Teltonika RUTX09 wired router

Teltonika RUTX09. Networking standards: IEEE 802.11e, IEEE 802.3, IEEE 802.3az, IEEE 802.3u, Ethernet LAN data rates: 10,100,1000 Mbit/s. Mobile network generation: 4G, 4G standard: LTE. Routing protocols: OSPFv2, BGP, RIP-1, RIP-2, VoIP protocols: H.323, SIP-alg, Supported network protocols: TCP, UDP, IPv4, IPv6, ICMP, UDP, NTP, DNS, HTTP, FTP, SMTP, TLS, ARP, VRRP, PPP, PPPoE, UPNP, SSH,.... Security algorithms: SNMP, SNMPv3, SSH. Processor frequency: 717 MHz, Flash memory: 256 MB, Internal memory: 256 MB

This powerful LTE router is designed as a Main/Backup Internet source where steady connection and high data throughput is required. Equipped with Dual-SIM and 4 x Gigabit Ethernet ports. RUTX09 has all advanced RutOS software and security features.

WAN connection

Feature: Ethernet WAN
Feature: SIM card slot

Network

Networking standards: IEEE 802.11e, IEEE 802.3, IEEE 802.3az, IEEE 802.3u
Feature: Ethernet LAN
Ethernet LAN data rates: 10,100,1000 Mbit/s
Feature: Auto MDI/MDI-X

Mobile network

Mobile network generation: 4G
4G standard: LTE
Feature: Short Message Service (SMS)

Management features

Feature: Web-based management
Feature: Quality of Service (QoS) support
Feature: Wi-Fi Multimedia (WMM)/(WME)
Feature: Reset button
Feature: Firmware upgradeable

Ports & interfaces

Ethernet LAN (RJ-45) ports: 4
USB ports quantity: 1
USB version: 2.0
Feature: DC-in jack

Protocols

Routing protocols: OSPFv2, BGP, RIP-1, RIP-2
VoIP protocols: H.323, SIP-alg
Supported network protocols: TCP, UDP, IPv4, IPv6, ICMP, UDP, NTP, DNS, HTTP, FTP, SMTP, TLS, ARP, VRRP, PPP, PPPoE, UPNP, SSH, DHCP, Telnet, SMPP

Security

Security algorithms: SNMP, SNMPv3, SSH
Feature: Firewall
Feature: Blacklist

Features

Feature: Built-in processor
Processor frequency: 717 MHz
Processor cores: 4
Flash memory: 256 MB
Internal memory: 256 MB
Internal memory type: DDR2
Operating system installed: RutOS

Design

Product colour: Aluminium
Housing material: Aluminium
LED indicators: Yes

Antenna

Antenna connector type: SMA

Operational conditions

Operating temperature (T-T): -40 - 75 °C
Operating relative humidity (H-H): 10 - 90%

Weight & dimensions

Width: 95 mm
Depth: 44 mm
Height: 115 mm
Weight: 456 g
