Teltonika RUT200

Teltonika RUT200. Device type: Cellular network router, Product colour: Black, Housing material: Aluminium, Plastic. Ethernet LAN interface type: Fast Ethernet, Ethernet LAN data rates: 10,100 Mbit/s, Networking standards: IEEE 802.3, IEEE 802.3u. Wi-Fi standards: 802.11b, 802.11g, Wi-Fi 4 (802.11n). Data network: 2G, 3G, 4G, 4G standard: LTE, SIM card type: MiniSIM. Security algorithms: AES-CCMP, TKIP, WEP, WPA-EAP, WPA-PSK, WPA2-Enterprise-PEAP, WPA2-PSK

RUT200
INDUSTRIAL CELLULAR ROUTER
RUT200 is a compact industrial cellular router that provides reliable, mission-critical connectivity in rigorous conditions common in industries like automation, transportation, and manufacturing. This model is equipped with 4G LTE, Wi-Fi, and two Ethernet ports, making it ideal for quickly setting up primary and backup connectivity with remote management capabilities.

Design

Device type: Cellular network router
Product colour: Black
Housing material: Aluminium, Plastic
Feature: Reset button
LED indicators: LAN, Power

Ethernet LAN features

Feature: Ethernet LAN
Ethernet LAN interface type: Fast Ethernet
Ethernet LAN data rates: 10,100 Mbit/s
Networking standards: IEEE 802.3, IEEE 802.3u
Feature: Auto MDI/MDI-X

Wireless LAN features

Feature: Wi-Fi
Wi-Fi standards: 802.11b, 802.11g, Wi-Fi 4 (802.11n)

Mobile network

Data network: 2G, 3G, 4G
4G standard: LTE
SIM card type: MiniSIM
Feature: Short Message Service (SMS)

Ports & interfaces

Ethernet LAN (RJ-45) ports: 2

Security

Security algorithms: AES-CCMP, TKIP, WEP, WPA-EAP, WPA-PSK, WPA2-Enterprise-PEAP, WPA2-PSK
Feature: Network address translation (NAT)
Feature: Firewall
Feature: DMZ support
Feature: Port forwarding

Certificates

Certification: CB

Performance

Feature: Built-in processor
Processor manufacturer: MediaTek
Processor frequency: 0.58 GHz
RAM capacity: 0.128 GB
RAM type: DDR2
Operating system installed: RutOS
Feature: Web-based management
Antenna connector type: SMA/RP-SMA
Antennas quantity: 3

Power

Power source type: DC

Operational conditions

Operating temperature (T-T): -40 - 75 °C
Operating relative humidity (H-H): 10 - 90%

Weight & dimensions

Width: 83 mm
Depth: 74 mm
Height: 25 mm
Weight: 125 g
