Teltonika RUTX12

Teltonika RUTX12. Device type: Cellular network router, Product colour: Black, Housing material: Aluminium. Ethernet LAN interface type: Gigabit Ethernet, Ethernet LAN data rates: 10,100,1000 Mbit/s, Networking standards: IEEE 802.11e, IEEE 802.3, IEEE 802.3az, IEEE 802.3u. Wi-Fi standards: 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), WLAN data transfer rates supported: 867 Mbit/s, Wi-Fi band: Dual-band (2.4 GHz / 5 GHz). Data network: 2G, 3G, 4G, LTE, SIM card type: MiniSIM. USB port type: USB Type-A

DUAL LTE CAT 6 INDUSTRIAL CELLULAR ROUTER

This powerful dual LTE Cat 6 router is a great fit for mission-critical applications. Two cellular modems for dual simultaneous connections, seamless mobile service switching and load balancing features make this device irreplaceable in applications where losing connection is not an option.

Design

Device type: Cellular network router
Product colour: Black
Housing material: Aluminium
Mounting: DIN-rail/Wall mounting
Market positioning: Industrial
Feature: Reset button
LED indicators: LAN, Network, Power, WAN, Wi-Fi

Ethernet LAN features

Feature: Ethernet LAN
Ethernet LAN interface type: Gigabit Ethernet
Ethernet LAN data rates: 10,100,1000 Mbit/s
Networking standards: IEEE 802.11e, IEEE 802.3, IEEE 802.3az, IEEE 802.3u
Feature: DHCP server
Feature: VoIP
Feature: Auto MDI/MDI-X
Feature: Dynamic DNS (DDNS)
Feature: Universal Plug and Play (UPnP)
Feature: Network bridge

Wireless LAN features

Feature: Wi-Fi
Wi-Fi standards: 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
WLAN data transfer rates supported: 867 Mbit/s
Wi-Fi band: Dual-band (2.4 GHz / 5 GHz)
Feature: MIMO
MIMO type: Multi User MIMO

Mobile network

Data network: 2G, 3G, 4G, LTE
Number of SIM cards: 2
SIM card type: MiniSIM
4G LTE category: 6
Feature: Short Message Service (SMS)

Ports & interfaces

Ethernet LAN (RJ-45) ports: 5
USB port type: USB Type-A
Feature: USB port
USB 2.0 ports quantity: 1

Security

Feature: Network address translation (NAT)
Feature: Firewall
Feature: DMZ support
Feature: Port forwarding

Certificates

Compliance certificates: CB, CE, EAC, RCM, UKCA

GPS Performance

Feature: GLONASS
Feature: BeiDou
Feature: Galileo
Feature: Quasi-Zenith Satellite System (QZSS)

Performance

Feature: Built-in processor
Processor manufacturer: Qualcomm
Processor frequency: 0.717 GHz
RAM capacity: 0.256 GB
Internal storage capacity: 0.256 GB
Operating system installed: RutOS
Feature: GPS (satellite)
Antenna connector type: SMA/RP-SMA

Power

Power source type: DC
Input voltage: 9 - 50 V

Operational conditions

Operating temperature (T-T): -40 - 75 °C
Operating relative humidity (H-H): 10 - 90%

Weight & dimensions

Width: 132 mm
Depth: 95.1 mm
Height: 44.2 mm
Weight: 540 g

Logistics data

Country of origin: Lithuania
