TP-Link TL-MR6500v wireless router

TP-Link N300 4G LTE Telephony WiFi Router. WAN connection type: RJ-45. Wi-Fi band: Single-band (2.4 GHz), Top Wi-Fi standard: Wi-Fi 4 (802.11n), WLAN data transfer rate (max): 300 Mbit/s. Ethernet LAN interface type: Fast Ethernet, Ethernet LAN data rates: 10,100 Mbit/s, Cabling technology: 10/100Base-T(X). Mobile network generation: 4G, 3G standards: DC-HSPA+, HSPA, HSPA+, UMTS, 4G standard: LTE-TDD LTE-FDD. Security algorithms: 64-bit WEP, 128-bit WEP, WPA, WPA-PSK, WPA2, WPA2-PSK, Firewall security: : DoS, SPI Firewall, IP and MAC Address Binding
Enjoy WiFi and Phone Calls All in One 4G Router
4G LTE Telephony Modem Router
Plug and Play,
No Configuration
With an integrated 4G LTE modem and a built-in SIM card slot, all you need to do is insert a micro SIM card and turn on the router. Enjoying fast, stable WiFi on a 4G LTE network has never been easier.
Share WiFi over a 4G Network
— Flexible and Stable
Simply build your home WiFi network via 4G broadband access with download speeds of up to 150 Mbps. You can share the internet with multiple WiFi devices to enjoy uninterrupted HD movies, rapid file downloads, seamless video chats, and more at the same time.
Enjoy WiFi and Phone Calls Simultaneously
TL-MR6500v is not only a WiFi router and modem combo, but also a phone. It has a phone port to connect your existing landline phone so that you can make phone calls and surf the internet at the same time. Moreover, various voice functions are supported including VoIP, VoLTE, and CSFB. Simply enjoy a professional and high-quality voice call as you like.
Built-in Storage for Voicemail
Instead of paying for a voicemail service from your ISP, get free access if you own this modem/router/phone combo. With 50 MB of internet storage, TL-MR6500v records 100 minutes of voicemail. Never worry about missing any calls or messages when away from home.
Special Design for Maximum Network Coverage
Two detachable advanced antennas reinforce the wireless connection between the router and every device with more stability and flexibility. A built-in power amplifier and low noise amplifier also help provide wider coverage by improving the router's sending and receiving capabilities.
Used for up to 32 Devices with Superior Stability
Easily share a 3G/4G connection with up to 32 wireless devices, such as phones, tablets, and laptops, at the same time. 3 LAN ports stand ready to provide internet for wired devices like desktop computers, printers, and more.
Available WAN Connection Backup
With a fully functional WAN/LAN Port, TL-MR6500v also works as a router which is compatible with cable, fiber, and DSL modem. Its WAN and 3G/4G failover backup strategy keeps a sustained internet connection no matter your situation.
Control at Your Fingertips
The powerful Tether app lets you monitor and manage your network settings easily from your phone (Android or iOS).
Easily set up Parental Controls, Guest Network, and QoS for your home network via Tether.

WAN connection

Ethernet WAN: Yes
DSL WAN: No
SIM card slot: Yes
3G/4G USB modem compatibility: Yes
WAN connection type: RJ-45

Wireless LAN features

Wi-Fi band: Single-band (2.4 GHz)
Top Wi-Fi standard: Wi-Fi 4 (802.11n)
WLAN data transfer rate (max): 300 Mbit/s
Wi-Fi standards: 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n)
WLAN data transfer rate (first band): 300 Mbit/s

Network

Ethernet LAN: Yes
Ethernet LAN interface type: Fast Ethernet
Ethernet LAN data rates: 10,100 Mbit/s
Cabling technology: 10/100Base-T(X)
Networking standards: IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Port forwarding: Yes
Port triggering: Yes
Dynamic DNS (DDNS): Yes
Static route: Yes
Number of guest networks (2.4 GHz): 1
VPN server: PPTP VPN, OpenVPN
VPN tunnels quantity: 10
VPN Passthrough: Yes

Mobile network

Mobile network generation: 4G
3G: Yes
4G: Yes
Dual SIM support: No
3G standards: DC-HSPA+, HSPA, HSPA+, UMTS
4G standard: LTE-TDD LTE-FDD
4G bands supported: 800,900,1800,2100,2300,2500,2600 MHz
3G bands supported: 900,2100 MHz
SIM card type: MicroSIM

Ports interfaces

Ethernet LAN (RJ-45) ports: 2
USB port: No
RJ-11 ports quantity: 1
Memory card slot(s): No
DC-in jack: Yes

Management features

Wi-Fi Multimedia (WMM)/(WME): Yes
Quality of Service (QoS) support: Yes
Reset button: Yes
WPS push button: Yes

Security

Security algorithms: 64-bit WEP, 128-bit WEP, WPA, WPA-PSK, WPA2, WPA2-PSK
Firewall: Yes
Firewall security: : DoS, SPI Firewall, IP and MAC Address Binding
Guest access: Yes
Parental control: Yes
DMZ support: Yes

Protocols

DHCP client: Yes
DHCP server: Yes
Universal Plug and Play (UPnP): Yes
VoIP protocols: SIP(RFC3261)/RTP(RFC1889/3550), G.711A/u, G.729AB, G.726

Design

Product colour: Black
Wall mountable: Yes
On/off switch: Yes
Product type: Tabletop router

Packaging content

Cables included: LAN (RJ-45)
AC adapter included: Yes
Quick installation guide: Yes

Antenna

Antenna design: External
Antennas quantity: 2
Detachable antenna(s): Yes

Power

Power source type: DC
Output voltage: 12 V
Output current: 1 A

Operational conditions

Operating temperature (T-T): 0 - 40 °C
Storage temperature (T-T): -40 - 70 °C
Storage relative humidity (H-H): 5 - 90%

Weight dimensions

Width: 202 mm
Depth: 141 mm
Height: 33.6 mm

Packaging data

Package width: 307 mm
Package depth: 223 mm
Package height: 70 mm
Package weight: 640 g

Logistics data

Harmonized System (HS) code: 85176990
