TELTONIKA Waterproof Tracker with Hight Capacity Internal Li-Ion Battery
Product reference:
18-FMB204
TELTONIKA Waterproof Tracker with Hight Capacity Internal Li-Ion Battery
TELTONIKA Waterproof Tracker with Hight Capacity Internal Li-Ion Battery
Product reference:
18-FMB204
TELTONIKA Waterproof Tracker with Hight Capacity Internal Li-Ion Battery
You have 3 products in compare list, please remove someone and try again
- Add to favorites products
- Added to favorites products
- Removed to favorites product
Guarantee
12 month
Delivery from Lithuania in
2 - 4
business days
Teltonika FMB204 is a SPECIAL waterproof (IP67) tracker with Bluetooth connectivity, internal high-gain GNSS and GSM antennas and an integrated high-capacity backup battery. The device is designed to work longer without a power source. FMB204 with a LiPo battery can work up to 6 days in power saving mode. FMB204 is perfect for agriculture, deliveries, refrigerated transport, trailer tracking, security and emergency services and more. 6-30V power supply makes FMB204 suitable for motorcycles and water transport.
| MODULE | |
| In the house | Teltonika TM2500 |
| Technology | GSM/GPRS/GPS/BLUETOOTH |
| GNSS | |
| GNSS | GPS, GLONASS, GALILEO, BEIDOU, SBAS, QZSS, DGPS, AGPS |
| Receiver | 33 channels |
| Tracking sensitivity | -165 dBM |
| Accuracy | < 2.5m CEP |
| Hot start | < 1 sec. |
| Warm start | < 25 seconds |
| Cold start | < 35 seconds |
| CELLULAR | |
| Technology | GSM |
| 2G bands | Quad-band 850 / 900 / 1800 / 1900 MHz |
| Data transfer | GPRS Multi-Slot Class 12 (up to 240 kbps), GPRS Mobile Station Class B |
| Data support | SMS (text/data) |
| POWER | |
| Input voltage range | 6 - 30 V DC with overvoltage protection |
| Internal Backup battery | 1800 mAh Li-Ion battery (6.66 Wh) |
| Power consumption | At 12V < 2.1 mA (Ultra Sleep) At 12V < 3.9 mA (Deep Sleep) At 12V < 4.2 mA (Online Sleep) At 12V < 15.7 mA (GPS Sleep) At 12V < 28.3 mA (nominal) |
| BLUETOOTH | |
| Specifications | 4.0 + LE |
| Supported peripherals | Temperature and Humidity sensor, Headset, OBDII dongle, Inateck Barcode Scanner, Universal BLE sensors support |
| INTERFACE | |
| Digital Inputs | 3 |
| Digital Outputs | 2 |
| Analog Inputs | 1 |
| 1WIRE DATA | 1 |
| 1WIRE POWER | 1 |
| GNSS antenna | Internal High Gain |
| Cellular antenna | Internal GSM High Gain |
| USB | 2.0 Micro USB |
| LED indication | 2 status LED lights |
| SIM | Dual-sim (1x Micro-SIM card; 1x eSIM) |
| Memory | 128MB internal flash memory |
| PHYSICAL SPECIFICATION | |
| Dimensions | 72.5 x 73 x 27.3 mm (L x W x H) |
| Weight | 205 g |
| OPERATING ENVIRONMENT | |
| Operating temperature (without battery) | -40°C to +85°C |
| Storage temperature (without battery) | -40°C to +85°C |
| Operating humidity | 5% to 95% non-condensing |
| Ingress Protection Rating | IP67 |
| Battery charging temperature | 0 °C to +45 °C |
| Battery discharge temperature | -20°C to +70°C |
| Battery storage temperature | -10°C to +45°C |
| FEATURES | |
| Sensors | Accelerometer |
| Scenarios | Green Driving, Over Speeding detection, Jamming detection, DOUT Control Via Call, GNSS Fuel Counter, Immobilizer, Excessive Idling detection, Unplug detection, Towing detection, Crash detection, Auto Geofence, Manual Geofence, Trip |
| Sleep modes | GPS Sleep, Online Deep Sleep, Deep Sleep, Ultra Deep Sleep |
| Configuration and firmware update | FOTA Web, FOTA, Teltonika Configurator (USB, Bluetooth), FMBT mobile application (Configuration) |
| SMS | Configuration, Events, DOUT control, Debug |
| GPRS commands | Configuration, DOUT control, Debug |
| Time Synchronization | GPS, NITZ, NTP |
| Fuel monitoring | LLS (Analog), OBDII dongle |
| Ignition detection | Digital Input 1, Accelerometer, External Power Voltage, Engine RPM (OBDII dongle) |
| CERTIFICATION APPROVALS | |
| Regulatory | CE/RED, E-Mark, EAC, RoHS, REACH |
