TP-LINK Omada AX3000 WiFi 6 Gigabit VPN Router
Product reference: 18-ER706W

TP-LINK Omada AX3000 WiFi 6 Gigabit VPN Router

TP-LINK Omada AX3000 WiFi 6 Gigabit VPN Router
TP-LINK Omada AX3000 WiFi 6 Gigabit VPN Router
TP-LINK Omada AX3000 WiFi 6 Gigabit VPN Router
TP-LINK Omada AX3000 WiFi 6 Gigabit VPN Router
TP-LINK Omada AX3000 WiFi 6 Gigabit VPN Router
TP-LINK Omada AX3000 WiFi 6 Gigabit VPN Router

TP-LINK Omada AX3000 WiFi 6 Gigabit VPN Router

Product reference: 18-ER706W

TP-LINK Omada AX3000 WiFi 6 Gigabit VPN Router

You have 3 products in compare list, please remove someone and try again
  • Add to favorites products
  • Added to favorites products
  • Removed to favorites product
Add to compare
151,25 €
Product in warehouse

Guarantee
12 month

Delivery from Lithuania in
2 - 4
business days

Your message has been successfully sent!
Fill in the required fields*

  • AX3000 Dual-Band WiFi: Supports 2402 Mbps on 5 GHz and 574 Mbps on 2.4 GHz

  • 6 Gigabit Ethernet Ports: 1 gigabit SFP and 5 gigabit RJ45 ports provide high-speed wired connectivity.

  • Omada Mesh Technology: Seamlessly connects to EAPs that support mesh technology, ideal for large-scale scenarios.

  • Centralized Management: Cloud access and Omada app for ultra convenience and easy management.

  • Boosted Coverage:Triple external antennas extend and concentrate the Wi-Fi signals.

  • High-Security VPN: Supports multiple VPN protocols including IPSec / SSL / Wireguard / PPTP / L2TP VPN, helping users to establish remote connections more flexibly.

  • Abundant Security Features: Advanced firewall policies, DoS defense, IP/MAC/URL filtering, and more security functions protect your network and data.


























SECURITY
Access ControlSource/Destination IP Based Access Control
Filtering• Web Group Filtering† • URL Filtering • Web Security†
ARP Inspection• Sending GARP Packets • ARP Scanning† • IP-MAC Binding
Attack Defense• TCP/UDP/ICMP Flood Defense • Block TCP Scan (Stealth FIN/Xmas/Null) • Block Ping from WAN

















































HARDWARE FEATURES
Interface• 1 Gigabit SFP WAN/LAN Port • 1 Gigabit WAN Port • 4 Gigabit LAN/WAN Ports • 1 USB3.0 (supports USB LTE dongle and USB Storage)
ButtonReset Button
Power Supply12VDC / 2A Power Adapter
Wi-Fi Frequency Signal Rate• 2.4 GHz: 574 Mbps • 5 GHz: 2402 Mbps (HE160)
Flash128MB NAND
DRAM512MB DDR4
Dimensions (W x D x H)8.9 × 5.2 × 1.4 in (226 × 131 × 35 mm) (Antenna dimensions are not included)
Antenna• 2.4 GHz: 2x 3 dBi dual-band detachable antennas • 5 GHz: 3x 4.5 dBi dual-band detachable antennas
MountingDesktop/Wall-mounting
Max Power Consumption• EU: 16.8W (with USB 3.0 connected), 11.8W (without USB 3.0 connected) • US: 22.7W (with USB 3.0 connected) 18.2W (without USB 3.0 connected)









































































PERFORMANCE
GRE• Unencrypted: 624.2Mbps • Encrypted: 301.5Mbps
WireGuard VPN393.5Mbps
Concurrent Session150,000
New Sessions /Second5,100
NAT (Static IP)937.2Mbps / 936.1Mbps
NAT(DHCP)945.8Mbps / 940.6Mbps
NAT(PPPoE)942.9Mbps / 942.9Mbps
NAT (L2TP)837.4Mbps / 881.5Mbps
NAT (PPTP)803.0Mbps / 910.5Mbps
IPsec VPN Throughput• ESP-SHA1-AES256: 646.9Mbps • ESP-SHA256-AES256: 642.8Mbps • ESP-SHA384-AES256: 648.9Mbps • ESP-SHA512-AES256: 658.4Mbps
OpenVPN129.3Mbps
L2TP VPN Throughput• Unencrypted: 1034.0 Mbps • Encrypted: 570.0 Mbps
PPTP VPN Throughput• Unencrypted: 1165.0 Mbps • Encrypted: 209.0 Mbps
SSL VPN Throughput126.7Mbps
66 Byte Packet forwarding rate1,453,489 pps / 1,453,488 pps
1.518 Byte Packet forwarding rate81,274 pps / 91,275 pps

















