MIKROTIK Ultimate Home Wi-Fi 6 AP with LTE / 5G and eSIM support Chateau 5G R17 ax
Product reference:
18-Chateau5GR17ax
MIKROTIK Ultimate Home Wi-Fi 6 AP with LTE/5G and eSIM support Chateau 5G R17 ax
MIKROTIK Ultimate Home Wi-Fi 6 AP with LTE / 5G and eSIM support Chateau 5G R17 ax
Product reference:
18-Chateau5GR17ax
MIKROTIK Ultimate Home Wi-Fi 6 AP with LTE/5G and eSIM support Chateau 5G R17 ax
You have 3 products in compare list, please remove someone and try again
- Add to favorites products
- Added to favorites products
- Removed to favorites product
Guarantee
12 month
Delivery from Lithuania in
2 - 4
business days
The Chateau 5G ax R17 may look familiar - with its sleek design, powerful dual-band Wi-Fi 6 connectivity, and all the impressive features of RouterOS v7. But inside, everything is even better.
The device now works with the most advanced5G Release 17 modem, therefore fully exploits the latest mobile communication technologies, including advanced carrier aggregation combinations. This means faster download speeds, more stable signals and faster connection response - even in regions where mobile towers are far away. No matter where you are,Chateau finds the strongest signal.
Network on your terms: eSIM or microSIM
Chateau has a real one installed on the deviceeSIM, fully compatible with:
MikroTik Connectivity(with pre-activated data plans);
Third-party eSIMs(eSIM profiles of mobile operators);
Multiple eSIM profiles(easily loaded, switched or stored).
High performance even in busy environments
Thanks to the four integratedLTE/5G antennasand two externaldual-band Wi-Fi 6 antennas, Chateau ensures excellent download and upload speeds:
Smart frequency aggregation with wideFDD + TDDlane support;
A particularly strong signal due to4x4 MIMOtechnologies;
Wi-Fi coveragedesigned for homes of various sizes, including multi-story homes.
RouterOS v7 - a powerful system with simple management
Chateau works withRouterOS v7, is an industrial-grade operating system used by vendors and IT administrators around the world. However, it also hassimple user interface, which anyone can understand. Don't want to delve into network configuration?There is a convenient iOS/Android appfor quick and easy setup!
Freedom to manage your network - no subscriptions
Create a safeVPN;
Optimizestreaming broadcasts;
Limit bandwidth;
CreateVLANsnetworks;
Block websites;
GetSMS alertswhen data limits are reached.
All this -without any subscriptions or hidden fees.
| Product code | S53UG+5HaxD2HaxD-TCRG650E-EU |
| Architecture | ARM 64bit |
| CPU | IPQ-6010 |
| CPU core count | 4 |
| CPU nominal frequency | car MHz |
| Switch chip model | IPQ-6010 |
| RouterOS license | 4 |
| Operating System | RouterOS v7 |
| RAM size | 1GB |
| Storage size | 128MB |
| Storage type | NAND |
| MTBF | Approximately 200'000 hours at 25C |
| Tested ambient temperature | -40°C to 70°C |
| IPsec hardware acceleration | Yes |
Powering
| Details | |
|---|---|
| Number of DC inputs | 1 (DC jack) |
| DC jack input Voltage | 12-28V |
| Max power consumption | 27 W |
| Max power consumption without attachments | 18W |
| Cooling type | Passive |
Mobile
| Details | |
|---|---|
| 3G Category | R8 (42.2Mbps Downlink, 5.76Mbps Uplink) |
| 3G bands | 1 (2100MHz) / 5 (850MHz) / 8 (900MHz) |
| LTE Category | 20 (2.0 Gbps Downlink, 211 Mbps Uplink) |
| MIMO DL | 4x4 |
| MIMO UL | 1x1 |
| LTE FDD bands | 1 (2100MHz) / 3 (1800MHz) / 5 (850MHz) / 7 (2600MHz) / 8 (900MHz) / 20 (800MHz) / 28 (700MHz) / 32 (1500MHz) |
| LTE TDD bands | 38 (2600MHz) / 41 (2500MHz) / 42 (3500MHz) / 40 (2300MHz) / 43 (3700MHz) |
| 5G NSA FDD bands | 1 (2100 MHz) / 3 (1800 MHz) / 5 (850 MHz) / 7 (2600 MHz) / 8 (900 MHz) / 20 (800 MHz) / 26 (850 MHz) / 28 (700 MHz) / 67 (700 MHz) / 75 (1500 MHz) / 76 (1500 MHz) |
| 5G NSA TDD bands | 38 (2600 MHz) / 40 (2300 MHz) / 41 (2500 MHz) / 77 (3700 MHz) / 78 (3500 MHz) |
| 5G SA FDD bands | 1 (2100 MHz) / 3 (1800 MHz) / 5 (850 MHz) / 7 (2600 MHz) / 8 (900 MHz) / 20 (800 MHz) / 26 (850 MHz) / 28 (700 MHz) / 67 (700 MHz) / 75 (1500 MHz) / 76 (1500 MHz) |
| 5G SA TDD bands | 38 (2600 MHz) / 40 (2300 MHz) / 41 (2500 MHz) / 77 (3700 MHz) / 78 (3500 MHz) |
| TAC | 86896506 |
Wireless specifications
| Details | |
|---|---|
| Wireless 2.4 GHz Max data rate | 574 Mbps |
| Wireless 2.4 GHz number of chains | 2 |
| Wireless 2.4 GHz standards | 802.11b/g/n/ax |
| Antenna gain dBi for 2.4 GHz | 3 |
| Wireless 2.4 GHz chip model | QCN-5022 |
| Wireless 2.4 GHz generation | Wi-Fi 6 |
| Wireless 5 GHz Max data rate | 1200 Mbps |
| Wireless 5 GHz number of chains | 2 |
| Wireless 5 GHz standards | 802.11a/n/ac/ax |
| Antenna gain dBi for 5 GHz | 6 |
| Wireless 5 GHz chip model | QCN-5052 |
| Wireless 5 GHz generation | Wi-Fi 6 |
Ethernet
| Details | |
|---|---|
| 10/100/1000 Ethernet ports | 4 |
| Number of 2.5G Ethernet ports | 1 |
Peripherals
| Details | |
|---|---|
| Number of SIM slots | 1 Modem (Micro SIM) |
| Number of USB ports | 1 |
| USB Power Reset | Yes |
| USB slot type | USB type A |
| Max USB current (A) | 1.5 |
Other
| Details | |
|---|---|
| CPU temperature monitor | Yes |
| PCB temperature monitor | Yes |
| Voltage Monitor | Yes |
| Mode button | Yes |
| eSIM | Yes |
Certifications Approvals
| Details | |
|---|---|
| Certification | CE, EAC, ROHS |
| IP | 20 |
Wireless specifications
| 2.4 GHz | Transmit (dBm) | Receive Sensitivity |
|---|---|---|
| 1MBit/s | 23 | -100 |
| 11MBit/s | 23 | -94 |
| 6MBit/s | 24 | -96 |
| 54Mbps | 21 | -80 |
| MCS0 | 24 | -96 |
| MCS7 | 20 | -75 |
| MCS9 | 19 | -70 |
| MCS11 | 17 | -67 |
| 5GHz | Transmit (dBm) | Receive Sensitivity |
|---|---|---|
| 6MBit/s | 24 | -96 |
| 54Mbps | 21 | -80 |
| MCS0 | 24 | -96 |
| MCS7 | 20 | -75 |
| MCS9 | 19 | -70 |
| MCS11 | 17 | -67 |
