edition. Product colour: Stainless steel, Rack capacity: 1U, Enclosure material: Aluminum. Processor frequency: 1700 MHz, Internal memory: 4096 MB, Internal memory type: DDR4. Ethernet LAN data rates: 1000 Mbit/s, Networking standards: IEEE 802.3af, IEEE 802.3at. WAN connection: Ethernet (RJ-45). Power consumption (typical): 50 W, Input voltage: 100 - 240 V, Input frequency: 50 - 60 Hz
All-in-one router and security gateway with an integrated PoE switch and network video recorder.
The Dream Machine Special Edition (UDM SE) is an enterprise-grade UniFi OS Console capable of helping home and business owners alike seamlessly scale and manage their networks with high-speed, dual-WAN connectivity (10G SFP+ and 2.5GbE RJ45 ports), a Gigabit, PoE switch, and a network video recorder (NVR) with 128 GB of internal storage. Powered by UniFi OS, the UDM SE gives you full control of all your UniFi devices, including access points, Protect cameras, Talk phones, and Access readers. It's also a future-proof console since it will be able to run all upcoming UniFi OS applications. Engineered for end-to-end simplicity, the UDM SE features an integrated Bluetooth radio that streamlines the initial setup and configuration process, which can be completed in minutes with the UniFI Network application (web or mobile).

Design

Product colour: Stainless steel
Rack capacity: 1U
Enclosure material: Aluminum
Mounting type: Rack mounting
LED indicators: Activity, Link, Ready

Performance

Control display unit: Yes
Built-in processor: Yes
Processor frequency: 1700 MHz
Number of processors installed: 1
Internal memory: 4096 MB
Internal memory type: DDR4
Flash memory: 16384 MB

Network

Ethernet LAN data rates: 1000 Mbit/s
Networking standards: IEEE 802.3af, IEEE 802.3at
Bluetooth: Yes

Ports interfaces

Ethernet LAN (RJ-45) ports: 8
WAN connection: Ethernet (RJ-45)

Management features

Reset button: Yes

Power

Power consumption (typical): 50 W
Input voltage: 100 - 240 V
Input frequency: 50 - 60 Hz
Input current: 4.4 A
Power supply: 240 W
Power over Ethernet (PoE): Yes

Weight dimensions

Width: 442.4 mm
Depth: 285.6 mm
Height: 43.7 mm
Weight: 4.95 kg

Operational conditions

Operating temperature (T-T): -10 - 40 °C
Operating relative humidity (H-H): 5 - 95%

Display

Touchscreen: Yes
Display diagonal: 3.3 cm (1.3")

Logistics data

Harmonized System (HS) code: 85176990
