Power Supply, TECNOWARE, FAL551FSP12, ATX, 550 W, FAL551FSP12
Product reference:
2-8026475183408
Power Supply, TECNOWARE, FAL551FSP12, ATX, 550 W, FAL551FSP12
Product reference:
2-8026475183408
You have 3 products in compare list, please remove someone and try again
- Add to favorites products
- Added to favorites products
- Removed to favorites product
Guarantee
24 month
Delivery from Lithuania in
3 - 5
business days
Not available
Internal power supply for personal computer, 550W power, input voltage 230 Vac, 50/60 Hz, conforms to ATX 12V v.2.31 specifications, main switch, surge protection, overload protection, short circuit protection, high MTBF, high reliability, quiet operation, 12 cm silent fan, temperature control of the fan speed, Flat type connection cables from 500mm to 800mm, 1 x 20+4-pin connector, 1 x 12V 4+4-pin connector, 1 x 6+2 PCI-E connector, 2 x Molex connectors, 4 x Sata connector, dimensions 150x140x86 mm, weight 1.0 Kg, black color, CE certification, RoHS.
- Internal Power Supply for Computers
- High Efficiency (> 85%) and High Operation Noise
- Active PFC > 0.9
- Dimensions: 140x86x150 mm (WxHxD)
- Input voltage 230 Vac 50Hz
- Temperature control of the fan speed
- Flat connection cables from 500mm to 800mm
- Surge protection
- Overload protection
- Short circuit protection
| 80 PLUS certification | No |
| AC input frequency | 47 - 63 Hz |
| AC input voltage | 180 - 264 V |
| ATX power connector (20+4 pin) | Yes |
| ATX version | 2.31 |
| Cabling type | Non-Modular |
| Combined power (+12V) | 360 W |
| Combined power (+3.3V) | 170 W |
| Combined power (+5V) | 170 W |
| Combined power (+5Vsb) | 12.5 W |
| Combined power (-12V) | 9.6 W |
| Compliance certificates | CE/RoHS |
| CPU power cable length | 550 mm |
| CPU power connector (4+4 pin) | Yes |
| Depth | 150 mm |
| Efficiency | 85 % |
| Fan diameter | 120 mm |
| Height | 86 mm |
| Input current | 5 A |
| Max output current (+12V) | 30 A |
| Max output current (+3.3V) | 23 A |
| Max output current (+5V) | 24 A |
| Max output current (+5Vsb) | 2.5 A |
| Max output current (-12V) | 0.8 A |
| Model name | FAL551FSP12 |
| Motherboard power cable length | 500 mm |
| Motherboard power connector | 20+4 pin ATX |
| Number of fans | 1 fan(s) |
| Number of SATA power connectors | 4 |
| On/off switch | Yes |
| Operating temperature (T-T) | 0 - 40 °C |
| Package type | Box |
| PCI Express power cable length | 500 mm |
| PCI Express power connectors (6+2 pin) | 1 |
| Peripheral (Molex) power connectors (4-pin) | 2 |
| Power factor | 0.9 |
| Power Factor Correction (PFC) type | Active |
| Power protection features | Overload/Short circuit/Surge protection |
| Power supply unit (PSU) form factor | ATX |
| Product colour | Black |
| Purpose | PC |
| Storage temperature (T-T) | -15 - 40 °C |
| Summary | Tecnoware Free Silent PRO 550. Total power: 550 W, AC input voltage: 180 - 264 V, AC input frequency: 47 - 63 Hz. Motherboard power connector: 20+4 pin ATX, Motherboard power cable length: 50 cm, PCI Express power cable length: 50 cm. Purpose: PC, Power supply unit (PSU) form factor: ATX. Product colour: Black, Fan diameter: 12 cm, Number of fans: 1 fan(s). Compliance certificates: CE, RoHS |
| Total power | 550 W |
| Unit Box Height | 0.1 |
| Unit Box Length | 0.2 |
| Unit Box Width | 0.16 |
| Unit Calculated Volume | 0.0034 cubm |
| Unit Calculated Weight | 1.13 kg |
| Units per Shipping Box | 8 |
| Vendor Homepage | https://www.tecnoware.com/en-US/Dettaglio/Articolo/883 |
| Weight | 1000 g |
| Width | 140 mm |
