Huawei B535-235a wireless router

Huawei B535-235a. WAN connection type: RJ-45. Wi-Fi band: Dual-band (2.4 GHz / 5 GHz), Top Wi-Fi standard: Wi-Fi 5 (802.11ac), WLAN data transfer rate (max): 867 Mbit/s. Mobile network generation: 4G, SIM card type: NanoSIM. Number of data streams: 2x2. Security algorithms: WEP, WPA-AES, WPA-PSK, WPA-TKIP, WPA2-AES, WPA2-PSK, WPA2-TKIP, WPA3-SAE

WAN connection

Feature: Ethernet WAN
Feature: SIM card slot
WAN connection type: RJ-45

Wireless LAN features

Wi-Fi band: Dual-band (2.4 GHz / 5 GHz)
Top Wi-Fi standard: Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max): 867 Mbit/s
Wi-Fi standards: 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
WLAN data transfer rate (first band): 400 Mbit/s
WLAN data transfer rate (second band): 867 Mbit/s

Network

Feature: Ethernet LAN
Feature: Dynamic DNS (DDNS)
Feature: SSID-based VLAN assignment

Mobile network

Mobile network generation: 4G
4G LTE category: 7
SIM card type: NanoSIM
Feature: Short Message Service (SMS)

Ports & interfaces

Ethernet LAN (RJ-45) ports: 4
RJ-11 ports quantity: 1
Feature: DC-in jack

Management features

Feature: Web-based management
Feature: Reset button
Feature: MIMO
Number of data streams: 2x2

Security

Security algorithms: WEP, WPA-AES, WPA-PSK, WPA-TKIP, WPA2-AES, WPA2-PSK, WPA2-TKIP, WPA3-SAE
Feature: Firewall
Feature: DDoS protection
Feature: MAC address filtering
Feature: DMZ support
Feature: Network address translation (NAT)

Protocols

Supported network protocols: IPv6/IPv4

Design

Product colour: White
Product type: Tabletop router

Packaging content

Cables included: LAN (RJ-45), Phone (RJ-11)
Feature: AC adapter included
Feature: Quick start guide

Antenna

Antenna design: Internal & external
Antenna connector type: SMA

Features

Internal memory: 256 MB
Flash memory: 256 MB

Power

Power source type: DC
AC input voltage: 100 - 240 V
AC input frequency: 50 - 60 Hz
Output voltage: 12 V
Output current: 2 A
Power consumption (typical): 24 W
Feature: External power adapter

Operational conditions

Operating temperature (T-T): 0 - 40 °C
Storage temperature (T-T): -20 - 70 °C

System requirements

Windows operating systems supported: Windows 10, Windows 11, Windows 8, Windows 8.1
Mac operating systems supported: Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 10.15.3 Catalina

Weight & dimensions

Width: 219 mm
Depth: 66 mm
Height: 138 mm
Weight: 330 g

Packaging data

Number of products included: 1 pc(s)
