New Evolution of Bronze
MONTECH BETA 2 leads the evolution of essential power supplies, bringing modern standards, refined design, and long-term reliability to the 80 PLUS Bronze segment. Built on the ATX 3.1 standard and with PCIe 5.1 support available on the 850W model, BETA 2 is designed to power today and tomorrow's systems with greater stability, efficiency, and confidence.
Next-Gen Ready
BETA 2 is fully compliant with the latest ATX 3.1 standard, ensuring safer and more reliable power delivery for modern platforms.
80 PLUS Bronze Efficiency
Certified with 80 PLUS Bronze efficiency, BETA 2 delivers optimized power conversion with reduced energy loss. The improved internal design helps maintain consistent efficiency across typical usage scenarios, balancing performance and value.
Enhanced Power Architecture
BETA 2 adopts DC-to-DC technology to deliver tighter voltage regulation and reduced fluctuation under load. This design improves overall system stability and helps protect sensitive components during power transitions.
High Quality Components
At the heart of BETA 2 is an industrial-grade Japanese main capacitor rated for 105°C/221°F operation. Built to withstand high temperatures and long-term stress, it enhances durability and reduces the risk of instability over time.
Upgraded Cooling
BETA 2 features an upgraded HDB cooling fan, delivering quieter operation and improved longevity compared to traditional sleeve-bearing designs. Optimized airflow supports stable performance even during extended workloads.
Refined Aesthetics & Premium Cabling
The MONTECH signature chassis design supports efficient airflow, while upgraded embossed cables deliver a cleaner, more premium look and a more refined overall build presentation.
Comprehensive Protection & Extended 5-Year Warranty
BETA 2 is built with comprehensive power protections including OPP, OVP, UVP, SCP, OCP, OTP to ensure stable operation for your system. Backed by an extended 5-year warranty, it reflects MONTECH's confidence in long-term reliability and commitment to dependable performance you can trust.
| AC įėjimo dažnis | 50/60 Hz |
| AC įėjimo įtampa | 100 - 240 V |
| Atitikties sertifikatai | BSMI/CB/cTUVus/EAC/Federalinė ryšių komisija (FCC)/KC/KCC/RCM/RoHS/TÜV mark/UKCA |
| ATX versija | 3.1 |
| Aukštis | 86 mm |
| Aušinimo padengimo tipas | HDB |
| Aušinimo tipas | Aktyvus |
| Bendroji galia | 550 W |
| Bruto svoris | 1.99 kg |
| CPU maitinimo jungtis (4 + 4 kaisčiai) | Taip |
| Darbo temperatūros diapazonas (TT) | 0 - 40 °C |
| Didžiausia išėjimo įtampa (+12 V) | 45.8 A |
| Didžiausia išėjimo įtampa (+12 VSB) | 3 A |
| Didžiausia išėjimo įtampa (+3,3 V) | 13 A |
| Didžiausia išėjimo įtampa (+5 V) | 13 A |
| Didžiausia išėjimo įtampa (-12 V) | 0.3 A |
| Garantinis laikotarpis | 5 metai |
| Ilgis | 140 mm |
| Iliuminacija | Ne |
| Kompleksinė galia (+12 V) | 549.6 W |
| Kompleksinė galia (+3,3 V) | 80 W |
| Kompleksinė galia (+5 VSB) | 15 W |
| Kompleksinė galia (+5V) | 80 W |
| Kompleksinė galia (-12 V) | 3.6 W |
| Maitinimo apsaugos ypatybės | Apsauga nuo per didelės įtampos/Apsauga nuo perkaitimo/Minimaliosios įtampos apsauga/Trumpasis jungimas/Viršijus galią/Viršijus nuolatinę srovę |
| Maitinimo bloko (PSU) formos koeficientas | ATX |
| Model name | BETA 2 |
| Motininės plokštės maitinimo jungtis | 20+4 pin ATX |
| Neto svoris | 1.4 kg |
| On/off mygtukas | Taip |
| Pakuotės tipas | "Box" |
| Paskirtis | PC |
| PCI "Express" maitinimo jungtys (6 + 2 kontaktai) | 2 |
| Perdavimo laidu tipas | Ne modulinis |
| Periferinė (Molex) galios jungtis (4-pin) | 4 |
| Plotis | 150 mm |
| Produkto spalva | Juoda |
| SATA elektros jungčių skaičius | 4 |
| SATA maitinimo kabelių skaičius | 1 |
| Sertifikatas 80 PLUS | 80 PLUS Bronze |
| Shipping Box Depth | 54.5 cm |
| Shipping Box Height | 23.5 cm |
| Shipping Box Weight | 15.9 kg |
| Shipping Box Width | 43 cm |
| Sudėtyje nėra | Gyvsidabris/Kadmis/Švinas |
| Summary | Montech BETA 2. Total power: 550 W, AC input voltage: 100 - 240 V, AC input frequency: 50/60 Hz. Motherboard power connector: 20+4 pin ATX, Cabling type: Non-Modular. Purpose: PC, Power supply unit (PSU) form factor: ATX, 80 PLUS certification: 80 PLUS Bronze. Product colour: Black, Cooling type: Active, Fan diameter: 12 cm. Compliance certificates: CB, BSMI, EAC, Federal Communications Commission (FCC), KC, KCC, RCM, RoHS, cTUVus, TÜV mark, UKCA |
| Unit Box Height | 0.1 |
| Unit Box Length | 0.255 |
| Unit Box Width | 0.2 |
| Unit Brutto Volume | 0.006884 cubm |
| Vendor Homepage | https://www.montechpc.com/beta-2-550w |
| Ventiliatoriaus skersmuo | 120 mm |
| Ventiliatorių skaičius | 1 ventiliatorius(iai / ių) |
| Vieneto aukštis | 10 cm |
| Vieneto gylis | 25.5 cm |
| Vieneto plotis | 20 cm |
| Vienetų skaičius vienoje siuntimo dėžėje | 8 |
| Įvesties srovė | 12 A |