WIRELESS FEATURES
Advanced Functions• Seamless Roaming • Mesh (with EAP that supports Mesh) • OFDMA • Beamforming • MU-MIMO • Wireless Encryption: WPA/WPA2/WPA3 Personal, WPA/WPA2/WPA3 Enterprise
Guest NetworkSupport

































BASIC FUNCTIONS
WAN Connection Type• Static IP • Dynamic IP • PPPoE (supports MRU Configuration) • PPTP • L2TP
MAC CloneModify WAN Address
DHCP• DHCP Server • DHCPv6 PD Server (only in Standalone Mode) • DHCP Options Customization • DHCP Address Reservation • Multi-IP Interfaces • Multi-Net DHCP
IPv6StaticIP / SLAAC / DHCPv6 / PPPoE / 6to4Tunnel / PassThrough / Non-Address mode
VLANs802.1Q VLANs
IPTVIGMP v2/v3 Proxy, Custom Mode, Bridge Mode

































ADVANCED FUNCTIONS
ACLIP/Port/Protocol/Domain Name Filtering
Advanced Routing• Static Routing • Policy Routing • RIP† • OSPF†
Bandwidth ControlIP-Based Bandwidth Control
Load Balance• Intelligent Load Balance • Application Optimized Routing • Link Backup (Timing, Failover) • Online Detection
NAT• One-to-One NAT • Multi-Net NAT • Port Forwarding • Port Triggering† • NAT-DMZ • FTP/H.323/SIP/IPSec/PPTP ALG • UPnP
Session LimitIP-Based Session Limit





























VPN
SSL VPN50 Tunnels
IPsec VPN• 100 IPSec VPN Tunnels • LAN-to-LAN, Client-to-LAN • Main, Aggressive Negotiation Mode • DES, 3DES, AES128, AES192, AES256 Encryption Algorithm • IPsec Failover • IKE v1/v2 • MD5, SHA1, SHA2-384 and SHA2-512 Authentication Algorithm • NAT Traversal (NAT-T) • Dead Peer Detection (DPD) • Perfect Forward Secrecy (PFS)
PPTP VPN• PPTP VPN Server • PPTP VPN Client (10)△ • 50 Tunnels • PPTP with MPPE Encryption
L2TP VPN• L2TP VPN Server • L2TP VPN Client (10)△ • 50 Tunnels • L2TP over IPSec
OpenVPN• OpenVPN Server • OpenVPN Client (5)△ • 55 OpenVPN Tunnels • 'Certificate + Account' Mode • Full Mode













AUTHENTICATION
Web Authentication• No Authentication • Simple Password§ • Hotspot (Local User / Voucher§ / SMS§ / Radius§) • External Radius Sever • External Portal Sever§ • LDAP





































MANAGEMENT
Omada AppYes.
Centralized Management• Omada Cloud-Based Controller • Omada Hardware Controller (OC300) • Omada Hardware Controller (OC200) • Omada Software Controller
Cloud AccessYes.
ServiceDynamic DNS (Dyndns, No-IP, Peanuthull, Comexe, DDNS Customization)
Maintenance• Web Management Interface • Remote Management • Export Import Configuration • SNMP v1/v2c/v3 • Diagnostics (Ping Traceroute)† • NTP Synchronize† • Port Mirroring • CLI (only in Standalone Mode) • Syslog Support
Zero-Touch ProvisioningYes. Require the use of Omada Cloud-Based Controller.
Management Features• Automatic Device Discovery • Intelligent Network Monitoring • Abnormal Event Warnings • Unified Configuration • Reboot Schedule • Captive Portal Configuration

























OTHERS
CertificationCE, FCC, RoHS
Package Contents• ER706W • Power Adapter • Quick Installation Guide
System Requirements• Microsoft Windows 98SE, NT, 2000, XP, Vista™ or Windows 7/8/8.1/10/11 • MAC OS, NetWare, UNIX or Linux
Environment• Operating Temperature: 0 °C to 40 °C (32 °F to 104 °F) • Storage Temperature: -40 °C to 70 °C (-40 °F to 158 °F) • Operating Humidity: 10% to 90% non-condensing • Storage Humidity: 5% to 90% non-condensing
