Teltonika TRB160 4G LTE Cat6 IoT-Gateway gateway / controller

Teltonika TRB160 4G LTE Cat6 IoT-Gateway. Product colour: Steel, Enclosure material: Aluminium, International Protection (IP) code: IP30. Antenna type: External, Antenna connector type: SMA. Processor manufacturer: ARM, Processor family: ARM Cortex, Processor model: Cortex-A7. Supported network protocols: TCP, UDP, IPv4, IPv6, ICMP, NTP, DNS, HTTP, HTTPS, SFTP, FTP, SMTP, SSL/TLS, ARP, VRRP, PPP,..., Data link protocols: HTTP(S), MQTT, Azure MQTT, Kinesis. Ethernet LAN data rates: 10,100,1000 Mbit/s, Networking standards: IEEE 802.3, IEEE 802.3az, IEEE 802.3u, Mobile network generation: 4G
The TRB160 is an ultra-small, lightweight, and energy-efficient IoT gateway equipped with mission-critical LTE Cat 6, Gigabit Ethernet, and a virtual network interface via USB Type-C for simultaneous powering and network data provision. This IoT gateway can reach cellular speeds of up to 300 Mbps with carrier aggregation in a broad range of applications and supports a wide range of industrial-grade protocols for M2M communication.

Design

Product colour: Steel
Enclosure material: Aluminium
International Protection (IP) code: IP30
Enclosure International Protection (IP) code: IP30

Features

Antenna type: External
Antenna connector type: SMA
Antennas quantity: 1
Short Message Service (SMS): Yes

Performance

Control display unit: No
Built-in processor: Yes
Processor manufacturer: ARM
Processor family: ARM Cortex
Processor model: Cortex-A7
Processor frequency: 1200 MHz
Internal memory: 128 MB
Flash memory: 256 MB

Protocols

Supported network protocols: TCP, UDP, IPv4, IPv6, ICMP, NTP, DNS, HTTP, HTTPS, SFTP, FTP, SMTP, SSL/TLS, ARP, VRRP, PPP, PPPoE, UPNP, SSH, DHCP, Telnet, SMPP, SNMP, MQTT, Wake On Lan (WOL)
Data link protocols: HTTP(S), MQTT, Azure MQTT, Kinesis
DMZ support: Yes

Network

Ethernet LAN data rates: 10,100,1000 Mbit/s
Networking standards: IEEE 802.3, IEEE 802.3az, IEEE 802.3u
4G LTE category: 4
Mobile network generation: 4G
Data network: 3G, 4G
Cabling technology: 10/100/1000Base-T(X)
Dynamic DNS (DDNS): Yes

Security

Firewall security: Yes
VLAN support: Yes
Network address translation (NAT): Yes

Ports interfaces

Ethernet LAN (RJ-45) ports: 1
WAN connection: Ethernet (RJ-45)

Management features

Quality of Service (QoS) support: Yes

Power

Power consumption (max): 3.3 W
Input voltage: 5 V
Power over Ethernet (PoE): Yes
DC input voltage: 9 - 30 V

Weight dimensions

Width: 74.2 mm
Depth: 83 mm
Height: 25 mm
Weight: 172 g

Operational conditions

Operating temperature (T-T): -40 - 75 °C
Operating relative humidity (H-H): 10 - 90%
