Teltonika TRB143 gateway / controller

Teltonika TRB143. Product colour: Steel, Enclosure material: Aluminium, International Protection (IP) code: IP30. Antenna type: External, Antenna connector type: SMA. Processor manufacturer: ARM, Processor family: ARM Cortex, Processor model: Cortex-A7. Supported network protocols: TCP, UDP, IPv4, IPv6, ICMP, NTP, DNS, HTTP, HTTPS, SFTP, FTP, SMTP, SSL/TLS, ARP, VRRP, PPP,..., Data link protocols: HTTP(S), MQTT, Azure MQTT, Kinesis. Ethernet LAN data rates: 10,100,1000 Mbit/s, Networking standards: IEEE 802.3, IEEE 802.3az, IEEE 802.3u, Mobile network generation: 4G

TRB143 - M-BUS CELLULAR GATEWAY
The TRB143 industrial gateway was designed with an integrated M-Bus interface specifically for telemetry and utility-monitoring applications. It features cellular and wired connectivity, one Gigabit Ethernet port, and a pair of digital Inputs/Outputs, making it applicable to a variety of environment-monitoring scenarios.

- M-BUS INTERFACE
Supporting up to 250 client devices
- CONNECTIVITY
4G/LTE (Cat 4), 3G, 2G
- DURABILITY
Rugged aluminum housing
- COMPACT
Simple integration

- Hardware version
Europe, The Middle East, Africa, Thailand

Design

Product colour: Steel
Enclosure material: Aluminium
International Protection (IP) code: IP30
Enclosure International Protection (IP) code: IP30

Features

Antenna type: External
Antenna connector type: SMA
Antennas quantity: 1
Feature: Short Message Service (SMS)

Performance

Feature: Built-in processor
Processor manufacturer: ARM
Processor family: ARM Cortex
Processor model: Cortex-A7
Processor frequency: 1300 MHz
Internal memory: 256 MB
Internal memory type: DDR3
Flash memory: 512 MB

Protocols

Data link protocols: HTTP(S), MQTT, Azure MQTT, Kinesis
Feature: DMZ support

Network

Ethernet LAN data rates: 10,100,1000 Mbit/s
Networking standards: IEEE 802.3, IEEE 802.3az, IEEE 802.3u
4G LTE category: 4
Mobile network generation: 4G
Data network: 2G, 3G, 4G
Cabling technology: 10/100/1000Base-T(X)
Feature: Dynamic DNS (DDNS)

Security

Firewall security: Yes
Feature: VLAN support
Feature: Network address translation (NAT)

Ports & interfaces

Ethernet LAN (RJ-45) ports: 1
WAN connection: Ethernet (RJ-45)

Management features

Feature: Quality of Service (QoS) support

Power

Power consumption (typical): 3 W
Power consumption (max): 6 W
Feature: Power over Ethernet (PoE)
DC input voltage: 12 - 30

Weight & dimensions

Width: 74.5 mm
Depth: 73 mm
Height: 25 mm
Weight: 145 g

Operational conditions

Operating temperature (T-T): -40 - 75 °C
Operating relative humidity (H-H): 10 - 90%
