TELTONIKA Industrial 24-Port PoE+ L2+ Managed Switch

SWM282 is a high-capacity L2 managed switch with enhanced L3 features designed to simplify network management and provide power and connectivity at scale. It features 24 PoE+ ports delivering up to 30W per port (total power budget of 300W) and 4 SFP slots. SupportingPROFINETand other industrial protocols, this 24-port switch is an excellent choice for enterprise networks and IIoT solutions.

PoE+
Simultaneously transmit data and power via 24 PoE+ ports - up to 30W per port

L2+
Advanced routing protocols and VLAN segmentation

Cloud support
Comes with a 2-year RMS management license

Protocols
PROFINET, MRP and EtherNet/IP for mixed industrial environments

Ethernet Fiber 4 x SFP ports IEEE 802.3 series standards 802.3i, 802.3u, 802.3ab, 802.3x, 802.3az ETH Multi-layer managed 24 x ETH ports, 10/100/1000 Mbps, supports auto MDI/MDIX crossover INDUSTRIAL PROTOCOLS Profinet Profinet Class B conformance (available with optional order code) Services EtherNet/IP Yes SNMP V2, V3 Yes LLDP Yes Network Management 802.1p class of service, 802.1x port-based network access control, 802.1Q VLAN Network Routing Dynamic routing (BGP, OSPF v2, RIP v1/v2, EIGRP) MRP MRP client role, MRP manager role L2 features Loop protection, Forwarding table, VLAN, STP/RSTP DHCP DHCP server, DHCP client, DHCP static leases capable of using MAC with wildcards Port Settings Enable/disable, link speed control, port isolation, PoE Management, EEE (802.3az) management, Port Mirroring L3 Features Static IPv4 routing, static IPv6 routing, DHCPv6 client, static IPv6 address QoS QOS Port priority, DSCP priority, 802.1p priority, TOS Scheduling method SP/WFQ/WRR Bandwidth control Rate limiting, storm control Traffic Shaper Port-based shaping Diagnostics Tools Cable diagnosis, ping, traceroute, nslookup Ping reboot Capability to restart PoE in a specific port Security Authentication PAM — preshared key, Radius TACACS+, IP login attempts block VLAN Port VLAN separation 802.1x Port-based network access control client and server MAC filtering support Allow specific MAC addresses to connect through specified ports, ignore unauthorized or disable the port if an unauthorized MAC address is detected API Teltonika Networks Web API (beta) support Expand your device's possibilities by using a set of configurable API endpoints to retrieve or change date For more information, please refer to this documentation: https://developers.teltonika-networks.com System Characteristics CPU Realtek, single core, 500MHz, MIPS-4KEc RAM 128MB, DDR3 FLASH storage 16 MB serial flash Firmware / Configuration WEB UI Update FW from file, check FW on server, configuration profiles, configuration backup FOTA Update FW RMS Update FW/configuration for multiple devices at once Keep settings Update FW without losing current configuration Factory settings reset A full factory reset restores all system settings, including the IP address, PIN, and user data to the default manufacturer's configuration. KB MAC address table size 8K entries Jumbo frame support 10000 bytes POE OUT PoE+ ports Ports 1-24 PoE standards IEEE 802.3af (PoE, Type 1) and IEEE 802.3at (PoE+, Type 2), Alternative A PoE Max Power per Port (at PSE) 30 W Total PoE Power Budget (at PSE) 300 W Power Connector C14 connector Input range voltage 100-240 VAC, 50/60 Hz Power consumption Idle: 9 W / Max: 330 W / PoE Max: 300 Physical Interfaces Ethernet 24 x RJ45 ports, 10/100/1000 Mbps Fiber 4 x SFP ports Status LEDs 1 x Power LED, 48 x ETH status LEDs, 1 x Status LED, 4 x SFP status LEDs Power 1 x C14 connector Reset Software reset button Other 1 x Grounding screw Physical Specification Casing material Anodized aluminum housing and panels Dimensions (W x H x D) 483 x 44 x 234 mm Weight 2291 g Mounting options Rack mounting kit Operating Environment Operating temperature 0 °C to 50 °C Operating humidity 10% to 90% non-condensing Ingress Protection Rating IP30 Regulatory Type Approvals Regulatory CE, UKCA, CB, RCM, FCC, IC
