FMB230is a WATER AND DUST RESISTANT tracker with internal GNSS, GSM antennas, configurable digital/analog inputs, negative input, pulse inputs, three DOUT outputs, Bluetooth connectivity and a backup battery.


FMB230It is based on the existing 'Teltonika' platform, so it retains all theFMB130features, adding the additional IP67 dust and water resistance.


This tracker is completely dustproof and protected against temporary immersion in water. It can be installed both inside and outside the vehicle without worrying that high-pressure water, dirt or dusty environments will affect its operation or performance quality. This is especially relevant for industries that face difficult conditions, such as agriculture, construction, mining and others.


As well asFMB130,FMB230has 3xDOUT outputs, allowing you to use 3 different DOUT scenarios simultaneously, such as: immobilizer, horn, warning lights, door lock, etc.


This tracker also has a negative input option, which saves time when integrating connectors such as vehicle door sensor, alarm button, seat belt detection and similar sensors or accessories. At the same time, the pulse input can be used to read data from a fuel flow meter. Pulse fuel usage control is much more accurate than various types of fuel level sensors and allows for accurate measurement when needed. It is an excellent solution for high fuel consumption machinery such as cranes, construction vehicles, mining machinery, agricultural machinery, etc.


MODULE
In the house Teltonika TM2500
Technology GSM/GPRS/GNSS/BLUETOOTH
GNSS
GNSS GPS, GLONASS, GALILEO, BEIDOU, QZSS, AGPS
Receiver Tracking: 33
Tracking sensitivity -165 dBM
Accuracy < 2.5m CEP
Hot start < 1 sec.
Warm start < 25 seconds
Cold start < 35 seconds
CELLULAR
Technology GSM
2G bands Quad-band 850 / 900 / 1800 / 1900 MHz
Data transfer GPRS Multi-Slot Class 12 (up to 240 kbps), GPRS Mobile Station Class B
Data support SMS (text/data)
POWER
Input voltage range 10 - 30 V DC with overvoltage protection
Internal Backup battery 170 mAh Li-Ion battery 3.7 V (0.63 Wh)
Power consumption At 12V < 2.5 mA (Ultra Deep Sleep) At 12V < 5 mA (Deep Sleep) At 12V < 5.5 mA (Online Deep Sleep) At 12V < 18.5 mA (GPS Sleep) At 12V < 34 mA (nominal with no load)
BLUETOOTH
Specifications 4.0 + LE
Supported peripherals Temperature and Humidity sensor, Headset, OBDII dongle, Inateck Barcode Scanner, Universal BLE sensors support
PHYSICAL SPECIFICATION
Dimensions 70.5 x 67.0 x 25.6 mm (L x W x H) 85.0 x 67.0 x 25.6 mm (L x W x H) (length with connector socket)
OPERATING ENVIRONMENT
Operating temperature (without battery) -40°C to +85°C
Storage temperature (without battery) -40°C to +85°C
Operating humidity 5% to 95% non-condensing
Ingress Protection Rating IP67
Battery charging temperature -0 °C to +45 °C
Battery discharge temperature -20°C to +60°C
Battery storage temperature -20 °C to +45 °C for 1 month -20 °C to +35 °C for 6 months
INTERFACE
Digital Inputs 3
Negative Inputs 1 (Digital Input 2)
Impulse Inputs 2 (Digital Input 1, Digital Input 2)
Digital Outputs 3
Analog Inputs 2
CAN Adapter inputs 1
1-Wire 1
GNSS antenna Internal High Gain
Cellular antenna Internal High Gain
USB 2.0 Micro USB
LED indication 2 status LED lights
SIM Micro-SIM + eSIM
Memory 128MB internal flash memory
FEATURES
Sensors Accelerometer
Scenarios Green Driving, Over Speeding detection, Jamming detection, GNSS Fuel Counter, DOUT Control Via Call, Excessive Idling detection, Immobilizer, iButton Read Notification, Unplug detection, Towing detection, Crash detection, Auto Geofence, Manual Geofence, Trip
Sleep modes GPS Sleep, Online Deep Sleep, Deep Sleep, Ultra Deep Sleep
Configuration and firmware update FOTA Web, FOTA, Teltonika Configurator (USB, Bluetooth), FMBT mobile application (Configuration)
SMS Configuration, Events, DOUT control, Debug
GPRS commands Configuration, DOUT control, Debug
Time Synchronization GNSS, NITZ, NTP
Fuel monitoring LLS (Analog), LV-CAN200, ALL-CAN300, CAN-CONTROL, OBDII dongle
Ignition detection Digital Input 1, Accelerometer, External Power Voltage, Engine RPM (CAN Adapters, OBDII dongle)
CERTIFICATIONS APPROVALS (IN PROGRESS)
Regulatory CE-RED, E-mark, Reach, RoHS, Anatel

Package contains: - FMB230 tracker - Input/output power supply cable- Packaging box with Teltonika branding
