Pressing on with its One Seasonic Initiative, the PRIME TX, PRIME PX and PRIME GX series became the successors to the Seasonic PRIME and PRIME Ultra series.
The PRIME Series has always demonstrated outstanding performance and have become the epitome of technological excellence and quality through the years. This third generation of PRIME Series rolled out not only with a uniformed naming scheme but also with updated general design and connection cables. As each new model in these PRIME series have their distinctive set of features and specifications, prospective customers will find a streamlined buying guidance through understanding the One Seasonic process.
80 PLUS PLATINUM
The PRIME Platinum Series achieves 80 PLUS Platinum certification with its 92 % efficiency at 50 % system load.
MICRO TOLERANCE LOAD REGULATION
Seasonic's latest design keeps the output voltage within a very tight range, achieving under 0.5 % load regulation. This impressive electrical performance and stability makes this power supply an ideal choice for high-performance systems.
PREMIUM HYBRID FAN CONTROL
Seasonic's vast experience in designing the most silent and efficient power supplies on the market was translated into the development of Hybrid Mode; a state-of-the-art fan control that enables users to keep the overall fan noise at the lowest possible level.
FLUID DYNAMIC FAN BEARING
High performance Fluid Dynamic Bearing (FDB) fans are designed to take advantage of the impact absorbance effects of oil. They are extremely reliable and generate considerably less operating noise and heat than ball bearing fans. The lubrication of the bearing surface reduces friction and vibration and therefore lowers overall power consumption. Due to the effortless, quieter rotations and its robust construction, this reliable fan technology also greatly increases the lifespan of the fan.
HOW IT WORKS
When the fan shaft rotates, high pressure oil drifts along the grooves of the bearing sleeve to generate a thin layer of lubrication between the bearing faces. As the speed increases, so does dynamic oil pressure and the shaft is lifted from the bearing to create smooth, effortless rotations. The herringbone shape of the groves helps to efficiently channel the lubricant and avert leakage.
CABLE-FREE CONNECTION DESIGN
Seasonic's engineers have implemented a new design feature, where instead of cables; the back panel and the PCB (Printed Circuit Board) are connected by a copper plate. This breakthrough solution not only lowers the chance of production errors during manual insertion but it also improves output power quality.
| AC įėjimo dažnis | 50 - 60 Hz |
| AC įėjimo įtampa | 100 - 240 V |
| Atitikties sertifikatai | RoHS |
| Aukštis | 86 mm |
| Aušinimo padengimo tipas | FDB |
| Aušinimo tipas | Aktyvus |
| Bendroji galia | 1300 W |
| Bruto svoris | 5.95 kg |
| CPU maitinimo jungtis (4 + 4 kaisčiai) | Taip |
| Darbo temperatūros diapazonas (TT) | 0 - 50 °C |
| Didžiausia išėjimo įtampa (+12 V) | 108 A |
| Didžiausia išėjimo įtampa (+12 VSB) | 3 A |
| Didžiausia išėjimo įtampa (+3,3 V) | 25 A |
| Didžiausia išėjimo įtampa (+5 V) | 25 A |
| Didžiausia išėjimo įtampa (-12 V) | 0.3 A |
| Ilgis | 210 mm |
| Kompleksinė galia (+12 V) | 1296 W |
| Kompleksinė galia (+3,3 V) | 125 W |
| Kompleksinė galia (+5 VSB) | 15 W |
| Kompleksinė galia (+5V) | 125 W |
| Kompleksinė galia (-12 V) | 3.6 W |
| Maitinimo apsaugos ypatybės | Apsauga nuo per didelės įtampos/Trumpasis jungimas/Viršijus nuolatinę srovę |
| Maitinimo bloko (PSU) formos koeficientas | ATX |
| Model | RIME-TX-1300-ATX30 |
| Model name | PRIME TX ATX 3.0 |
| Motininės plokštės maitinimo jungtis | 20+4 pin ATX |
| Motininės plokštės maitinimo kabelio ilgis | 610 mm |
| Neto svoris | 1.5 kg |
| On/off mygtukas | Taip |
| Pakuotės tipas | "Box" |
| Paskirtis | PC |
| Perdavimo laidu tipas | Visiškai modulinis |
| Periferinė (Molex) galios jungtis (4-pin) | 5 |
| Plotis | 150 mm |
| Pridedamas (-i) laidų užveržiklis (-iai) | Taip |
| Pridėti kabeliai | AC,PCIe,Peripheral (Molex),Peripheral (Molex) to SATA 3.3,SATA |
| Produkto spalva | Juoda |
| SATA elektros jungčių skaičius | 14 |
| Sertifikatas 80 PLUS | 80 PLUS Platinum |
| Sertifikavimas | cTUVus, TUV, CB, CCC, BSMI, EAC, Energy Star, RoHS, WEEE, ErP Lot 6, REACH |
| Shipping Box Depth | 55 cm |
| Shipping Box Height | 49 cm |
| Shipping Box Weight | 23.8 kg |
| Shipping Box Width | 22.5 cm |
| Summary | Seasonic Prime -TX-1300. Total power: 1300 W, AC input voltage: 100 - 240 V, AC input frequency: 50 - 60 Hz. Motherboard power connector: 20+4 pin ATX, Motherboard power cable length: 61 cm, Cabling type: Fully-Modular. Purpose: PC, Power supply unit (PSU) form factor: ATX, 80 PLUS certification: 80 PLUS Platinum. Product colour: Black, Cooling type: Active, Fan diameter: 13.5 cm. Cables included: AC, PCIe, Peripheral (Molex), Peripheral (Molex) to SATA 3.3, SATA |
| Unit Box Height | 0.195 |
| Unit Box Length | 0.45 |
| Unit Box Width | 0.125 |
| Unit Brutto Volume | 0.01516 cubm |
| Vendor Homepage | https://seasonic.com/prime-px |
| Ventiliatoriaus skersmuo | 135 mm |
| Ventiliatorių skaičius | 1 ventiliatorius(iai / ių) |
| Vidutinis laikas tarp trikčių (MTBF) | 150000 h |
| Vieneto aukštis | 19.5 cm |
| Vieneto gylis | 45 cm |
| Vieneto plotis | 12.5 cm |
| Vienetų skaičius vienoje siuntimo dėžėje | 4 |
| Įvesties srovė | 15 - 7.5 A |
