The LtAP Mini LTE Kit is a small, rugged and versatile wireless access point designed to keep your vehicle connected on any journey. The latest 2024 version introduces the addedB28 frequency band support, ensuring even wider compatibility of LTE networks.
Main features:
- Durable body:Weatherproof, suitable for mounting on a wall or in a vehicle.
- LTE connection:Dual SIM slots make it easy to switch between network providers. The new LTE modem supports the most popular frequency bands, including B28.
- GPS tracking:Built-in GPS support allows real-time tracking of vehicle location. (Recommended for use with ACGPSA antenna, IP67 resistance rating).
- Flexible power supply:Power the device via DC connector, passive PoE-in or microUSB. The device can also work with a portable power bank.
- Communication connections:Ethernet port for wired devices, 2.4 GHz wireless radio, RS232 serial port for debugging.
Why choose LtAP Mini LTE Kit?This device is an ideal solution for vehicle tracking and connectivity in both urban and wild environments. It comes with a built-in RouterOS software sample that allows you to quickly get started with location tracking. In addition, the ability to connect an external LTE or GPS antenna ensures even better connection quality.
Discover new horizons of possibilities with the LtAP Mini LTE Kit - affordable, reliable and adaptable to any environment!
| Product code | RB912R-2nD-LTmEC200A-EU |
| Architecture | MIPSBE |
| CPU | QCA9531 |
| CPU core count | 1 |
| CPU nominal frequency | 650MHz |
| RouterOS license | 4 |
| Operating System | RouterOS v7 |
| RAM size | 64MB |
| Storage size | 16MB |
| Storage type | FLASH |
| MTBF | Approximately 100'000 hours at 25C |
| Tested ambient temperature | -40°C to 70°C |
Powering
| Details | |
|---|---|
| MicroUSB input Voltage | 5V |
| Number of DC inputs | 3 (DC jack, PoE-IN, MicroUSB) |
| DC jack input Voltage | 8-30V |
| Max power consumption | 8W |
| Cooling type | Passive |
| PoE in | 802.3af/at |
| PoE input voltage | 12-57V |
Mobile
| Details | |
|---|---|
| 2G Category | Class12 |
| 2G bands | 8 (900MHz) / 3 (1800MHz) |
| 3G Category | R7 (21Mbps Downlink, 5.76Mbps Uplink) |
| 3G bands | 5 (850MHz) / 8 (900MHz) / 1 (2100MHz) |
| LTE Category | 4 (150Mbps Downlink, 50Mbps Uplink) |
| MIMO DL | 2x2 |
| MIMO UL | 1x1 |
| LTE FDD bands | 20 (800MHz) / 8 (900MHz) / 3 (1800MHz) / 1 (2100MHz) / 7 (2600MHz) / 5 (850MHz) / 28 (700MHz) |
| LTE TDD bands | 40 (2300MHz) / 38 (2600MHz) / 41 (2500MHz) |
| TAC | 86314105 |
Wireless specifications
| Details | |
|---|---|
| Wireless 2.4 GHz Max data rate | 300 Mbps |
| Wireless 2.4 GHz number of chains | 2 |
| Wireless 2.4 GHz standards | 802.11b/g/n |
| Antenna gain dBi for 2.4 GHz | 1.5 |
| Wireless 2.4 GHz chip model | QCA9531 |
| Wireless 2.4 GHz generation | Wi-Fi 4 |
Ethernet
| Details | |
|---|---|
| 10/100 Ethernet ports | 1 |
Peripherals
| Details | |
|---|---|
| Number of SIM slots | 2 Modem (Mini SIM) |
| MiniPCI-e slots | 1 |
| Serial console port | RS232 |
Other
| Details | |
|---|---|
| Mode button | Yes |
| GNSS standards | GPS |
| GPS RF connector type | uUFL |
Certifications Approvals
| Details | |
|---|---|
| Certification | CE, E-MARK, EAC, ROHS |
| IP | IP54 |
