Power Supply, XILENCE, 700 Watts, PFC Active, XN054
Product reference:
2-4044953501234
Power Supply, XILENCE, 700 Watts, PFC Active, XN054
Product reference:
2-4044953501234
You have 3 products in compare list, please remove someone and try again
- Add to favorites products
- Added to favorites products
- Removed to favorites product
Guarantee
24 month
Delivery from Lithuania in
3 - 5
business days
Not available
The latest generation of Redwing power supplies combines an exciting design with modern technology and top quality. In the current revision, the power supply series has been completely revised and adapted to the demands of today's computer systems. The result not only convinces through its efficient technic, but with its modern design and high stability. The connections have been coordinated to current systems and four integrated safety circuits always ensure safe operation.
| AC input frequency | 50 Hz |
| AC input voltage | 200 - 240 V |
| ATX power connector (20+4 pin) | Yes |
| ATX version | 2.31 |
| Bearing technology | FDB |
| Cabling type | Non-Modular |
| Combined power (+12V) | 648 W |
| Combined power (+3.3V) | 120 W |
| Combined power (+5V) | 120 W |
| Compliance certificates | RoHS/WEEE |
| Cooling type | Active |
| CPU P4 connector (4-pin) | 1 |
| CPU power cable length | 550 mm |
| Fan diameter | 120 mm |
| Fan location | Top |
| Input current | 8 A |
| Max output current (+12V) | 54 A |
| Max output current (+3.3V) | 24 A |
| Max output current (+5V) | 18 A |
| Max output current (+5Vsb) | 2.5 A |
| Max output current (-12V) | 0.5 A |
| Motherboard power cable length | 450 mm |
| Motherboard power connector | 20+4 pin ATX |
| Number of fans | 1 fan(s) |
| Number of SATA power connectors | 6 |
| On/off switch | Yes |
| Package depth | 165 mm |
| Package height | 100 mm |
| Package type | Box |
| Package weight | 1840 g |
| Package width | 225 mm |
| PCI Express connector | Yes |
| PCI Express power cable length | 500 mm |
| PCI Express power connectors (6+2 pin) | 1 |
| PCI Express power connectors (6-pin) | 1 |
| Peripheral (Molex) power connectors (4-pin) | 2 |
| Power Factor Correction (PFC) type | Passive |
| Power protection features | Over current/Over power/Over voltage/Overheating/Short circuit/Under voltage |
| Power supply unit (PSU) form factor | ATX |
| Product colour | Black |
| Product Net Weight | 1.2 kg |
| Purpose | PC |
| Shipping Box Depth | 53 cm |
| Shipping Box Height | 18 cm |
| Shipping Box Weight | 15.960000038147 kg |
| Shipping Box Width | 48.5 cm |
| Summary | Xilence Performance A+ XN054. Total power: 700 W, AC input voltage: 200 - 240 V, AC input frequency: 50 Hz. Motherboard power connector: 20+4 pin ATX, Motherboard power cable length: 45 cm, PCI Express power cable length: 50 cm. Purpose: PC, Power supply unit (PSU) form factor: ATX, Bearing technology: FDB. Product colour: Black, Cooling type: Active, Fan diameter: 12 cm. Compliance certificates: RoHS, WEEE |
| Total power | 700 W |
| Unit Box Height | 0.1 |
| Unit Box Length | 0.23 |
| Unit Box Width | 0.165 |
| Unit Calculated Volume | 0.004627 cubm |
| Unit Calculated Weight | 1.6 kg |
| Units per Shipping Box | 10 |
| Vendor Homepage | https://www.xilence.net/en/power-supplies/25 |
