Teltonika RUT241

Teltonika RUT241. Device type: Cellular network router, Product colour: Black, Housing material: Aluminium, Plastic. Ethernet LAN interface type: Fast Ethernet, Ethernet LAN data rates: 10,100 Mbit/s, Networking standards: IEEE 802.11w, IEEE 802.11s, IEEE 802.11r, IEEE 802.11v, IEEE 802.11k, IEEE 802.3, IEEE 802.3u,.... Wi-Fi standards: 802.11b, 802.11g, Wi-Fi 4 (802.11n). Data network: 4G, 2G, 3G, 4G standard: LTE-FDD, SIM card type: MiniSIM + eSIM. Security algorithms: WPA2-Enterprise-PEAP, WPA2-PSK, WPA-EAP, WPA-PSK, WPA3-SAE, WPA3-EAP, OWE, AES-CCMP, TKIP, EAP-TLS

The RUT241 is a compact, industrial-grade cellular router designed for reliable and versatile connectivity in IoT and M2M applications. RUT241 features rugged design, multiple connection interfaces including 4G LTE, Wi-Fi, and two Ethernet ports, as well as full compatibility with Teltonika's Remote Management System (RMS). With support for automatic WAN failover and advanced RutOS software, the RUT241 enables continuous connectivity and solution automation through its digital inputs and outputs. RUT241 includes eSIM™ functionality based on the SGP.22 architecture, allowing up to seven eSIM™ profiles alongside a physical SIM card—easily managed via WebUI and RMS—offering even greater flexibility for global deployment. A non-eSIM™ version is also available - see the order code for details.

Design

Device type: Cellular network router
Product colour: Black
Housing material: Aluminium, Plastic
Mounting: DIN-rail/Wall mounting
Market positioning: Industrial
Feature: Reset button
LED indicators: Status, Signal strength, LAN, Power

Ethernet LAN features

Feature: Ethernet LAN
Ethernet LAN interface type: Fast Ethernet
Ethernet LAN data rates: 10,100 Mbit/s
Feature: DHCP server
Feature: VoIP
Feature: Auto MDI/MDI-X
Feature: Dynamic DNS (DDNS)
Feature: Universal Plug and Play (UPnP)
Feature: Network bridge

Wireless LAN features

Feature: Wi-Fi
Wi-Fi standards: 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Number of WLAN connections (max): 50

Mobile network

Data network: 4G, 2G, 3G
4G standard: LTE-FDD
Number of SIM cards: 2
SIM card type: MiniSIM + eSIM
4G LTE category: 4
Feature: Short Message Service (SMS)
Data transfer rate (LTE) (download): 150 Mbit/s
Data transfer rate (LTE) (upload): 50 Mbit/s

Ports & interfaces

Ethernet LAN (RJ-45) ports: 2

Security

Security algorithms: WPA2-Enterprise-PEAP, WPA2-PSK, WPA-EAP, WPA-PSK, WPA3-SAE, WPA3-EAP, OWE, AES-CCMP, TKIP, EAP-TLS
Feature: Network address translation (NAT)
Feature: Firewall
Feature: DMZ support
Feature: Port forwarding

Certificates

Compliance certificates: CE, UKCA, Federal Communications Commission (FCC), Industry Canada (IC), PTCRB, Norma Oficial Mexicana (NOM), RCM, KC, CB, REACH, RoHS

Packaging content

Cables included: LAN (RJ-45)
Feature: AC adapter included
Feature: Quick start guide

Performance

Feature: Built-in processor
Processor manufacturer: Mediatek
Processor frequency: 0.58 GHz
RAM capacity: 0.128 GB
RAM type: DDR2
Internal storage capacity: 0.016 GB
Operating system installed: RutOS
Feature: Web-based management
Antenna type: External
Antenna connector type: SMA/RP-SMA
Antennas quantity: 3
International Protection (IP) code: IP30

Power

Power source type: DC, PoE
Input voltage: 9 - 30 V
Power consumption (max): 6.5 W

Operational conditions

Operating temperature (T-T): -40 - 75 °C
Operating relative humidity (H-H): 10 - 90%

Weight & dimensions

Width: 83 mm
Depth: 74 mm
Height: 25 mm
Weight: 125 g
