CCR2116-12G-4S+: Advanced 10G networking solution with a powerful 16-core ARM processor


Forget about CPU limitations in 10G environments with this powerful 16-core ARM CPU-based CCR router. This model features twice the speed of the previous 36-core CCR model and 6 times faster BGP performance. The device also features an M.2 PCIe slot.


The new 'CCR2116-12G-4S+' router allows you to unleash the full potential of reliable 10G networks by combining it with a modern processor. Like its 'younger brother' - the excellent CCR2004, this router is equipped with a powerful 'Amazon Annapurna Labs Alpine' processor. But with 16 cores operating at a frequency of 2 GHz, this CCR model surpasses its predecessor. This model has a single-core speed increase of at least 15%, which is very important for performing high-intensity tasks based on switching processing, such as queue processing. 'CCR2116-12G-4S+' sets a new single-core performance standard for the entire CCR product family! In addition, this device supports Layer 3 hardware offloading (Hardware Offloading)!


To make the most of this power, proper connectivity is required. The device features four 10G SFP+ ports with a dedicated full-duplex line connected to a Marvell Aldrin family switch chip. There are also 12 Gigabit Ethernet ports connected via a Marvell chip, and another Gigabit port directly connected to the CPU for management purposes.


Each group of 4 ports has a separate full-duplex connection to the switch chip, so there are no bottlenecks - you can expect switch-like performance in most settings. The next generation processors deliver incredible performance. Compared to the CCR1036 - a powerful 36-core processor, the new CCR2116 easily doubles the performance. 16 cores versus 36, but double the performance.


If you're a large Internet Service Provider (ISP) dealing with dynamic routing, massive BGP tables, complex firewall rules, and advanced QoS configurations, this is the device for you. It's a combination of raw power and convenience, with reliable 10G networking. And, as with any ISP-grade device, there's dual power redundancy for less worry.


Details
Product code CCR2116-12G-4S+
Architecture ARM 64bit
CPU AL73400
CPU core count 16
CPU nominal frequency 2000MHz
RouterOS license 6
Operating System RouterOS (v7 only)
RAM size 16GB
Storage size 128MB
Storage type NAND
MTBF Approximately 200'000 hours at 25C
Tested ambient temperature -20°C to 60°C

Powering


Details
Number of AC inputs 2
AC input range 100-240
Max power consumption 72W
Max power consumption without attachments 60W
FAN count 4

Ethernet


Details
10/100/1000 Ethernet ports 13

Fiber


Details
SFP+ ports 4

Peripherals


Details
Serial console port RJ45
Number of M.2 slots 1

Other


Details
CPU temperature monitor Yes
PCB temperature monitor Yes
Mode button Yes

Certifications Approvals


Details
Certification CE, EAC, ROHS
